Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 11061-0077 | GASKET | 1 |
| 1 | 13168-0051 | LEVER | 1 |
| 1 | 13271-0241 | PLATE | 1 |
| 1 | 14024-1971 | COVER | 1 |
| 1 | 14091-0209 | COVER | 1 |
| 1 | 14091-0587 | COVER,TOP | 1 |
| 1 | 14091-0588 | COVER | 1 |
| 1 | 15004-0011 | CARBURETOR-ASSY,FCR-M | 1 |
| 1 | 16012-0002 | CAP-STARTER PLUNGER | 1 |
| 1 | 16014-0004 | SCREW-PILOT AIR | 1 |
| 1 | 16016-0009 | PLUNGER | 1 |
| 1 | 16016-0017 | PLUNGER | 1 |
| 1 | 16021-0013 | SCREW-THROTTLE STOP | 1 |
| 1 | 16025-0009 | VALVE-THROTTLE | 1 |
| 1 | 16025-0013 | VALVE-THROTTLE | 1 |
| 1 | 16030-1057 | VALVE-FLOAT | 1 |
| 1 | 16031-1100 | FLOAT | 1 |
| 1 | 16039-0230 | WASHER | 1 |
| 1 | 16041-0004 | SHAFT-CARBURETOR | 1 |
| 1 | 16044-007 | CLAMP,FLOAT VALVE | 1 |
| 1 | 16049-1051 | COVER-MAIN JET | 1 |
| 1 | 16157-0003 | JET-STARTER | 1 |
| 1 | 16159-0004 | JET-POWER | 1 |
| 1 | 16170-0003 | LINK-ASSY | 1 |
| 1 | 16187-0188 | NEEDLE-JET,NCYP (OPTION) | 1 |
| 1 | 16187-0189 | NEEDLE-JET,NCYQ (OPTION) | 1 |
| 1 | 16187-0190 | NEEDLE-JET (OPTION) | 1 |
| 1 | 16187-0191 | NEEDLE-JET,NCYS (OPTION) | 1 |
| 1 | 16187-0192 | NEEDLE-JET,NCYT (OPTION) | 1 |
| 1 | 16187-0212 | NEEDLE-JET,NCVP (OPTION) | 1 |
| 1 | 16187-0213 | NEEDLE-JET,NCVQ (OPTION) | 1 |
| 1 | 16187-0214 | NEEDLE-JET,NCVR | 1 |
| 1 | 16187-0215 | NEEDLE-JET,NCVS (OPTION) | 1 |
| 1 | 16187-0216 | NEEDLE-JET,NCVT (OPTION) | 1 |
| 1 | 21083-0035 | ARM | 1 |
| 1 | 21176-0016 | SENSOR | 1 |
| 1 | 43028-0006 | DIAPHRAGM | 1 |
| 1 | 46102-0033 | ROD | 1 |
| 1 | 49121-0001 | NOZZLE-MAIN | 1 |
| 1 | 92005-0016 | FITTING | 1 |
| 1 | 92009-1551 | SCREW,DRAIN,6X0.75 | 1 |
| 1 | 92009-1876 | SCREW | 1 |
| 1 | 92009-1981 | SCREW,THROTTLE SENSOR | 1 |
| 1 | 92033-0018 | RING-SNAP | 1 |
| 5 | 92037-1396 | CLAMP,TUBE | 5 |
| 1 | 92055-0066 | RING-O | 1 |
| 1 | 92055-0109 | RING-O | 1 |
| 1 | 92055-1004 | RING-O | 1 |
| 1 | 92055-1167 | RING-O,MAIN JET COVER | 1 |
| 3 | 92055-1223 | RING-O | 3 |
| 1 | 92055-1671 | RING-O | 1 |
| 92063-1370 | JET-MAIN,#165 (OPTION) | ||
| 1 | 92063-1371 | JET-MAIN (OPTION) | 1 |
| 92063-1372 | JET-MAIN (OPTION) | ||
| 1 | 92063-1373 | JET-MAIN,#172 (OPTION) | 1 |
| 92063-1374 | JET-MAIN | ||
| 1 | 92063-1375 | JET-MAIN,#178 (OPTION) | 1 |
| 1 | 92063-1376 | JET-MAIN,#180 (OPTION) | 1 |
| 1 | 92063-1377 | JET-MAIN,#182 (OPTION) | 1 |
| 1 | 92063-1378 | JET-MAIN (OPTION) | 1 |
| 1 | 92064-1139 | JET-PILOT,#38 (OPTION) | 1 |
| 1 | 92064-1140 | JET-PILOT,#40 (OPTION) | 1 |
| 1 | 92064-1141 | JET-PILOT,#42 | 1 |
| 3 | 220D0408 | SCREW-PAN-CROS | 3 |
| 4 | 220D0414 | SCREW-PAN-CROS | 4 |
| 1 | 92064-1142 | JET-PILOT,#45 (OPTION) | 1 |
| 1 | 92064-1143 | JET-PILOT,#48 (OPTION) | 1 |
| 1 | 92064-1160 | JET-PILOT,#100 | 1 |
| 1 | 92081-1092 | SPRING,DIAPHRAGM | 1 |
| 1 | 92081-1620 | SPRING | 1 |
| 1 | 92093-1046 | SEAL,U-RING | 1 |
| 1 | 92145-0164 | SPRING | 1 |
| 1 | 92145-0166 | SPRING | 1 |
| 1 | 92145-0167 | SPRING | 1 |
| 2 | 92150-1426 | BOLT,SOCKET,4X12 | 2 |
| 1 | 92152-0141 | COLLAR | 1 |
| 1 | 92153-0639 | BOLT | 1 |
| 1 | 92153-1512 | BOLT | 1 |
| 1 | 92170-1204 | CLAMP,JET NEEDLE | 1 |
| 2 | 92170-1582 | CLAMP | 2 |
| 2 | 92171-0149 | CLAMP | 2 |
| 1 | 92171-0246 | CLAMP | 1 |
| 1 | 92172-0127 | SCREW | 1 |
| 1 | 92172-0128 | SCREW | 1 |
| 1 | 92172-0129 | SCREW | 1 |
| 2 | 92192-0083 | TUBE | 2 |
| 2 | 92192-0084 | TUBE | 2 |
| 1 | 92192-0085 | TUBE | 1 |
| 1 | 92192-0219 | TUBE,7X12X270,PROTECT | 1 |
| 1 | 92200-0107 | WASHER | 1 |
| 1 | 92200-1434 | WASHER,LINK ARM,STAIN | 1 |
