Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 707001803 | Throttle Pedal | 1 |
| 2 | 707001990 | Bushing | 2 |
| 2 | 250100031 | Push Nut | 2 |
| 2 | 233081416 | Hex. Flange Nut M8 | 2 |
| 4 | 707001807 | Anti-Vibration Mount | 4 |
| 2 | 207609046 | Hex. Flange Screw M10 X 90 | 2 |
| 2 | 233201436 | Hex. Flange Elastic Nut M10 | 2 |
| 2 | 707001808 | Anti-Vibration Mount | 2 |
| 1 | 230602546 | Hex. Flange Screw M10 X 125 | 1 |
| 1 | 233201436 | Hex. Flange Elastic Nut M10 | 1 |
| 1 | 707001881 | Rear Engine Support | 1 |
| 6 | 207582544 | Hex. Flange Screw M8 X 25, Scotch Grip | 6 |
| 1 | 706600077 | Front Inlet Duct | 1 |
| 1 | 514052924 | Norma Clamp | 1 |
| 1 | 706600137 | Seal | 1 |
| 1 | 706600138 | Seal | 1 |
| 1 | 706600129 | Adaptor | 1 |
| 6 | 250000722 | Torx Screw M6 X 20 | 6 |
| 6 | 250000957 | Extruded Panel Nut M6 | 6 |
| 1 | 706600148 | CVT Filter Includes 240 to 240b | 1 |
| 1 | 706600136 | Seal | 1 |
| 1 | 706600139 | Seal | 1 |
| 1 | 708000909 | Latch | 1 |
| 1 | 706600078 | Front Outlet Duct | 1 |
| 1 | 514052983 | Norma Gear Clamp | 1 |
| 1 | 706600147 | Hose Support | 1 |
| 2 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 2 |
| 1 | 293150230 | Tuflok Plastic Rivet | 1 |
| 1 | 706600080 | Rear Inlet Duct | 1 |
| 1 | 706600081 | Rear Outlet Duct | 1 |
| 1 | 514052861 | Gear Clamp (Norma) | 1 |
| 1 | 707002056 | Outlet Support | 1 |
| 2 | 207664044 | Hex. Flange Screw M6 X 40 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 1 | 707000911 | Lever | 1 |
| 1 | 207663544 | Hex. Flange Screw M6 X 35 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 1 | 707001614 | Cable Support | 1 |
| 2 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 2 |
| 1 | 707001809 | Shifting Cable | 1 |
| 2 | 232581414 | Hex. Elastic Stop Nut M8 | 2 |
| 1 | 234001410 | Flat Washer 10 mm | 1 |
| 1 | 707000828 | Lower Lever Arm | 1 |
| 2 | 707000847 | Flanged Bushing | 2 |
| 1 | 707001376 | Bushing | 1 |
| 2 | 234062410 | Flat Washer 6 mm | 2 |
| 1 | 207667056 | Hex. Flange Screw M6 X 70 | 1 |
| 1 | 707000711 | Upper Lever Arm | 1 |
| 2 | 707000869 | Flanged Bushing | 2 |
| 1 | 207665044 | Hex. Flange Screw M6 X 50 | 1 |
| 1 | 707000750 | Lever Arm Spring | 1 |
| 1 | 707000965 | Lever Button | 1 |
| 1 | 232180491 | Hex. Jam Nut M8 | 1 |
| 1 | 293650042 | Oetiker Clamp | 1 |
| 1 | 293750058 | 2-Pieces Fixing Tie Rap for Edges | 1 |
| 1 | 293710171 | Elbow Fitting | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 219704389 | Polyurethane Hose 4000MM Long | 1 |
| 219704449 | TUBING 13MM I.D. 300MM LONG | ||
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 707001981 | Valve Support | 1 |
| 2 | 390402000 | Pop Rivet 3/16" | 2 |
| 2 | 207552044 | Hex. Flange Screw M5 X 20, Scotch Grip | 2 |
| 2 | 293450268 | Insert M5 X 0.8 | 2 |
| 1 | 293650262 | Oeticker Clamp | 1 |
| 2 | 207662554 | Hex. Flange Screw M6 X 25 | 2 |
| 2 | 250100198 | Panel Nut M6 X 1.0 | 2 |
| 1 | 707001931 | Hose Vent | 1 |
| 2 | 293650051 | Tridon Gear Clamp | 2 |
| 1 | 219704450 | Corrugated Sheath 23 MM ID 1000MM Long | 1 |
| 1 | 710005037 | Clip Tie-Rap | 1 |
| 1 | 219704407 | Tubing 10 MM 1000MM Long | 1 |
