Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705007918 | LH REAR FENDER SUPPORT | 1 |
| 1 | 705007919 | RH REAR FENDER SUPPORT | 1 |
| 2 | 705007917 | Support Plate | 2 |
| 4 | 250000760 | Torx Screw Truss Head K50X20 T20 | 4 |
| 2 | 250000957 | Extruded Panel Nut M6 | 2 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 2 | 250000646 | Black, Torx Screw M6 X 35 | 2 |
| 1 | 705009037 | White LH Rear Fender Package XC | 1 |
| 1 | 705009037 | White LH Rear Fender Package DPS | 1 |
| 1 | 705010785 | FENDER REAR L B-101 Package XCDPS | 1 |
| 1 | 705009038 | White RH Rear Fender Package DPS | 1 |
| 1 | 705009038 | White RH Rear Fender Package XC | 1 |
| 1 | 705010786 | RIGHT REAR FENDER Package XCDPS | 1 |
| 6 | 517302785 | Edge Clip | 6 |
| 1 | 705009548 | LH Inner Fender | 1 |
| 1 | 705009549 | RH Inner Fender | 1 |
| 12 | 250000958 | Panel Nut M5 X 0.8 | 12 |
| 6 | 250000724 | Torx Screw M5 X 20 | 6 |
| 6 | 250000762 | Torx Screw M5 X 25 | 6 |
| 6 | 250200025 | Washer M5 | 6 |
| 4 | 250000712 | Torx Screw M6 X 20 | 4 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 2 | 250000712 | Torx Screw M6 X 20 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 4 | 705011221 | Red Reflector | 4 |
| 4 | 233251494 | Elastic Flange Nut M5 | 4 |
| 1 | 705006128 | Bagage Central Rack | 1 |
| 1 | 705006132 | Central Bagage Rack Cap | 1 |
| 1 | 705006279 | Bagage Rack Tube | 1 |
| 705003559 | Lugage Rack | ||
| 1 | 705005469 | Tube | 1 |
| 1 | 705005470 | Tube | 1 |
| 2 | 250000648 | Torx Screw M6 X 60 | 2 |
| 8 | 250000646 | Black, Torx Screw M6 X 35 | 8 |
| 2 | 250000647 | Torx Screw M6 X 45 | 2 |
| 12 | 233261434 | Flange Elastic Nut M6 | 12 |
| 2 | 207561634 | Hex. Flange Screw M6 X 16, Scotch Grip | 2 |
| 293450274 | Insert | ||
| 1 | 705006713 | LH Bagage Rack Cover | 1 |
| 1 | 705006714 | RH BAGAGE RACK COVER | 1 |
| 1 | 705005994 | LOGO Support | 1 |
| 1 | 250000720 | Torx Screw K50 X 16 | 1 |
| 2 | 705007828 | Deflector | 2 |
| 6 | 293150089 | Tuflok Plastic Rivet | 6 |
| 4 | 250200025 | Washer M5 | 4 |
| 4 | 250000724 | Torx Screw M5 X 20 | 4 |
| 1 | 705004731 | LH Rear Facia | 1 |
| 1 | 705004732 | RH Rear Facia | 1 |
| 1 | 705007370 | WHITE LH REAR FACIA TRIM Package DPS Bright White Models | 1 |
| 1 | 705007370 | WHITE LH REAR FACIA TRIM Package XC | 1 |
| 1 | 705010793 | Trim LH Can-Am Red Package XCDPS | 1 |
| 1 | 705007371 | WHITE RH REAR FACIA TRIM Package XC | 1 |
| 1 | 705007371 | WHITE RH REAR FACIA TRIM Package DPS Bright White Models | 1 |
| 1 | 705010794 | TRIM_HEADLIGHT REAR R B-101 Package XCDPS | 1 |
| 4 | 233261434 | Flange Elastic Nut M6 | 4 |
| 2 | 250000958 | Panel Nut M5 X 0.8 | 2 |
| 2 | 250000724 | Torx Screw M5 X 20 | 2 |
| 2 | 224060201 | Flat Washer | 2 |
| 4 | 705007044 | Rear Support Facia Clip | 4 |
| 2 | 207687044 | Hex. Flange Screw M8 X 70 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 1 | 705007299 | Body Tube | 1 |
| 1 | 705007045 | LH Rear Facia Support | 1 |
| 1 | 705007046 | RH Rear Facia Support | 1 |
| 2 | 705007047 | TUBE CONNECTOR | 2 |
| 2 | 207562544 | Hex. Flange Screw M6 X 25 | 2 |
| 2 | 224061201 | Flat Washer | 2 |
