Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 207065544 | Hex. Screw M6 X 55 | 1 |
| 2 | 207663544 | Hex. Flange Screw M6 X 35 | 2 |
| 4 | 207682544 | Hex. Flange Screw M8 X 25 BRE | 4 |
| 4 | 207682544 | Hex. Flange Screw M8 X 25 AUS | 4 |
| 4 | 207682544 | Hex. Flange Screw M8 X 25 EUR | 4 |
| 4 | 210262080 | Hex. Forming Screw M6 X 20 TLTD | 4 |
| 230060060 | Hex. Screw M6 X 100 | ||
| 1 | 230065060 | Hex. Screw M6 X 150 | 1 |
| 1 | 232180600 | Hex. Jam Nut M8 TLTD | 1 |
| 2 | 232361600 | Nut M6 RS Brezil | 2 |
| 2 | 232361600 | Nut M6 RS Australie | 2 |
| 2 | 232361600 | Nut M6 Europe | 2 |
| 2 | 232561494 | Elastic Stop Nut M6 RS Australie | 2 |
| 2 | 232561494 | Elastic Stop Nut M6 RS Brezil | 2 |
| 2 | 232561494 | Elastic Stop Nut M6 Europe | 2 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 1 | 233261494 | Hex. Flange Elastic Nut M6 TLTD | 1 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 1 | 234081410 | Flat Washer 8 mm | 1 |
| 6 | 250000081 | Torx Screw M6 X 25 | 6 |
| 4 | 250000303 | Torx Truss Screw M6 X 20 TLTD | 4 |
| 1 | 250000348 | Torx Truss Screw M6 X 16 TLTD | 1 |
| 1 | 250000350 | Torx Truss Screw M6 X 20 TLTD | 1 |
| 4 | 250000446 | Torx Screw M6 X 20, Scotch Grip | 4 |
| 2 | 250000454 | Torx Screw M6 X 12 | 2 |
| 1 | 250100113 | Panel Nut, M6 X 1.0 TLTD | 1 |
| 2 | 250100113 | Panel Nut, M6 X 1.0 TLTD | 2 |
| 4 | 269500706 | Sleeve | 4 |
| 4 | 269501943 | Elastic Nut Housing M8 EUR | 4 |
| 4 | 269501943 | Elastic Nut Housing M8 AUS | 4 |
| 4 | 269501943 | Elastic Nut Housing M8 BRE | 4 |
| 1 | 269501481 | REAR ARM | 1 |
| 1 | 269501482 | FRONT ARM | 1 |
| 4 | 293150089 | Tuflok Plastic Rivet TLTD | 4 |
| 1 | 219704371 | Neoprene Seal 3000 mm Long TLTD | 1 |
| 4 | 293740028 | Dual Lock Velcro Washer 3/4" | 4 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 2 | 414436900 | BLACK SNAP CAP | 2 |
| 12 | 414479100 | Clip | 12 |
| 1 | 517303484 | Hood Cable | 1 |
| 1 | 518325515 | LH FRONT PANEL FOAM | 1 |
| 1 | 518325516 | RH FRONT PANEL FOAM | 1 |
| 2 | 705000321 | Oval Washer | 2 |
| 1 | 705003875 | Pearl White Front Fascia White | 1 |
| 705006612 | BLACK CURRENT FRONT FASCIA Black Current Met | ||
| 1 | 705001469 | LH HEADLAMP BEZEL EUR | 1 |
| 1 | 705001469 | LH HEADLAMP BEZEL AUS | 1 |
| 1 | 705001469 | LH HEADLAMP BEZEL BRE | 1 |
| 1 | 705001470 | RH Headlamp Bezel AUS | 1 |
| 1 | 705001470 | RH Headlamp Bezel EUR | 1 |
| 1 | 705001470 | RH Headlamp Bezel BRE | 1 |
| 1 | 705001541 | LH Air Duct C/U | 1 |
| 1 | 705001543 | RH Air Duct C/U | 1 |
| 1 | 705003899 | PEARL WHITE REAR FENDER White EUR | 1 |
| 1 | 705003899 | PEARL WHITE REAR FENDER White AUS | 1 |
| 1 | 705003900 | Pearl White Rear Fender White C/U | 1 |
| 1 | 705006625 | FENDER REAR B-342 Black Current Met EUR | 1 |
| 705006627 | BLACK CURRENT REAR FENDER Black Current Met C/U | ||
| 1 | 705006086 | Rear Fender Support | 1 |
| 1 | 705002223 | Lug | 1 |
| 1 | 705005904 | Latch | 1 |
| 705002367 | LICENCE PLATE SUPPORT Europe | ||
| 705007018 | BACKUP LIGHT BRACKET RS Australie | ||
| 710003509 | License Plate Light RS Australie | ||
| 2 | 233251494 | Elastic Flange Nut M5 RS Australie | 2 |
| 705002367 | LICENCE PLATE SUPPORT RS Australie | ||
| 2 | 250000652 | Socket Screw M5 X .80 X 16 RS Australie | 2 |
| 2 | 234051670 | Flat Washer M5 RS Australie | 2 |
| 1 | 710003319 | REVERSE LIGHT RS Australie | 1 |
| 2 | 250000575 | Torx-Truss M4 X 16 RS Australie | 2 |
| 2 | 234041480 | Flat Washer 4 mm RS Australie | 2 |
| 2 | 232541484 | Elastic Stop Nut M4 RS Australie | 2 |
| 1 | 705004796 | BLACK LH HEADLAMP SUPPORT BRE | 1 |
| 1 | 705004796 | BLACK LH HEADLAMP SUPPORT AUS | 1 |
| 1 | 705004796 | BLACK LH HEADLAMP SUPPORT EUR | 1 |
| 1 | 705004797 | BLACK RH HEADLAMP SUPPORT BRE | 1 |
| 1 | 705004797 | BLACK RH HEADLAMP SUPPORT EUR | 1 |
| 1 | 705004797 | BLACK RH HEADLAMP SUPPORT AUS | 1 |
| 1 | 705003900 | Pearl White Rear Fender TLTD White Europe | 1 |
| 705006627 | BLACK CURRENT REAR FENDER TLTD Black Europe | ||
| 1 | 705002837 | Skid Plate | 1 |
| 1 | 705003207 | Plastic Washer TLTD | 1 |
| 1 | 705003911 | Spring | 1 |
| 2 | 705004606 | Fuse Cover Ass'y | 2 |
| 1 | 705004628 | Battery Cover Ass'Y | 1 |
| 1 | 705007172 | Storage Bin Ass'y | 1 |
| 705006619 | LH FRONT PANNEL, CASSIS Black Current Met | ||
| 705006882 | PANEL_BODY FL B-313 White | ||
| 1 | 705006620 | RH FRONT PANNEL, CASSIS Black Current Met | 1 |
| 1 | 705006883 | RH FRONT PANNEL, VEGAS WHITE White | 1 |
| 705006605 | PANEL_BODY LWR F B-342 Black Current Met | ||
| 1 | 705006873 | Vegas White Bumper Cover White | 1 |
| 1 | 705006226 | Hood, White White | 1 |
| 1 | 705006608 | Hood, Cassis Black Current Met | 1 |
| 708300624 | Front Liner Bag TLTD |
