Каталог / Side x Side / Can-Am / 2017 / MAVERICK X3 / Front Suspension

Список запчастей

№	Артикул	Название	Кол-во
1	706202700	Black LH Upper Arm Model X3	1
1	706202701	Black RH Upper Arm Model X3	1
1	706202700	Black LH Upper Arm Model X3 Xds	1
1	706202701	Black RH Upper Arm Model X3 Xds	1
1	706203076	Black Upper Suspension Arm LH Model X3 Xrs Black	1
1	706203077	Black Upper Suspension Arm RH Model X3 Xrs Black	1
1	706203074	Red Upper Suspension Arm LH Model X3 Xrs Gold	1
1	706203075	Red Upper Suspension Arm RH Model X3 Xrs Gold	1
16	706201659	Cushion	16
8	706202257	Interior Bushing	8
8	706202300	Wear Plate	8
8	293550056	Grease Fitting 90°	8
1	706202919	Deep Black, LH Lower Arm Model X3	1
1	706202920	Deep Black, RH Lower Arm Model X3	1
1	706202919	Deep Black, LH Lower Arm Model X3 Xds	1
1	706202920	Deep Black, RH Lower Arm Model X3 Xds	1
1	706202706	Black, LH Lower Arm Model X3 Xrs	1
1	706202707	Black, RH Lower Arm Model X3 Xrs	1
4	250000859	Flange Screw M12 X 85	4
4	250000861	Flange Screw M12 X 145	4
8	233221466	Elastic Flange Nut M12	8
2	706202801	Upper Ball Joint	2
2	706202045	Ball Joint	2
2	250000857	Flange Screw M12 X 60	2
4	233221466	Elastic Flange Nut M12	4
1	706202695	FRONT SHOCK Model X3	1
1	706202699	FRONT SHOCK Model X3	1
1	706202095	LH FRONT SHOCK Model X3 Xds	1
1	706202269	RH FRONT SHOCK Model X3 Xds	1
1	706202856	LH Front Shock Model X3 Xrs Black	1
1	706202857	RH Front Shock Model X3 Xrs Black	1
1	706202380	LH Front Shock Model X3 Xrs Gold	1
1	706202383	FRONT SHOCK Model X3 Xrs Gold	1
4	715900337	Spherical Bearing	4
8	715900338	O-Ring Bushing	8
8	715900480	Circlip	8
4	715900481	Reducer Model X3 Xrs	4
	715900420	Interior bushing Model X3 Xds
2	715900482	Bearing Model X3 Xrs	2
8	715900481	Reducer Model X3	8
2	706203032	Black Front Spring Model X3	2
2	706203032	Black Front Spring Model X3 Xds	2
2	706203056	SPRING Model X3 Xrs Black	2
2	706203033	Front Spring Model X3 Xrs Gold	2
2	706202180	Black, Front Spring Model X3	2
2	706202180	Black, Front Spring Model X3 Xds	2
2	706202696	Black, Front Spring Model X3 Xrs Black	2
2	706202381	Red, Front Spring Model X3 Xrs Gold	2
1	706202759	LH Knuckle	1
1	706202760	RH Knuckle	1
2	706202502	Wear Plate	2
4	293370035	Circlip	4
2	250100099	Nut M12	2
2	250200086	Flat Washer	2
2	211400017	Cotter Pin	2
2	207605044	Hex. Flange Screw M10 X 50	2
2	233201436	Hex. Flange Elastic Nut M10	2
1	706202454	Sway Bar	1
1	706202764	Link Stabilizer Bar LH	1
1	706202765	Link Stabilizer Bar RH	1
2	706202849	Bushing	2
2	293550056	Grease Fitting 90°	2
2	706202460	Clamp	2
2	706202551	Support Plate	2
4	250000876	Hex. Flange Screw M12 X 95	4
4	233201436	Hex. Flange Elastic Nut M10	4
4	234201474	Conical Spring Washer 10 mm	4
1	706202708	Black, Link Model X3	1
1	706202708	Black, Link Model X3 Xds	1
1	706202708	Black, Link Model X3 Xrs Black	1
1	706202709	Red Link Model X3 Xrs Gold	1
