Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 703500982 | Door Limit Device Kit | 2 |
| 2 | 250000722 | Torx Screw M6 X 20 | 2 |
| 6 | 234062670 | Stainless Steel Flat Washer | 6 |
| 4 | 708300737 | Bushing | 4 |
| 705800659 | DOOR_RIGID FL ASSY Includes 300 to 300ap | ||
| 1 | 705800047 | Driver Door Harness | 1 |
| 1 | 705800594 | LH Window Regulator Ass'y | 1 |
| 1 | 705800016 | LH Roll-Down Glass | 1 |
| 1 | 703500915 | LH Interior Latch Kit Includes 300d to 300d3 | 1 |
| XXX | Not Available As Spare Parts | ||
| 1 | 705800608 | LH A-Pillar Glass | 1 |
| 1 | 705800322 | LH Routed Inner Door | 1 |
| 1 | 705800665 | LH Ext Door Panel Includes 300j to 300j2 | 1 |
| 1 | 715900703 | Seal | 1 |
| 2 | 710004979 | Window Switch | 2 |
| 1 | 705800015 | Exterior Paddle Latch | 1 |
| 1 | 705800289 | Seal 705800290 - 5000 MM | 1 |
| 1 | 715006687 | LH Door Panel Kit | 1 |
| 1 | 705800324 | LH Interior Handle | 1 |
| 2 | 705800595 | Window Guide Bracket | 2 |
| 2 | 705800590 | Window Guide Extrusion | 2 |
| 1 | 705800184 | Key Set | 1 |
| 2 | 705800591 | Folcked Beltline Trim 705800294 600mm | 2 |
| 1 | 705800604 | LH Door Pocket | 1 |
| 9 | 705009405 | Plastic Dart | 9 |
| 7 | 250000874 | Torx Truss M8 X 25 Not Shown | 7 |
| 3 | 205951046 | Socket Head Screw M5 X 10 | 3 |
| 9 | 293730011 | Black, Dart | 9 |
| 8 | 205460860 | Socket Screw M6 X 8 Not Shown | 8 |
| 6 | 234062670 | Stainless Steel Flat Washer Not Shown | 6 |
| 6 | 250000995 | Torx-truss M/s M6 X 10 | 6 |
| 4 | 250000789 | Torx Truss M6X14 Not Shown | 4 |
| 1 | 250000616 | Black, Socket Screw, M6 X 16 S.Grip | 1 |
| 2 | 205484060 | Socket Head Screw M8 X 40 | 2 |
| 2 | 233261494 | Hex. Flange Elastic Nut M6 Not Shown | 2 |
| 2 | 233281466 | Elastic Flange Nut M8 | 2 |
| 1 | 207662044 | Hex. Flange Screw M6 X 20 Not Shown | 1 |
| 1 | 715900493 | LH Latch Cable 2.4'' Not Shown | 1 |
| 1 | 715900504 | Interior Latch Cable 28'' Not Shown | 1 |
| 2 | 715900526 | LH Power Window Switch Housing | 2 |
| 1 | 705800038 | Striker Bolt | 1 |
| 1 | 250200005 | Conical Spring Washer M12 | 1 |
| 1 | 232521416 | Elastic Stop Nut M12 | 1 |
| 4 | 250000874 | Torx Truss M8 X 25 | 4 |
| 7 | 250000874 | Torx Truss M8 X 25 | 7 |
| 1 | 705800898 | LH Front Striker Support | 1 |
| 1 | 705800342 | LH Upper Female Door Hinge | 1 |
| 2 | 705800482 | Lower Female Door Hinge | 2 |
| 1 | 705800340 | LH Upper Male Door Hinge | 1 |
| 1 | 705800344 | LH Lower Male Door Hinge | 1 |
| 2 | 250000874 | Torx Truss M8 X 25 | 2 |
| 2 | 293370125 | Retaining Ring | 2 |
| 705800660 | DOOR_RIGID FR ASSY Includes 400 to 400an | ||
| 1 | 705800050 | Passenger Door Harness | 1 |
| 1 | 705800593 | RH Window Regulator Ass'y | 1 |
| 1 | 705800025 | RH Roll-Down Glass | 1 |
| 1 | 703500916 | RH Interior Latch Kit Includes 400d to 400d3 | 1 |
| 1 | 705800609 | RH A-Pillar Glass | 1 |
| 1 | 705800323 | RH Routed Inner Door | 1 |
| 1 | 705800666 | RH Door Panel EXT Includes 400j to 400j2 | 1 |
| 1 | 710004979 | Window Switch | 1 |
| 1 | 715006689 | RH Door Panel Kit | 1 |
| 1 | 705800325 | RH Interior Handle | 1 |
| 1 | 705800591 | Folcked Beltline Trim 705800294 600mm | 1 |
| 1 | 705800605 | RH Door Pocket | 1 |
| 1 | 715900494 | RH Latch Cable 2.9'' Not Shown | 1 |
| 1 | 715900527 | RH Power Window Switch Housing | 1 |
| 1 | 705800900 | RH Front Striker Support | 1 |
| 1 | 705800343 | RH Female Upper Door Hinge | 1 |
| 1 | 705800341 | RH Male Upper Door Hinge | 1 |
| 1 | 705800345 | RH Lower Male Door Hinge | 1 |
