Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 715004061 | Black Frame Kit Except Model Gold Built in 2016 | ||
| 715004465 | Black Frame Kit Except Model Gold Built in 2017 | ||
| 715004190 | Red Frame Kit Model Gold Built in 2016 | ||
| 715004466 | Red Frame Kit Model Gold Built in 2017 | ||
| 715004060 | Black Cage Kit Except Model Gold Built in 2016 | ||
| 715004463 | Front Black Cage Kit Except Model Gold Built in 2017 | ||
| 715004189 | Red Cage Kit Model Gold Built in 2016 | ||
| 715004464 | Front Red Cage Kit Model Gold Built in 2017 | ||
| 2 | 250000720 | Torx Screw K50 X 16 | 2 |
| 16 | 207523036 | Hex. Flange Screw S.Grip M12 X 30 | 16 |
| 16 | 233221414 | Hex. Flange Elastic Nut M12 | 16 |
| 1 | 705205897 | Front Plate | 1 |
| 2 | 207561044 | Flange Screw M6 X 10, Scotch Grip | 2 |
| 1 | 706200308 | Plug 1-1/4" | 1 |
| 1 | 705205746 | Black, Front Bumper Except Model Gold | 1 |
| 1 | 705205747 | PAINTED FRONT BUMPER Model Gold | 1 |
| 705205748 | PAINTED ADDED CAGE Except Model Gold Built in 2016 | ||
| 1 | 705206774 | Added Cage Except Model Gold Built in 2017 | 1 |
| 1 | 705205749 | Red Cage Insert Model Gold Built in 2016 | 1 |
| 1 | 705206771 | Painted Added Cage Model Gold Built in 2017 | 1 |
| 8 | 233221466 | Elastic Flange Nut M12 | 8 |
| 705205476 | PLAQUE | ||
| 2 | 207581244 | Hex. Flange Screw M8 X 12, Scotch Grip | 2 |
| 2 | 233281416 | Hex. Elastic Flange Nut M8 | 2 |
| 1 | 705206066 | Rear Upper Plate | 1 |
| 1 | 705205564 | Stifner Plate | 1 |
| 1 | 207661654 | Hex. Flange Screw M6 X 16 | 1 |
| 1 | 233261494 | Hex. Elastic Flange Nut M6 | 1 |
| 1 | 705206070 | Rear Mid Plate | 1 |
| 1 | 705206073 | Rear Lower Plate | 1 |
| 2 | 705205926 | Black, LH Link Plate Except Model Gold | 2 |
| 2 | 705205929 | PLATE_CONNECTING B-101 PAINTED Model Gold | 2 |
| 4 | 390402000 | Pop Rivet 3/16" | 4 |
| 1 | 705205750 | Rear Plate | 1 |
| 2 | 705205751 | Black, Rear Mount Except Model Gold | 2 |
| 2 | 705205752 | Red- Rear Mount Model Gold | 2 |
| 4 | 250000901 | Torx Truss M8 X 65 | 4 |
| 4 | 250100025 | Elastic Flange Nut M8 | 4 |
| 4 | 705205634 | Sleeve | 4 |
| 1 | 705205268 | Belt Bar | 1 |
| 4 | 232521416 | Elastic Stop Nut M12 | 4 |
| 1 | 705205294 | Upper Link Arm | 1 |
| 3 | 705205295 | Lower Arm Link | 3 |
| 1 | 706202491 | Support | 1 |
| 2 | 390402000 | Pop Rivet 3/16" | 2 |
| 1 | 705206069 | Front Upper Plate | 1 |
| 1 | 705206511 | Rear Upper Plate Model XRSDPS | 1 |
