Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 518327675 | Frame XU 4-TEC SC-5 Model-EUROPE | ||
| 518327673 | FRAME XU 4-TEC SC-5, BLACK | ||
| 1 | 518326720 | E Module | 1 |
| 1 | 518326198 | Front Member | 1 |
| 1 | 390909100 | Avex Rivet | 1 |
| 1 | 293150120 | Hemlock Rivet 6.5 mm | 1 |
| 1 | 293150119 | Hemlock Rivet, 6.5 mm | 1 |
| 2 | 505072690 | Leg Bushing | 2 |
| 1 | 518326328 | RH Side Member | 1 |
| 1 | 518326330 | LH Side Member | 1 |
| 518325987 | Seat Box Bracket | ||
| 1 | 518326109 | SUPPORT TUBE BRACKET LH | 1 |
| 1 | 518326110 | SUPPORT TUBE BRACKET RH | 1 |
| 1 | 518325524 | LH Frame Corner | 1 |
| 518325526 | FRAME CORNER RH | ||
| 1 | 509000867 | Tunnel Radiator | 1 |
| 1 | 207662044 | Hex. Flange Screw M6 X 20 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 1 | 518325371 | MAG Engine Support | 1 |
| 1 | 518326963 | LH Footboard Support Tube | 1 |
| 1 | 518326964 | RH Footboard Support Tube | 1 |
| 207662086 | SCREW-HEX.FLANGE DIN.6921 | ||
| 2 | 520000492 | Footrest Model-EUROPE | 2 |
| 2 | 520001208 | Black Rear Footrest | 2 |
| 1 | 518326464 | TOE HOOK LH Model-EUROPE | 1 |
| 1 | 518327375 | TOE HOLD L.H. | 1 |
| 518326465 | TOE HOOK RH Model-EUROPE | ||
| 1 | 518327376 | Black RH Toe Hook | 1 |
| 4 | 390909200 | Avex Rivet | 4 |
| 1 | 514054616 | SPRING BRACKET | 1 |
| 1 | 518327546 | S Module Model-EUROPE | 1 |
| 1 | 518327157 | MODULE S DRILLED | 1 |
| 1 | 518327475 | Front Suspension Support | 1 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 210262080 | Hex. Forming Screw M6 X 20 | 2 |
| 2 | 250000522 | Hex Flange Screw M6 x 25 | 2 |
| 518327644 | PULLEY SUPPORT | ||
| 2 | 207582586 | Hex. Flange Screw M8 X 25, Scotch Grip | 2 |
| 1 | 605355235 | FASTENING BRACKET | 1 |
| 1 | 293150163 | Rivet Hucklok | 1 |
| 1 | 293150144 | Stavex Rivet | 1 |
| 1 | 518326970 | Front Member | 1 |
| 518326103 | UPPER SUPPORT TUBE WELDED | ||
| XXXX | Not Available As Spare Part - Lock washer D6 | ||
| 2 | 518325114 | Upper Lateral Column Support | 2 |
| 1 | 518326657 | Center Column Support | 1 |
| 2 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 2 |
| 1 | 293150147 | Hemlock Rivet | 1 |
| 1 | 518327392 | Brace Ass'y | 1 |
| 1 | 518325560 | Adhesive Patch | 1 |
| 1 | 414644300 | Black, Dart | 1 |
| 1 | 293730042 | Full Moon Dart 5 mm | 1 |
| 1 | 518327194 | Rear Profile | 1 |
| 6 | 250000376 | Hex Forming Screw DIN.7500D | 6 |
| 1 | 293150174 | Hemlock Rivet, 6.4 mm | 1 |
| 1 | 36087 | Rivet | 1 |
| 1 | 293150104 | Pop Rivet 3/16" | 1 |
| 1 | 390909200 | Avex Rivet | 1 |
| 2 | 512060295 | Rubber Mount | 2 |
| XXXX | Not Available As Spare Part - Drive Axle Cover Black LH | ||
| XXXX | Not Available As Spare Part - Drive Axle Cover Black RH | ||
| 1 | 518325626 | Brake Hose Cover | 1 |
| 1 | 518326430 | Clinch Nut plate | 1 |
| XXXX | Not Available As Spare Part - Rivet | ||
| 1 | 518326566 | PULLEY COVER PLATE | 1 |
| 1 | 515177073 | FUSEBOX SUPPORT | 1 |
| 518326123 | GEARBOX FRONT PLATE | ||
| 1 | 518326124 | Gearbox Rear Plate | 1 |
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 1 | 207583586 | Hex. Flange Screw M8 X 35, Scotch Grip Sub 250000986 | 1 |
| 1 | 518327448 | Muffler Support | 1 |
| 1 | 293150183 | Rivet | 1 |
| 518326895 | FOOTREST LH | ||
| 518326896 | FOOTREST RH |
