Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 6 | 11009-1344 | GASKET,8.2X14X1.0 | 6 |
| 1 | 11009-1532 | GASKET,BEVEL GEAR CAS | 1 |
| 1 | 92065-058 | GASKET,10.5X16X1 | 1 |
| 11012-1477 | CAP,BEARING | ||
| 1 | 13048-1069 | CAM-DAMPER | 1 |
| 13101-1097 | GEAR-ASSY,FRONT BEVEL | ||
| 1 | 13101-5062 | GEAR-ASSY,FRONT BEVEL | 1 |
| 1 | 13107-1190 | SHAFT,BEVEL GEAR,FR | 1 |
| 1 | 13151-1007 | SWITCH-COMP,NEUTRAL | 1 |
| 1 | 14055-1065 | CASE-GEAR,BEVEL,FR | 1 |
| 1 | 16115-1009 | CAP-OIL FILLER | 1 |
| 1 | 26011-1351 | WIRE-LEAD | 1 |
| 1 | 32033-1706 | PIPE,OIL | 1 |
| 1 | 32033-1707 | PIPE,OIL | 1 |
| 1 | 41046-1067 | HOUSING-BEARING | 1 |
| 1 | 42034-1014 | COUPLING,FRONT DRIVEN | 1 |
| 1 | 51036-1002 | CUP | 1 |
| 1 | 52005-1057 | GAUGE,OIL LEVEL | 1 |
| 1 | 92001-1169 | BOLT,FLANGED,12X42 | 1 |
| 92002-1429 | BOLT,BANJO,8X20 | ||
| 1 | 92002-1449 | BOLT,6X10 | 1 |
| 2 | 92002-1582 | BOLT,FLANGED,6X25 | 2 |
| 2 | 92002-1583 | BOLT,6X50 | 2 |
| 2 | 92002-1584 | BOLT,6X60 | 2 |
| 3 | 92002-1585 | BOLT,6X105 | 3 |
| 4 | 92002-1612 | BOLT,6X25 | 4 |
| 1 | 92004-1109 | STUD | 1 |
| 1 | 92015-1543 | NUT | 1 |
| 1 | 92025-1072 | SHIM,25.2X29.8X1.70 | 1 |
| 1 | 92025-1073 | SHIM,25.2X29.8X1.72 | 1 |
| 1 | 92025-1074 | SHIM,25.2X29.8X1.74 | 1 |
| 1 | 92025-1075 | SHIM,25.2X29.8X1.76 | 1 |
| 1 | 92025-1076 | SHIM,25.2X29.8X1.78 | 1 |
| 1 | 92025-1077 | SHIM,25.2X29.8X1.80 | 1 |
| 92025-1606 | SHIM,T=0.1 | ||
| 1 | 92025-1607 | SHIM,T=0.15 | 1 |
| 1 | 92025-1608 | SHIM,T=0.5 | 1 |
| 1 | 92025-1609 | SHIM,T=0.6 | 1 |
| 1 | 92025-1610 | SHIM,T=0.7 | 1 |
| 1 | 92025-1611 | SHIM,T=0.8 | 1 |
| 1 | 92025-1612 | SHIM,T=0.9 | 1 |
| 1 | 92025-1613 | SHIM,T=1.0 | 1 |
| 1 | 92025-1614 | SHIM,T=1.2 | 1 |
| 1 | 92025-1688 | SHIM,25.3X36X0.15 | 1 |
| 1 | 92025-1689 | SHIM,25.3X36X0.50 | 1 |
| 1 | 92025-1690 | SHIM,25.3X36X0.60 | 1 |
| 1 | 92025-1691 | SHIM,25.3X36X0.70 | 1 |
| 1 | 92025-1692 | SHIM,25.3X36X0.80 | 1 |
| 1 | 92025-1693 | SHIM,25.3X36X0.90 | 1 |
| 1 | 92025-1694 | SHIM,25.3X36X1.00 | 1 |
| 1 | 92025-1695 | SHIM,25.3X36X1.10 | 1 |
| 1 | 92025-1696 | SHIM,25.3X36X1.20 | 1 |
| 1 | 92027-1152 | COLLAR,25.2X29.8X22.8 | 1 |
| 92027-1153 | COLLAR,25.2X29.8X22.9 | ||
| 1 | 92027-1154 | COLLAR,25.2X29.8X23 | 1 |
| 1 | 92027-1155 | COLLAR,25.2X29.8X23.1 | 1 |
| 1 | 92027-1156 | COLLAR,25.2X29.8X23.2 | 1 |
| 92027-1157 | COLLAR,25.2X29.8X23.3 | ||
| 1 | 92027-1158 | COLLAR,25.2X29.8X23.4 | 1 |
| 1 | 92027-1159 | COLLAR,25.2X29.8X23.5 | 1 |
| 1 | 92027-1160 | COLLAR,25.2X29.8X23.6 | 1 |
| 1 | 92027-1161 | COLLAR,25.2X29.8X23.7 | 1 |
| 1 | 92027-1162 | COLLAR,25.2X29.8X23.8 | 1 |
| 1 | 92027-1163 | COLLAR,25.2X29.8X23.9 | 1 |
| 1 | 92027-1164 | COLLAR,25.2X29.8X24 | 1 |
| 1 | 92027-1165 | COLLAR,25.2X29.8X24.1 | 1 |
| 3 | 92037-1539 | CLAMP,L=45 | 3 |
| 2 | 92042-007 | PIN,DOWEL,6.3X8X14 | 2 |
| 1 | 92045-1160 | BEARING-BALL | 1 |
| 1 | 92049-1017 | SEAL-OIL,SD-8187 | 1 |
| 1 | 92049-1038 | SEAL-OIL,TC35527 | 1 |
| 1 | 92051-005 | SEAL-OIL,TB13225.5 | 1 |
| 1 | 92055-049 | RING-O,31.5X2.6 | 1 |
| 1 | 92055-1044 | RING-O,ID=18.64 | 1 |
| 1 | 92066-1012 | PLUG,OIL LINE,7.2X8 | 1 |
| 1 | 92081-1859 | SPRING,CAM DAMPER | 1 |
| 1 | 92116-1003 | BEARING-ROLLER,4T30205 | 1 |
| 92116-1006 | BRG,ROLLER,4T-30305 | ||
| 4 | 130S0625 | BOLT-FLANGED,6X25,BLA | 4 |
| 1 | 670B1506 | O RING,6MM | 1 |
| 1 | 671B2565 | O RING,65MM | 1 |
| 1 | 671B2570 | 0 RING,70MM | 1 |
