Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 417223867 | Fixe Flange Ass'y | 1 |
| 1 | 417223763 | Slider Flange Ass'y | 1 |
| 1 | 417222758 | Bushing | 1 |
| 1 | 293370037 | Circlip | 1 |
| 6 | 417223679 | Rampe 735 Includes 5-6 | 6 |
| XXX | Not Available As Spare Parts Included In Ramp Kit | ||
| 12 | 417223660 | Stopper Washer | 12 |
| 6 | 417223694 | Ramp Axle | 6 |
| 6 | 232551414 | Elastic Stop Nut M5 | 6 |
| 1 | 417223650 | Spring Cover Ass'y | 1 |
| 1 | 293370065 | Circlip | 1 |
| 1 | 417223752 | Seat Spring | 1 |
| 1 | 417223751 | Clutch Spring, Yellow/Red | 1 |
| 6 | 250000580 | Torx Screw M6 X 30 | 6 |
| 1 | 417223790 | Governor Cup Ass'y | 1 |
| 6 | 417223767 | Roller | 6 |
| 6 | 417223257 | Roller Axle | 6 |
| 3 | 293300169 | O Ring | 3 |
| 12 | 417223269 | Slider Shoe | 12 |
| 1 | 417300432 | Pulley Drive Bolt | 1 |
| 1 | 250200114 | Sealing Washer | 1 |
| 1 | 516005503 | Decal English | 1 |
| 417127423 | FIXED FLANGE ASS'Y | ||
| 2 | 417127189 | Roller | 2 |
| 2 | 417127294 | Pivot Stud | 2 |
| 2 | 250200009 | Lock Washer 8 mm | 2 |
| XXXX | Not Available As Spare Part - Circlip | ||
| 1 | 417127412 | Cam Ass'y | 1 |
| 1 | 293370049 | Circlip | 1 |
| 1 | 417127317 | Sliding Flange Ass'y | 1 |
| 2 | 417127000 | Bushing | 2 |
| 4 | 250000283 | Torx Screw M8 X 25, Scotch Grip | 4 |
| 1 | 415129604 | Calibration Ass'y | 1 |
| 1 | 205052544 | Socket Screw M5 X 25 | 1 |
| 1 | 234051410 | Flat Washer M5 | 1 |
| 1 | 232551414 | Elastic Stop Nut M5 | 1 |
| 1 | 417127155 | Washer | 1 |
| 1 | 504152574 | Ball Bearing | 1 |
| 1 | 413703100 | Loctite 609, 10 ml | 1 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 1 | 417300391 | Belt | 1 |
| 417300419 | RETAINER RING | ||
| 417127203 | SOCKET SET SCREW M6X6 DIN 916 | ||
| 1 | 417300382 | Belt Guard | 1 |
| 516004649 | Security label, Belt Guard | ||
| 1 | 417300380 | Reinforcement | 1 |
| 3 | 390909200 | Avex Rivet | 3 |
| 1 | 417300381 | Guide | 1 |
| 1 | 417300356 | Side Protector | 1 |
| 5 | 293150103 | Pop Rivet 3/16" | 5 |
| 1 | 417300373 | Belt Guard Bracket | 1 |
| 8 | 293150104 | Pop Rivet 3/16" | 8 |
| 1 | 114045200 | Hair Pin | 1 |
| 1 | 417300396 | BELT GUARD BRACKET | 1 |
| 2 | 241151640 | Hex. Flange Screw K50 X 2.24 X 16 | 2 |
| 1 | 518325626 | Brake Hose Cover | 1 |
| 1 | 417300363 | Belt Guard Bracket | 1 |
| 2 | 293150163 | Rivet Hucklok | 2 |
| 1 | 504153054 | Protective Rubber | 1 |
| 518326566 | PULLEY COVER PLATE | ||
| 1 | 516003919 | Warning Decal Europe | 1 |
| 2 | 516004651 | Caution Label, Air Intake | 2 |
| 1 | 417127427 | RELEASE SPRING | 1 |
| 2 | 250400061 | Spring Pin M3 X 18 | 2 |
