Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705012077 | Painted Sunburst Yellow LH Front Panel Carbon Black Models | 1 |
| 1 | 705012078 | Painted Sunburst Yellow RH Front Panel Carbon Black Models | 1 |
| 2 | 250000722 | Torx Screw M6 X 20 | 2 |
| 2 | 250000957 | Extruded Panel Nut M6 | 2 |
| 4 | 250000957 | Extruded Panel Nut M6 | 4 |
| 4 | 250000760 | Torx Screw Truss Head K50X20 T20 | 4 |
| 4 | 234051410 | Flat Washer M5 | 4 |
| 2 | 293150089 | Tuflok Plastic Rivet | 2 |
| 1 | 705012083 | Painted Carbon Black Lh Rear Panel Carbon Black Models | 1 |
| 1 | 705012084 | Painted Carbon Black RH Rear Panel Carbon Black Models | 1 |
| 2 | 250000843 | Torx Truss Screw M6 X 30 | 2 |
| 1 | 250000748 | Torx Screw M6 X 45 | 1 |
| 3 | 250000957 | Extruded Panel Nut M6 | 3 |
| 1 | 705006991 | LH Lateral Middle Panel | 1 |
| 1 | 705006992 | RH Lateral Middle Panel | 1 |
| 8 | 293150104 | Pop Rivet 3/16" | 8 |
| 2 | 705007827 | Inner Fender | 2 |
| 4 | 293150089 | Tuflok Plastic Rivet | 4 |
| 4 | 210261650 | Hex. Flange Screw M6 X 16 | 4 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 1 | 705006038 | LH BUMPER SKID CAP | 1 |
| 1 | 705006039 | RH BUMPER SKID CAP | 1 |
| 2 | 250000712 | Torx Screw M6 X 20 | 2 |
| 2 | 233261494 | Hex. Elastic Flange Nut M6 | 2 |
| 1 | 705005798 | Front Skid Plate | 1 |
| 4 | 291001932 | Pad | 4 |
| 1 | 705005480 | Rear Skid Plate | 1 |
| 22 | 705007171 | Cup | 22 |
| 22 | 210262050 | Hexagonal Head Screw | 22 |
| 8 | 250000957 | Extruded Panel Nut M6 | 8 |
| 2 | 705007038 | RH Lateral Skid Plate | 2 |
| 4 | 250200097 | Flat Washer | 4 |
| 4 | 210262050 | Hexagonal Head Screw | 4 |
| 14 | 293150104 | Pop Rivet 3/16" | 14 |
| 1 | 705008988 | LH Front Deflector Carbon Black Models | 1 |
| 1 | 705008989 | RH Front Deflector Carbon Black Models | 1 |
| 10 | 250000842 | Stainless, Torx Screw M6 X 30 Carbon Black Models | 10 |
| 8 | 234062670 | Stainless Steel Flat Washer Carbon Black Models | 8 |
| 8 | 232561434 | Elastic Stop Nut M6 Carbon Black Models | 8 |
| 1 | 705007637 | LH Rear Deflector Carbon Black Models | 1 |
| 1 | 705007638 | RH Rear Deflector Carbon Black Models | 1 |
| 8 | 250000712 | Torx Screw M6 X 20 Carbon Black Models | 8 |
| 6 | 234062670 | Stainless Steel Flat Washer Carbon Black Models | 6 |
| 3 | 250000758 | Torx Screw M6 X 25 Carbon Black Models | 3 |
| 11 | 234062670 | Stainless Steel Flat Washer Carbon Black Models | 11 |
| 11 | 232561434 | Elastic Stop Nut M6 Carbon Black Models | 11 |
| 1 | 250200086 | Flat Washer Carbon Black Models | 1 |
| 4 | 250100031 | Push Nut | 4 |
