Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 705010721 | Clip | 2 |
| 1 | 705012472 | Carbon Black, LH Door Panel | 1 |
| 1 | 705012547 | Blue Door Frame LH Blue Cage Model | 1 |
| 1 | 705011187 | Door Support | 1 |
| 2 | 207582054 | Washer Head Hexa. Screw M8 X 20 | 2 |
| 2 | 234081430 | Flat Washer M8 | 2 |
| 2 | 234081100 | Flat Washer 8 mm, Nylon | 2 |
| 1 | 705012183 | LH Latch | 1 |
| 1 | 293850126 | Belt | 1 |
| 1 | 293150108 | Pop Rivet 3/16” | 1 |
| 1 | 293730070 | Belt Stopper | 1 |
| 1 | 293730072 | Belt Stopper | 1 |
| 1 | 705010734 | LH Latch Cover | 1 |
| 2 | 250000957 | Extruded Panel Nut M6 | 2 |
| 2 | 250000721 | Torx Truss Screw M6 X 16 | 2 |
| 1 | 234062670 | Stainless Steel Flat Washer | 1 |
| 1 | 293150103 | Pop Rivet 3/16" | 1 |
| 1 | 250000957 | Extruded Panel Nut M6 | 1 |
| 3 | 250000722 | Torx Screw M6 X 20 | 3 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 1 | 293850129 | Door Belt | 1 |
| 2 | 293150103 | Pop Rivet 3/16" | 2 |
| 1 | 705010732 | LH Lower Door Panel | 1 |
| 2 | 250000749 | Torx Truss Screw M6 X 50 | 2 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 2 | 233261466 | Hex. Flange Elastic Nut M6 | 2 |
| 1 | 705012473 | Carbon Black, RH Door Panel | 1 |
| 1 | 705012548 | Blue Door Frame RH Blue Cage Model | 1 |
| 1 | 705012184 | RH Latch | 1 |
| 1 | 705010735 | RH Latch Cover | 1 |
| 1 | 705010733 | RH Lower Door Panel | 1 |
| 1 | 715004064 | LH Front Lateral Panel Kit | 1 |
| 5 | 250000722 | Torx Screw M6 X 20 | 5 |
| 2 | 250000712 | Torx Screw M6 X 20 | 2 |
| 1 | 250000807 | Torx Truss Screw M6 X 25 | 1 |
| 2 | 233261494 | Hex. Elastic Flange Nut M6 | 2 |
| 293450274 | Insert | ||
| 3 | 250000957 | Extruded Panel Nut M6 | 3 |
| 1 | 250000868 | Torx Truss M6 X 50 | 1 |
| 1 | 715004074 | RH Front Lateral Panel Kit | 1 |
| 6 | 250000722 | Torx Screw M6 X 20 | 6 |
| 1 | 233261494 | Hex. Elastic Flange Nut M6 | 1 |
| 1 | 517303756 | Grommet | 1 |
| 1 | 705010334 | RH Side Panel Cover | 1 |
| 2 | 250000807 | Torx Truss Screw M6 X 25 | 2 |
| 2 | 250000720 | Torx Screw K50 X 16 | 2 |
| 1 | 705012768 | LH Central Lateral Panel | 1 |
| 1 | 705012769 | RH Central Lateral Panel | 1 |
| 4 | 250000722 | Torx Screw M6 X 20 | 4 |
| 2 | 705010872 | Insert | 2 |
| 1 | 705012770 | LH Rear Lateral Panel | 1 |
| 1 | 705012771 | RH Rear Lateral Panel | 1 |
| 2 | 293150104 | Pop Rivet 3/16" | 2 |
| 2 | 705003841 | Support Plate | 2 |
| 14 | 250000722 | Torx Screw M6 X 20 | 14 |
| 4 | 705003841 | Support Plate | 4 |
| 1 | 715002903 | Door Panels Includes 7300 to 7300m | 1 |
| 1 | 705010271 | LH Door Panels | 1 |
| 1 | 705012018 | Door Seal | 1 |
| 1 | 705010272 | RH Door Panels | 1 |
| 4 | 250000902 | Torx-Truss M/S M6 X 80 | 4 |
| 12 | 233261494 | Hex. Elastic Flange Nut M6 | 12 |
| 10 | 705202223 | Offset Washer | 10 |
| 8 | 250000749 | Torx Truss Screw M6 X 50 | 8 |
| 6 | 234062670 | Stainless Steel Flat Washer | 6 |
| 1 | 219704364 | Neoprene Seal (1PAC=3M) | 1 |
| 1 | 705012772 | LH Lateral Panel | 1 |
| 5 | 250200164 | Flat washer M6 | 5 |
| 5 | 250000807 | Torx Truss Screw M6 X 25 | 5 |
| 1 | 705012773 | RH Lateral Panel | 1 |
| 1 | 705012774 | LH Lateral Structure | 1 |
| 5 | 250000957 | Extruded Panel Nut M6 | 5 |
| 3 | 207587534 | Hex. Flange Screw M8 X 75, Scotch Grip | 3 |
| 3 | 233281464 | Elastic Flange Nut M8 | 3 |
| 1 | 705012775 | RH Lateral Structure | 1 |
