Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 293150089 | Tuflok Plastic Rivet | 1 |
| 2 | 207584034 | Hex. Flange Screw, Scotch Grip | 2 |
| 2 | 207662044 | Hex. Flange Screw M6 X 20 | 2 |
| 1 | 210261280 | Hex. Flange Screw M6 X 12 | 1 |
| 4 | 210261680 | Hex. Flange Screw M6 X 16 | 4 |
| 2 | 232361600 | Nut M6 | 2 |
| 6 | 233261494 | Hex. Flange Elastic Nut M6 | 6 |
| 3 | 234062670 | Stainless Steel Flat Washer | 3 |
| 3 | 250000350 | Torx Truss Screw M6 X 20 | 3 |
| 2 | 250000454 | Torx Screw M6 X 12 | 2 |
| 1 | 250000350 | Torx Truss Screw M6 X 20 | 1 |
| 1 | 250100069 | Panel Nut M8 X 1.25 | 1 |
| 1 | 250100113 | Panel Nut, M6 X 1.0 | 1 |
| 1 | 219704364 | Neoprene Seal (1PAC=3M) | 1 |
| 1 | 414745900 | Tuflock Phillips Plastic Screw TLTD | 1 |
| 250200133 | RUBBER WASHER TLTD | ||
| 1 | 517302785 | Edge Clip | 1 |
| 1 | 518325518 | RH Upper Side Panel Foam | 1 |
| 518327438 | RH LATERAL PANEL FOAM | ||
| 1 | 518327441 | Lateral Console Foam | 1 |
| 2 | 518327579 | LATERAL CONSOLE FOAM TLTD | 2 |
| 1 | 518327600 | LH UPPER PANEL FOAM | 1 |
| 705006259 | LH UPPER SIDE PANEL, WHITE White | ||
| 1 | 705006647 | LH UPPER SIDE PANEL, CASSIS Black Current Met | 1 |
| 705006254 | RH UPPER SIDE PANEL, WHITE White | ||
| 705006646 | RH UPPER SIDE PANEL, CASSIS Black Current Met | ||
| 705004002 | LH REAR GRILL TLTD | ||
| 1 | 705004003 | RH Rear Grille TLTD | 1 |
| 1 | 705006084 | LH Rear Fender Support | 1 |
| 705006085 | RH REAR FENDER SUPPORT | ||
| 1 | 705007213 | UPPER BELT GUARD TLTD | 1 |
| 705003894 | PEARL WHITE REAR TIP White | ||
| 705006649 | REAR TIP, CASSIS Black Current Met | ||
| 1 | 705002092 | Lower Belt Guard | 1 |
| 1 | 705002369 | LH LATERAL GRILL | 1 |
| 1 | 705002508 | LH Heat Reflective Sheet | 1 |
| 705002509 | BLACK RH REAR PANEL FOAM | ||
| 4 | 219704364 | Neoprene Seal (1PAC=3M) | 4 |
| 3 | 705002649 | Quarter Turn Screw | 3 |
| 6 | 705002650 | Washer | 6 |
| 3 | 705002651 | Quarter Turn Nut | 3 |
| 1 | 705002980 | LH REINFORCEMENT PLATE | 1 |
| 1 | 705002981 | RH Reinforcement Plate | 1 |
| 1 | 705003207 | Plastic Washer | 1 |
| 1 | 705006241 | PANEL_BODY RH B-313 White | 1 |
| 705006629 | Black Current RH Side Panel Black Current Met | ||
| 1 | 705006249 | PANEL_BODY LH B-313 White | 1 |
| 1 | 705006631 | BLACK CURRENT LH SIDE PANEL Black Current Met | 1 |
| 1 | 705006639 | Black Current LH Rear Panel Black Current Met | 1 |
| 1 | 705007012 | White LH Rear Panel White | 1 |
| 705004636 | LH RADIATOR MOULDING | ||
| 2 | 705004838 | Flat Clip | 2 |
| 705005261 | RH RADIATOR MOULDING | ||
| 705005262 | LH RADIATOR GRILL | ||
| 705005263 | RH RADIATOR GRILL | ||
| 705006864 | RH REAR PANEL, CASSIS Black Current Met | ||
| 1 | 705006865 | RH Rear Panel, White White | 1 |
| 1 | 705005409 | LH Tank Cover | 1 |
| 1 | 705005410 | RH TANK COVER | 1 |
| 1 | 705005413 | LH DEFLECTOR PANNEL TLTD | 1 |
| 1 | 705005414 | RH Deflector Pannel | 1 |
| 1 | 705005429 | Passenger Handle | 1 |
| 1 | 705005447 | LH Skid Plate | 1 |
| 1 | 705005462 | HEAT DEFLECTOR | 1 |
| 1 | 705006070 | RH REAR FENDER REINFORCEMENT | 1 |
| 1 | 705006136 | LH REAR FENDER REINFORCEMENT | 1 |
| 1 | 705006531 | UPPER HEAT SEAL TLTD | 1 |
| 1 | 705006532 | LOWER HEAT SEAT TLTD | 1 |
| 705006688 | RH INNER HEAT SHIELD | ||
| 1 | 705006829 | UNDER TAIL COVER | 1 |
| 1 | 705006981 | LH INNER HEAT DEFLECTOR TLTD | 1 |
| 1 | 705007053 | Heat Shield Rocker Panel | 1 |
| 1 | 708000759 | Rubber Stopper | 1 |
| 2 | 250000488 | Torx Truss Screw M6 X 20 | 2 |
