Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705011087 | Black, LH Front Fender Model Black | 1 |
| 1 | 705011091 | Black, RH Front Fender Model Black | 1 |
| 1 | 705011092 | Gold, LH Front Fender Model Gold | 1 |
| 1 | 705011093 | Gold, RH Front Fender Model Gold | 1 |
| 1 | 705009505 | White, LH Front Fender Model White | 1 |
| 1 | 705009506 | White, RH Front Fender Model White | 1 |
| 1 | 705011084 | YELLOW LH FRONT FENDER Model Yellow | 1 |
| 1 | 705011086 | YELLOW RH FRONT FENDER Model Yellow | 1 |
| 6 | 705010721 | Clip | 6 |
| 4 | 517302785 | Edge Clip | 4 |
| 4 | 705003841 | Support Plate | 4 |
| 4 | 250000048 | Panel Nut M6 X 1.0 | 4 |
| 705010671 | Central Hood | ||
| 4 | 705010718 | Grommet | 4 |
| 2 | 293150089 | Tuflok Plastic Rivet | 2 |
| 2 | 250000722 | Torx Screw M6 X 20 | 2 |
| 2 | 250000048 | Panel Nut M6 X 1.0 | 2 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 1 | 705009508 | Front Facia | 1 |
| 4 | 250000722 | Torx Screw M6 X 20 | 4 |
| 1 | 517303756 | Grommet | 1 |
| 2 | 520000271 | Amber, Reflector | 2 |
| 2 | 250000720 | Torx Screw K50 X 16 | 2 |
| 1 | 705011806 | LH Reflector Support | 1 |
| 1 | 705011814 | RH Reflector Support | 1 |
| 1 | 705010277 | White, Facia Cover Model White | 1 |
| 1 | 705011094 | YELLOW FACIA COVER Model Yellow | 1 |
| 1 | 705011095 | Black, Facia Cover Model Black | 1 |
| 1 | 705011097 | Gold, Facia cover Model Gold | 1 |
| 1 | 705010443 | Front Radiator Grille | 1 |
| 6 | 517302785 | Edge Clip | 6 |
| 1 | 705010885 | Logo Except Model X3 | 1 |
| 1 | 250000725 | Screw M4 X 16 Except Model X3 | 1 |
| 1 | 705009978 | Front Deflector | 1 |
| 4 | 293150103 | Pop Rivet 3/16" | 4 |
| 1 | 705010742 | Lower Radiator deflector | 1 |
| 1 | 705010626 | LH Radiator deflector | 1 |
| 1 | 705010627 | RH Radiator deflector | 1 |
| 2 | 517302785 | Edge Clip | 2 |
| 1 | 705010628 | LH Light Cover | 1 |
| 1 | 705010629 | RH Light Cover | 1 |
| 1 | 705011115 | Black, LH Door Panel Model Black | 1 |
| 1 | 705011116 | Black, RH Door Panel Model Black | 1 |
| 1 | 705011117 | Gold, LH Door Panel Model Gold | 1 |
| 1 | 705011118 | Gold, RH Door Panel Model Gold | 1 |
| 1 | 705010067 | White LH Door Panel Model White | 1 |
| 1 | 705010068 | White RH Door Panel Model White | 1 |
| 1 | 705011113 | Yellow LH Door Panel Model Yellow | 1 |
| 1 | 705011114 | Yellow RH Door Panel Model Yellow | 1 |
| 1 | 705011344 | Black LH Door Frame Except Model Gold | 1 |
| 1 | 705011345 | Black RH Door Frame Except Model Gold | 1 |
| 1 | 705011346 | Red LH Door Frame Model Gold | 1 |
| 1 | 705011347 | Red RH Door Frame Model Gold | 1 |
| 4 | 207582054 | Washer Head Hexa. Screw M8 X 20 | 4 |
| 4 | 234081430 | Flat Washer M8 | 4 |
| 4 | 234081100 | Flat Washer 8 mm, Nylon | 4 |
| 1 | 705012183 | LH Latch | 1 |
| 1 | 705012184 | RH Latch | 1 |
| 2 | 293850126 | Belt | 2 |
| XXXX | Not Available As Spare Part - Spring Order item 2540 | ||
| 2 | 293730070 | Belt Stopper | 2 |
| 2 | 293730072 | Belt Stopper | 2 |
| 1 | 705010734 | LH Latch Cover | 1 |
| 1 | 705010735 | RH Latch Cover | 1 |
| 4 | 250000721 | Torx Truss Screw M6 X 16 | 4 |
| 3 | 250000721 | Torx Truss Screw M6 X 16 LH Side | 3 |
| 3 | 250000722 | Torx Screw M6 X 20 RH Side | 3 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 2 | 293850129 | Door Belt | 2 |
| 1 | 705010732 | LH Lower Door Panel Except Model X3 Xrs | 1 |
| 1 | 705010733 | RH Lower Door Panel Except Model X3 Xrs | 1 |
| 2 | 250000749 | Torx Truss Screw M6 X 50 LH Side, Except Model X3 Xrs | 2 |
| 2 | 250000868 | Torx Truss M6 X 50 RH Side, Except Model X3 Xrs | 2 |
| 8 | 234062670 | Stainless Steel Flat Washer Except Model X3 Xrs | 8 |
| 4 | 233261466 | Hex. Flange Elastic Nut M6 Except Model X3 Xrs | 4 |
| 2 | 293150108 | Pop Rivet 3/16” | 2 |
| 2 | 293900112 | Bushing | 2 |
| 715004073 | LH Front Lateral Panel | ||
| 1 | 715004074 | RH Front Lateral Panel Kit | 1 |
| 16 | 250000722 | Torx Screw M6 X 20 | 16 |
| 4 | 233261466 | Hex. Flange Elastic Nut M6 | 4 |
| 293450274 | Insert | ||
| 5 | 250000048 | Panel Nut M6 X 1.0 | 5 |
| 2 | 250000868 | Torx Truss M6 X 50 | 2 |
| 1 | 233261434 | Flange Elastic Nut M6 | 1 |
| 1 | 705010334 | RH Side Panel Cover | 1 |
| 1 | 705009511 | LH Rear Fender Deflector | 1 |
| 1 | 705009512 | RH Rear Fender Deflector | 1 |
| 10 | 250000722 | Torx Screw M6 X 20 | 10 |
| 10 | 234062670 | Stainless Steel Flat Washer | 10 |
| 10 | 233161464 | Hex. Elastic Flange Nut M6 | 10 |
| 2 | 250000807 | Torx Truss Screw M6 X 25 | 2 |
| 1 | 705009513 | LH Central Lateral Panel | 1 |
| 1 | 705009514 | RH Central Lateral Panel | 1 |
| 2 | 705010872 | Insert | 2 |
| 1 | 705010676 | LH Rear Lateral Panel | 1 |
| 1 | 705010677 | Deep Black, RH Rear Lateral Panel | 1 |
| 2 | 293150104 | Pop Rivet 3/16" | 2 |
| 2 | 705003841 | Support Plate | 2 |
| 1 | 705009515 | White, LH Rear Fender Model White | 1 |
| 1 | 705011119 | Yellow LH Rear Fender Model Yellow | 1 |
| 1 | 705011121 | Black, LH Rear Fender Model Black | 1 |
| 1 | 705011123 | Gold, LH Rear Fender Model Gold | 1 |
| 1 | 705009516 | White, RH Rear Fender Model White | 1 |
| 1 | 705011120 | Yellow RH Rear Fender Model Yellow | 1 |
| 1 | 705011122 | Black, RH Rear Fender Model Black | 1 |
| 1 | 705011124 | Gold, RH Rear Fender Model Gold | 1 |
| 14 | 250000722 | Torx Screw M6 X 20 | 14 |
| 10 | 705010872 | Insert | 10 |
| 1 | 705010686 | LH Rear Lateral Cover | 1 |
| 1 | 705010687 | RH Rear Lateral Cover | 1 |
| 4 | 250000720 | Torx Screw K50 X 16 | 4 |
| 1 | 705010335 | LH Rear Cage Trim | 1 |
| 1 | 705010336 | RH Rear Cage Trim | 1 |
| 2 | 293650268 | Clip | 2 |
| 1 | 705010001 | Rear Facia | 1 |
| 5 | 250000722 | Torx Screw M6 X 20 | 5 |
| 2 | 705011221 | Red Reflector | 2 |
| 2 | 233251494 | Elastic Flange Nut M5 | 2 |
| 1 | 715004063 | Luggage Rack | 1 |
| 1 | 705010773 | E-Coat Luggage Rack Tube | 1 |
| 2 | 230683034 | Hex. Flange Screw M8 X 130 | 2 |
| 2 | 269501943 | Elastic Nut Housing M8 | 2 |
| 6 | 250000868 | Torx Truss M6 X 50 | 6 |
| 6 | 233261494 | Hex. Elastic Flange Nut M6 | 6 |
| 4 | 207687044 | Hex. Flange Screw M8 X 70 | 4 |
| 4 | 233081416 | Hex. Flange Nut M8 | 4 |
| 3 | 250000048 | Panel Nut M6 X 1.0 | 3 |
| 1 | 705010288 | Air Intake Cover | 1 |
| 1 | 705011293 | Foam Air Intake Cover | 1 |
| 4 | 250000760 | Torx Screw Truss Head K50X20 T20 | 4 |
| 1 | 705010286 | Rear Cover | 1 |
| 1 | 705010390 | Central Skid Plate Except Model X3 Xrs | 1 |
| 1 | 705012362 | Central Skid Plate Model X3 Xrs | 1 |
| 1 | 293150108 | Pop Rivet 3/16” | 1 |
| 1 | 705010391 | Rear Skid Plate Except Model X3 Xrs | 1 |
| 1 | 705012363 | Rear Skid Plate Model X3 Xrs | 1 |
| 2 | 705011187 | Door Support | 2 |
| 1 | 715002902 | Sport Roof Kit Model X3 Xrs | 1 |
| 1 | 704904566 | Decal "Can-Am" Model X3 Xrs | 1 |
| 2 | 715003815 | Quarter Turn Service Kit Model X3 Xrs | 2 |
| XXXX | Not Available As Spare Part - Hardware Service Kit (if applicable) Model X3 Xrs | ||
| 4 | 250000792 | Torx Screw M5 X 20 Model X3 Xrs | 4 |
| 8 | 250200164 | Flat washer M6 Model X3 Xrs | 8 |
| 4 | 705011055 | Quarter Turn Urethane Washer Model X3 Xrs | 4 |
| 4 | 233251494 | Elastic Flange Nut M5 Model X3 Xrs | 4 |
| 1 | 219704385 | Was 293250424 Seal Model X3 Xrs | 1 |
| 2 | 705011280 | Strap Model X3 Xrs | 2 |
