Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 715008984 | Interior Open Carrier Kit Includes 10 to 10a2 | 1 |
| 1 | 715007479 | Cargo Box Inside Ass'y | 1 |
| 1 | 704909634 | Tire Pressure Warning Label | 1 |
| 1 | 708303499 | LH Cargo Panel | 1 |
| 20 | 250000980 | Hex. Screw Pt K60 X 25 | 20 |
| 20 | 250200162 | Flat Washer M6.6 X 22 | 20 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 1 | 250000867 | Torx Truss Hex. Screw M6X35, Nylon Patch | 1 |
| 1 | 293900101 | Bushing | 1 |
| 1 | 250200162 | Flat Washer M6.6 X 22 | 1 |
| 1 | 708304595 | LH Panel Support Includes 100b9 to 100b9a7 | 1 |
| 6 | 390402000 | Pop Rivet 3/16" | 6 |
| 1 | 708303500 | RH Cargo Panel | 1 |
| 1 | 708304596 | RH Panel Support Includes 100c9 to 100c9a7 | 1 |
| 1 | 708303501 | Tailgate Ass'y | 1 |
| 10 | 250000980 | Hex. Screw Pt K60 X 25 | 10 |
| 10 | 250200162 | Flat Washer M6.6 X 22 | 10 |
| 708304597 | LH Tailgate Support | ||
| 4 | 207662554 | Hex. Flange Screw M6 X 25 | 4 |
| 2 | 207663554 | Hex. Flange Screw M6 X 35 | 2 |
| 6 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 6 |
| 8 | 250200162 | Flat Washer M6.6 X 22 | 8 |
| 2 | 293900101 | Bushing | 2 |
| 1 | 708304598 | RH Tailgate Support | 1 |
| 2 | 708302893 | Cable Retaining | 2 |
| 12 | 293150108 | Pop Rivet 3/16” | 12 |
| 5 | 250000722 | Torx Screw M6 X 20 | 5 |
| 17 | 250200162 | Flat Washer M6.6 X 22 | 17 |
| 1 | 708303264 | LH Rear Reflector | 1 |
| 1 | 708303265 | RH Rear Reflector | 1 |
| 1 | 708303216 | Deflector | 1 |
| 6 | 293150108 | Pop Rivet 3/16” | 6 |
| 6 | 517124300 | Washer | 6 |
| 1 | 708303496 | Taillight Support | 1 |
| 2 | 250000760 | Torx Screw Truss Head K50X20 T20 | 2 |
| 6 | 293150292 | Black, Pop Rivet 3/16 X ,550 | 6 |
| 2 | 705016982 | Red, Reflector | 2 |
| 2 | 232551414 | Elastic Stop Nut M5 | 2 |
| 1 | 715008399 | Open Carrier Frame Kit | 1 |
| 4 | 207587044 | Hex. Flange Screw M8 X 70 | 4 |
| 4 | 250200187 | Flat Washer M8 | 4 |
| 5 | 250100199 | Insert Half Hex Body M6 x 1.0 | 5 |
| 8 | 250100199 | Insert Half Hex Body M6 x 1.0 | 8 |
| 2 | 250300645 | Protruding Stud M8 X 28 | 2 |
| 2 | 207682544 | Hex. Flange Screw M8 X 25 | 2 |
| 2 | 708304601 | Rubber Stopper | 2 |
| 2 | 293150292 | Black, Pop Rivet 3/16 X ,550 | 2 |
| 1 | 708303709 | Front Square Tube | 1 |
| 3 | 207682046 | Hex. Flange Screw M8 X 20 | 3 |
| 3 | 233281416 | Hex. Elastic Flange Nut M8 | 3 |
| 9 | 250100199 | Insert Half Hex Body M6 x 1.0 | 9 |
| 2 | 708304601 | Rubber Stopper Includes 540 to 540a | 2 |
| 1 | 224060251 | Washer | 1 |
| 1 | 708304411 | LH Stopper | 1 |
| 4 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 4 |
| 1 | 708304412 | RH Stopper | 1 |
| 2 | 708301480 | Retaining Plate | 2 |
| 4 | 207662054 | Hex. Flange Screw M6 X 20 | 4 |
| 8 | 250001107 | Torx Flat Head Screw T-30 S.Grip M6X25 | 8 |
| 4 | 708302990 | D-Ring | 4 |
| 4 | 708302991 | Tie-Down Ring Spring | 4 |
| 4 | 708302992 | Tie-Down Ring Bracket | 4 |
| 2 | 511001014 | Latch Ass'y | 2 |
| 4 | 250000901 | Torx Truss M8 X 65 | 4 |
| 4 | 233281464 | Elastic Flange Nut M8 | 4 |
| 4 | 234082670 | Stainless Steel Flat Washer | 4 |
| 2 | 708304581 | Female Hinge | 2 |
| 4 | 234082410 | Flat Washer 8 mm | 4 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 2 | 293300131 | O-Ring | 2 |
| 2 | 708303361 | Hinge Bushing | 2 |
| 1 | 715007096 | Actuator Open Carrier Kit | 1 |
| 4 | 250000906 | Hex Flange Screw M6 X 16 | 4 |
| 2 | 250400096 | Pin Clevis | 2 |
| 2 | 414575600 | Hair Pin | 2 |
| 1 | 707900889 | Heat Shield | 1 |
