Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8KG-F1950-00-00 | REAR FRAME COMP. | 1 |
| 2 | 8JR-F1911-00-00 | PANEL, FRAME | 1 |
| 3 | 8JR-F1954-00-00 | BRACKET, REAR TRACK SUS | 1 |
| 4 | 8JR-F1944-00-00 | BRACKET, REAR TRACK SUS | 1 |
| 5 | 8JP-RA520-00-00 | RIVET, 11 UN | 73 |
| 6 | 8JP-RA532-00-00 | RIVET, 20 UN | 14 |
| 7 | 8JP-RA370-00-00 | NUT, HEX. LOCKING | |
| 8 | 8JW-F115M-00-00 | BRACKET, MEMBER 2 | 1 |
| 9 | 8JW-F115L-00-00 | BRACKET, MEMBER 1 | |
| 10 | 8JP-RA239-00-00 | SCREW, 5 | 8 |
| 11 | 8JP-RA528-00-00 | RIVET, 3/16 | 2 |
| 12 | 8JP-RA529-00-00 | RIVET, 17 UN | 55 |
| 13 | 8KG-F1912-00-00 | PANEL, SUB FRAME 1 | 1 |
| 14 | 8JP-RA530-00-00 | RIVET, 18 | 16 |
| 15 | 8JW-F1923-00-00 | REINFORCEMENT, FRAME REAR 1 | 1 |
| 16 | 8JP-F1919-00-00 | BRACKET | 1 |
| 17 | 8JP-RA521-00-00 | RIVET, 12 | 2 |
| 18 | 8JP-RA272-00-00 | SCREW, M8X1.25X20 | |
| 19 | 8JP-F2556-00-00 | SUPPORT, FUEL TANK 2 | 1 |
| 20 | 8JP-F2555-00-00 | SUPPORT, FUEL TANK 1 | 1 |
| 21 | 8JP-F192E-00-00 | REINFORCEMENT, FRAME | 1 |
| 22 | 8JP-F1929-00-00 | REINFORCEMENT, FRAME SIDE | 1 |
| 23 | 8JM-RA301-00-00 | NUT, SELF-LOCKING M8-1.25 | 2 |
| 24 | 8JP-RA247-00-00 | SCREW, M5X0.8X35 | 4 |
| 25 | 8JP-RA353-00-00 | NUT, CLIP M5 | 9 |
| 26 | 8JW-F1996-00-00 | REINFORCEMENT SUB FRAME FRONT 2 | 1 |
| 27 | 8JW-F1995-00-00 | REINFORCEMENT SUB FRAME FRONT 1 | 1 |
| 28 | 8JP-RA251-00-00 | SCREW, M5X1.0X16 | 4 |
| 29 | 8JP-F2147-00-00 | PROTECTOR, CHAIN | 1 |
| 30 | 8JP-RA523-00-00 | RIVET, 14 | 8 |
| 31 | 8JP-F5717-00-00 | PROTECTOR, DISC BRAKE | 1 |
| 32 | 8JW-F5718-00-00 | PROTECTOR, DISC BRAKE | 1 |
| 33 | 8JP-RA179-00-00 | BOLT, FLANGE M6X1.0X12 | 2 |
| 34 | 8JP-RA244-00-00 | SCREW, M5X0.8X20 | 1 |
| 35 | 8JP-RA526-00-00 | RIVET, 3/16 UN | 2 |
| 36 | 8JW-F1926-00-00 | REINFORCEMENT, FOOTREST 1 | 2 |
| 37 | 8KG-H2589-00-00 | PROTECTER, WIRE HARNESS | 1 |
| 38 | 8JP-RA527-00-00 | RIVET, 3/16 | 4 |
| 39 | 8KG-F1135-00-00 | GUSSET | 1 |
| 40 | 8KG-F1134-00-00 | GUSSET | 1 |
| 41 | 8JW-F1137-00-00 | GUSSET | 1 |
| 42 | 8JW-F1136-00-00 | GUSSET | 1 |
| 43 | 8JP-F151A-00-00 | LABEL 1 | |
| 44 | 8JW-F117E-10-00 | BRACKET, TAILLIGHT | 1 |
| 45 | 8JP-K7762-70-00 | LABEL, WARNING 2 (ENGLISH) | 1 |
| 46 | 8JP-K7762-S0-00 | LABEL, WARNING 2 (FRENCH) | 1 |
| 47 | 8JP-F197C-00-00 | PROTECTOR, FRAME 3 | 1 |
| 48 | 8JP-F197B-00-00 | PROTECTOR, FRAME | 1 |
| 49 | 8KG-F1978-00-00 | PROTECTOR, FRAME | 2 |
| 50 | 8JP-F4141-00-00 | PROTECTOR, FUEL TANK | 1 |
| 51 | 8KN-RAP08-00-00 | DECAL, FRAME 7 FOR DPBSE | 1 |
| 52 | 8KN-RAP09-00-00 | DECAL, FRAME 8 FOR DPBSE | 1 |
| 53 | 8KN-RAP0A-00-00 | DECAL, FRAME 9 FOR DPBSE | 1 |
| 54 | 8KN-RAP0B-00-00 | DECAL, FRAME 10 FOR DPBSE | 1 |
| 55 | 8KN-RAP0C-00-00 | DECAL, FRAME 11 UR FOR DPBSE | 1 |
| 8KN-RAP08-10-00 | DECAL, FRAME 7 UR FOR BWC1 | 0 | |
| 56 | 8KN-RAP0D-00-00 | DECAL, FRAME 12 UR FOR DPBSE | 1 |
| 8KN-RAP09-10-00 | DECAL, FRAME 8 UR FOR BWC1 | 0 | |
| 57 | 8KN-RAP0E-00-00 | DECAL, FRAME 13 UR FOR DPBSE | |
| 8KN-RAP0C-10-00 | DECAL, FRAME 11 UR FOR BWC1 | 0 | |
| 58 | 8KN-RAP0F-00-00 | DECAL, FRAME 14 UR FOR DPBSE | 1 |
| 8KN-RAP0D-10-00 | DECAL, FRAME 12 UR FOR BWC1 | 0 | |
| 59 | 8KG-RAP0G-00-00 | DECAL, FRAME 15 UR FOR DPBSE | |
| 8KG-RAP0G-10-00 | DECAL, FRAME 15 UR FOR BWC1 | ||
| 60 | 8KG-RAP0H-00-00 | DECAL, FRAME 16 UR FOR DPBSE | |
| 8KG-RAP0H-10-00 | DECAL, FRAME 16 UR FOR BWC1 | ||
| 61 | 8JP-F8100-00-00 | TOOL KIT | |
| 62 | 8JP-RA524-00-00 | RIVET, 15 | 1 |
