Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 706200744 | RH Lower Suspension Arm | 1 |
| 2 | 706200796 | Suspension Upper Arm | 2 |
| 8 | 706202088 | Cushion | 8 |
| 4 | 703500875 | Suspension Arm Bushing Kit | 4 |
| 2 | 706202445 | Bushing | 2 |
| 4 | 706201062 | Cushion | 4 |
| 4 | 706201063 | Wear Plate | 4 |
| 4 | 207607046 | Hex. Flange Screw M10 X 70 | 4 |
| 2 | 706202044 | Ball Joint | 2 |
| 6 | 233201416 | Hex. Flange Elastic Nut M10 | 6 |
| 2 | 250000510 | Hex. Cap Screw M10 X 225 | 2 |
| 4 | 503190439 | Washer | 4 |
| 1 | 706200742 | LH Lower Suspension Arm | 1 |
| 2 | 706202045 | Ball Joint | 2 |
| 6 | 408200700 | Grease Fitting | 6 |
| 1 | 706200782 | Front Shock Package XTP | 1 |
| 1 | 706200782 | Front Shock Package DPS, Hunter | 1 |
| 1 | 706200780 | Front Shock Package STD | 1 |
| 2 | 715900122 | Bushing | 2 |
| 1 | 706201758 | Front Shock Commander MAX Package XT | 1 |
| 1 | 706202738 | Front Shock Package XTP | 1 |
| 1 | 706201758 | Front Shock Commander MAX Package DPS | 1 |
| 1 | 706201369 | BLACK FRONT SPRING Package Hunter | 1 |
| 1 | 706202774 | Black, Front Spring Commander MAX Package XT | 1 |
| 1 | 706201369 | BLACK FRONT SPRING Package XT | 1 |
| 1 | 706201367 | RED FRONT SPRING Package DPS | 1 |
| 1 | 706201631 | RED FRONT SPRING Package STD | 1 |
| 1 | 706201367 | RED FRONT SPRING Package XT | 1 |
| 1 | 706201617 | Black, Front Spring Package XTP | 1 |
| 706202615 | VIPER RED FRONT SPRING Commander MAX Package DPS | ||
| 706202615 | VIPER RED FRONT SPRING Commander MAX Package XT | ||
| 1 | 706200860 | YELLOW FRONT SPRING Package XT | 1 |
| 1 | 706000910 | Adjustment Ring Except Package XTP | 1 |
| 1 | 706000911 | Protector Ring Except Package XTP | 1 |
| 1 | 706000567 | Spring Stopper Except Package XTP | 1 |
| 1 | 706201670 | RH Protector | 1 |
| 1 | 706201669 | LH Protector | 1 |
| 6 | 293150104 | Pop Rivet 3/16" | 6 |
| 4 | 293370035 | Circlip | 4 |
| 2 | 250100099 | Nut M12 | 2 |
| 2 | 250200086 | Flat Washer | 2 |
| 2 | 211400017 | Cotter Pin | 2 |
| 2 | 207605044 | Hex. Flange Screw M10 X 50 | 2 |
| 2 | 233201414 | Hex. Flange Elastic Nut M10 | 2 |
| 1 | 706202560 | Sway Bar Ass'y Except Europe | 1 |
| 1 | 706202536 | LH Sway Bar Link Except Europe | 1 |
| 1 | 706202537 | RH Sway Bar Link Except Europe | 1 |
| 2 | 706201086 | Stabilizer Bushing Except Europe | 2 |
| 2 | 706201087 | Clamp Except Europe | 2 |
| 2 | 506060600 | U-clamp Except Europe | 2 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 Except Europe | 4 |
| 4 | 233201416 | Hex. Flange Elastic Nut M10 Except Europe | 4 |
| 4 | 207605587 | SCREW-HEX.FLANGE DIN.6921 | 4 |
| 4 | 233201416 | Hex. Flange Elastic Nut M10 | 4 |
