Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 40543-437-000 | ADJUSTER, CHAIN | 1 |
| 1 | 95014-12100 | ADJUSTER C, R. CHAIN | 1 |
| 41200-446-000 | SPROCKET, FINAL DRIVEN (58T) | ||
| 41200-446-810 | SPROCKET, FINAL DRIVEN (56T) (Optional). | ||
| 41200-446-820 | SPROCKET, FINAL DRIVEN (60T) (Optional). | ||
| 4 | 41241-307-010 | BUSH, RR. WHEEL DAMPER | 4 |
| 42304-437-000 | COLLAR, RR. WHEEL SIDE | ||
| 42610-437-000ZA | HUB, RR. WHEEL *NH105* (MAT BLACK) | ||
| 42620-437-000 | COLLAR, RR. AXLE DISTANCE | ||
| 42701-446-003 | RIM, RR. WHEEL (1.85X18) (DAIDO) | ||
| 42711-446-003 | TIRE, RR. (4.10-18) (BS) | ||
| 1 | 0Y400-41300 | TUBE, TIRE (3.50/4.10-18) (BS) | 1 |
| 1 | 08400-30000 | TUBE, TIRE (5.10-18) (BS) | 1 |
| 1 | 08400-41300 | TUBE, TIRE (3.50/4.10-18) (BS) | 1 |
| 1 | 42712-KA3-711 | TUBE, TIRE (130/80-140/90) (BS) | 1 |
| 1 | 42712-KA5-681 | TUBE, TIRE (5.10-18) (BS) | 1 |
| 1 | 42712-KS7-003 | TUBE, TIRE | 1 |
| 1 | 42712-KT1-671 | TUBE, TIRE (100/100-18) (INOUE) | 1 |
| 1 | 42712-430-701 | TUBE, TIRE (5.10-18) (BS) | 1 |
| 1 | 42712-446-003 | TUBE, TIRE (3.50/4.10-18) (BS) | 1 |
| 1 | 42713-268-003 | FLAP, TIRE (18) (BS) | 1 |
| 2 | 42715-KA2-680 | STOPPER, BEAD (1.85) | 2 |
| 2 | 42715-360-006 | STOPPER, BEAD (1.85B) | 2 |
| 2 | 42715-444-000 | STOPPER, BEAD (1.85) | 2 |
| 4 | 90128-391-000 | BOLT, DRIVEN SPROCKET FIXING | 4 |
| 1 | 90305-401-680 | NUT, AXLE (14MM) | 1 |
| 4 | 90308-382-670 | NUT, FLANGE (10MM) | 4 |
| 1 | 90664-216-000 | CIRCLIP (58MM) | 1 |
| 1 | 91257-230-000 | OIL SEAL (28X42X7) | 1 |
| 1 | 91257-230-003 | OIL SEAL (28X42X7) (ARAI) | 1 |
| 1 | 91257-230-005 | OIL SEAL (28X42X7) (NOK) | 1 |
| 1 | 90310-KA3-711 | NUT, HEX. (6MM) | 1 |
| 1 | 94000-06000-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06000 | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06000-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06008-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94001-06200-0S | NUT, HEX. (6MM) | 1 |
| 1 | 94030-06000 | NUT, HEX. (6MM) | 1 |
| 1 | 94103-06000 | WASHER, PLAIN (6MM) | 1 |
| 1 | 94111-06000 | WASHER, SPRING (6MM) | 1 |
| 1 | 94201-30250 | PIN, COTTER (3.0X25) | 1 |
| 1 | 94201-30300 | PIN, COTTER (3X30) | 1 |
| 1 | 94201-30400 | PIN, COTTER (3.0X40) | 1 |
| 1 | 94201-30450 | PIN, COTTER (3.0X45) | 1 |
| 2 | 96140-63020-10 | BEARING, RADIAL BALL (6302U) | 2 |
| 2 | 96150-63020-10 | BEARING, RADIAL BALL (6302UU) | 2 |
| 97506-69178-Q0 | SPOKE SET BS (8X169) | ||
| 18 | 97716-69177-Q0 | SPOKE BS (8X168.5) | 18 |
