Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 207503044 | Hex. Screw M10 X 1.5 X 30 | 1 |
| 7 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 7 |
| 2 | 230681034 | Hex. Flange Screw M8 X 110 | 2 |
| XXX | Not Available As Spare Parts | ||
| 1 | 207189060 | Hex. Screw M8 x 90 | 1 |
| 4 | 232180600 | Hex. Jam Nut M8 | 4 |
| 2 | 233281434 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 234281704 | Spring Washer M8 | 2 |
| 4 | 250000099 | Allen Plastite Screw #12 | 4 |
| 2 | 207503046 | Hex. Flange Screw M10 X 30, Scotch Grip | 2 |
| 1 | 207561044 | Flange Screw M6 X 10, Scotch Grip | 1 |
| 1 | 230020586 | Hexagonal Screw M12 X 105 | 1 |
| 1 | 232521416 | Elastic Stop Nut M12 | 1 |
| 2 | 234001410 | Flat Washer 10 mm | 2 |
| 2 | 234021430 | Flat Washer | 2 |
| 4 | 250000223 | Torx Screw M6 X 16 | 4 |
| 2 | 250200136 | Plastic Washer 20MM | 2 |
| 1 | 705005333 | RH Front Rubber Pad | 1 |
| 1 | 705005334 | RH FRONT FOOTREST ASS'Y | 1 |
| 1 | 705005723 | Pivot Support | 1 |
| 2 | 705005861 | Pivot Bracket | 2 |
| 1 | 705005367 | Latch Ass'y | 1 |
| 1 | 705006428 | Latch Pin M12 X 30 | 1 |
| 1 | 705006533 | Spring | 1 |
| 1 | 705006557 | Retaining Plate | 1 |
| 1 | 705600458 | Bearing | 1 |
| 2 | 706000447 | Bearing | 2 |
| 2 | 706000448 | Seal, Single Lip ID 19.4 OD 26 | 2 |
| 1 | 706000731 | Bushing | 1 |
| 1 | 708000759 | Rubber Stopper | 1 |
| 2 | 250100069 | Panel Nut M8 X 1.25 | 2 |
| 4 | 503183800 | Washer | 4 |
| 1 | 518327010 | LH ROCKER PANEL FOAM | 1 |
| 1 | 518327011 | RH ROCKER PANEL FOAM | 1 |
| 518327438 | RH LATERAL PANEL FOAM | ||
| 4 | 705002153 | Bushing | 4 |
| 2 | 705003013 | Adjuster Block | 2 |
| 4 | 705003018 | Rubber Bushing | 4 |
| 1 | 705005266 | LH ROCKER PANEL | 1 |
| 1 | 705005267 | RH Rocker Panel | 1 |
| 1 | 705007678 | BLACK CURRENT LH SIDE CONSOLE Model-Black | 1 |
| 1 | 705007689 | WHITE LH SIDE CONSOLE Model-White | 1 |
| 1 | 705006796 | LH REAR FOOT SUPPORT | 1 |
| 705006798 | LH REAR FOOTREST | ||
| 1 | 705006801 | BLACK RH SLIDING BLOCK | 1 |
| 705006794 | RH FOOTREST SUPPORT, BLACK | ||
| 1 | 705006800 | Black RH Footrest Support | 1 |
| 1 | 705005350 | RH REAR RUBBER PAD | 1 |
| 1 | 705005351 | LH REAR RUBBER PAD | 1 |
| 1 | 705005413 | LH DEFLECTOR PANNEL | 1 |
| 705007680 | BLACK CURRENT RH SIDE CONSOLE Model-Black | ||
| 1 | 705007690 | WHITE RH SIDE CONSOLE Model-White | 1 |
| 4 | 708000759 | Rubber Stopper | 4 |
| 2 | 250000130 | Torx Screw M5 X 20 | 2 |
| 2 | 250000079 | Panel Nut M5 X 0.8 | 2 |
| 4 | 250000079 | Panel Nut M5 X 0.8 | 4 |
| 2 | 250000661 | Socket Screw M5 X 16 F/ | 2 |
| 1 | 705005330 | LH Front Footrest Ass'y | 1 |
| 1 | 705006297 | LH FRONT RUBBER PAD | 1 |
| 1 | 705005329 | LH FRONT RUBBER PAD | 1 |
| 2 | 705007473 | Lock Plate | 2 |
| XXXX | Not Available As Spare Part - Retaining Ring |
