Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 706203039 | LH Front Suspension Upper Arm Package XMR - SunBurst Yellow | 1 |
| 1 | 706202977 | Deep Black, LH Front Upper Suspension Arm Packages CAB, Lone Star Edition & XMR | 1 |
| 1 | 706203257 | Red, LH Front Upper Suspension Arm Package XTP | 1 |
| 1 | 706203251 | LH Front Upper Suspension Arm Packages Hunting Edition, XTP, XT & DPS | 1 |
| 1 | 706203040 | RH Front Suspension Upper Arm Package XMR - SunBurst Yellow | 1 |
| 1 | 706202978 | Deep Black, RH Front Upper Suspension Arm Packages CAB, Lone Star Edition & XMR | 1 |
| 1 | 706203258 | Red, RH Front Upper Suspension Arm Package XTP | 1 |
| 1 | 706203252 | RH Front Upper Suspension Arm Packages Hunting Edition, XTP, XT & DPS | 1 |
| 16 | 703500875 | Suspension Arm Bushing Kit | 16 |
| 8 | 703500875 | Suspension Arm Bushing Kit | 8 |
| 8 | 408200700 | Grease Fitting | 8 |
| 1 | 706203041 | LH Front Suspension Lower Arm Package XMR - SunBurst Yellow | 1 |
| 1 | 706202979 | Deep Black, LH Front Lower Suspension Arm Packages CAB, Lone Star Edition & XMR | 1 |
| 1 | 706203045 | Red, LH Front Lower Suspension Arm Package XTP | 1 |
| 1 | 706203028 | LH Front Lower Suspension Arm Packages Hunting Edition, XTP, XT & DPS | 1 |
| 1 | 706203042 | RH Front Suspension Lower Arm Package XMR - SunBurst Yellow | 1 |
| 1 | 706202980 | Deep Black, RH Front Lower Suspension Arm Packages CAB, Lone Star Edition & XMR | 1 |
| 1 | 706203046 | Red, RH Front Lower Suspension Arm Package XTP | 1 |
| 1 | 706203029 | RH Front Lower Suspension Arm Packages Hunting Edition, XTP, XT & DPS | 1 |
| 6 | 207607046 | Hex. Flange Screw M10 X 70 | 6 |
| 2 | 207607046 | Hex. Flange Screw M10 X 70 | 2 |
| 10 | 233201436 | Hex. Flange Elastic Nut M10 | 10 |
| 2 | 706203084 | Ball Joint | 2 |
| 2 | 706202045 | Ball Joint | 2 |
| 4 | 293150104 | Pop Rivet 3/16" | 4 |
| 1 | 706202135 | RH CV joint Guard | 1 |
| 1 | 706202134 | LH CV joint Guard | 1 |
| 1 | 706203096 | LH Front Knuckle | 1 |
| 1 | 706203097 | RH Front Knuckle | 1 |
| 4 | 293370035 | Circlip | 4 |
| 2 | 250100099 | Nut M12 | 2 |
| 2 | 250200086 | Flat Washer | 2 |
| 2 | 211400017 | Cotter Pin | 2 |
| 4 | 207606046 | Hex. Flange Screw M10 X 6 Package CAB & Lone Star Edition | 4 |
| 2 | 207605546 | Hex. Flange Screw M10 X 55 | 2 |
| 1 | 706203167 | Sway Bar Packages CAB, Lone Star Edition & XMR | 1 |
| 2 | 706203437 | Clamp Packages CAB, Lone Star Edition & XMR | 2 |
| 2 | 706002535 | Cushion Packages CAB, Lone Star Edition & XMR | 2 |
| 2 | 293550056 | Grease Fitting 90° Packages CAB, Lone Star Edition & XMR | 2 |
| 4 | 250000951 | Hex. Flange Screw DIN.6921 Packages CAB, Lone Star Edition & XMR | 4 |
| 4 | 233221466 | Elastic Flange Nut M12 Packages CAB, Lone Star Edition & XMR | 4 |
| 1 | 706202538 | RH Stabilizer Bar Link Packages CAB, Lone Star Edition & XMR | 1 |
| 1 | 706202539 | LH Stabilizer Bar Link Packages CAB, Lone Star Edition & XMR | 1 |
| 4 | 233201436 | Hex. Flange Elastic Nut M10 Packages CAB, Lone Star Edition & XMR | 4 |
| 4 | 234201474 | Conical Spring Washer 10 mm Packages CAB, Lone Star Edition & XMR | 4 |
