Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 707001943 | CAP Package XMR | 2 |
| 2 | 707001978 | Cap Can-Am Red Package XMR | 2 |
| 2 | 233251494 | Elastic Flange Nut M5 Package XMR | 2 |
| 2 | 250000577 | Torx Truss Screw K40 X 12 Package XMR | 2 |
| 2 | 250000792 | Torx Screw M5 X 20 Package XMR | 2 |
| 2 | 234052600 | Flat Washer 5 mm, Stainless Package XMR | 2 |
| 1 | 705007918 | LH REAR FENDER SUPPORT | 1 |
| 1 | 705007919 | RH REAR FENDER SUPPORT | 1 |
| 2 | 705007917 | Support Plate | 2 |
| 4 | 250000760 | Torx Screw Truss Head K50X20 T20 | 4 |
| 2 | 250000048 | Panel Nut M6 X 1.0 | 2 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 2 | 250000646 | Black, Torx Screw M6 X 35 | 2 |
| 1 | 705010785 | FENDER REAR L B-101 Package XMR | 1 |
| 1 | 705010786 | RIGHT REAR FENDER Package XMR | 1 |
| 1 | 705009729 | Hyper Silver LH Rear Fender Package XDS | 1 |
| 1 | 705009730 | Hyper Silver RH Rear Fender Package XDS | 1 |
| 1 | 705008949 | FENDER REAR L B-365 | 1 |
| 1 | 705008951 | Quarry Gray RH Rear Fender | 1 |
| 1 | 705009727 | Timeless Black LH Rear Fender | 1 |
| 1 | 705009728 | TIMELESS BLACK RH REAR FENDER | 1 |
| 1 | 705007045 | LH Rear Facia Support | 1 |
| 1 | 705009037 | White LH Rear Fender Package XC DPS | 1 |
| 1 | 705009038 | White RH Rear Fender Package XC DPS | 1 |
| 1 | 705009033 | FENDER REAR L B-190 Package XC | 1 |
| 1 | 705009034 | Yellow RH Rear Fender Package XC | 1 |
| 6 | 517302785 | Edge Clip | 6 |
| 1 | 705009445 | INNER FENDER Engine 1000TEFI | 1 |
| 1 | 705009548 | LH Inner Fender Engine 1000REFI | 1 |
| 1 | 705009549 | RH Inner Fender | 1 |
| 12 | 250000079 | Panel Nut M5 X 0.8 | 12 |
| 6 | 250000724 | Torx Screw M5 X 20 | 6 |
| 6 | 250000762 | Torx Screw M5 X 25 | 6 |
| 6 | 250200025 | Washer M5 | 6 |
| 4 | 250000712 | Torx Screw M6 X 20 | 4 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 2 | 250000712 | Torx Screw M6 X 20 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 4 | 705011221 | Red Reflector Except Europe | 4 |
| 4 | 233251494 | Elastic Flange Nut M5 Except Europe | 4 |
| 2 | 705011221 | Red Reflector Europe | 2 |
| 2 | 705006828 | REFLECTOR SUPPORT Europe | 2 |
| 4 | 233251494 | Elastic Flange Nut M5 Europe | 4 |
| 2 | 250000742 | Torx Screw M5 X 14 Europe | 2 |
| 1 | 705006128 | Bagage Central Rack Engine 1000REFI | 1 |
| 1 | 705006132 | Central Bagage Rack Cap Engine 1000REFI | 1 |
| 1 | 705006279 | Bagage Rack Tube Engine 1000REFI | 1 |
| 715004179 | REAR RACK KIT | ||
| 1 | 705005469 | Tube | 1 |
| 1 | 705005470 | Tube | 1 |
| 2 | 250000648 | Torx Screw M6 X 60 Engine 1000REFI | 2 |
| 1 | 250000646 | Black, Torx Screw M6 X 35 | 1 |
| 2 | 250000647 | Torx Screw M6 X 45 Engine 1000REFI | 2 |
| 1 | 233261434 | Flange Elastic Nut M6 | 1 |
| 2 | 207561634 | Hex. Flange Screw M6 X 16, Scotch Grip | 2 |
| 293450274 | Insert | ||
| 1 | 705006713 | LH Bagage Rack Cover | 1 |
| 1 | 705006714 | RH BAGAGE RACK COVER | 1 |
| 6 | 234062670 | Stainless Steel Flat Washer Engine 1000TEFI | 6 |
| 1 | 705009046 | LH INTERCOOLER COVER Engine 1000TEFI | 1 |
| 8 | 250000722 | Torx Screw M6 X 20 Engine 1000TEFI | 8 |
| 1 | 705009047 | RH INTERCOOLER COVER Engine 1000TEFI | 1 |
| 1 | 705005994 | LOGO Support | 1 |
| 1 | 250000720 | Torx Screw K50 X 16 | 1 |
| 2 | 705007828 | Deflector Package XC, XC DPS | 2 |
| 2 | 705007828 | Deflector Package DPS | 2 |
| 2 | 705007828 | Deflector Package XXC, XMR | 2 |
| 2 | 705009408 | SUPPORT Package XDS | 2 |
| 1 | 705009143 | DEFLECTOR Engine 1000TEFI Except Europe | 1 |
| 1 | 293150089 | Tuflok Plastic Rivet | 1 |
| 1 | 250200025 | Washer M5 | 1 |
| 1 | 250000724 | Torx Screw M5 X 20 | 1 |
| 1 | 233251494 | Elastic Flange Nut M5 | 1 |
| 1 | 236282054 | Hex. Screw M8 X 20 Engine 1000TEFI Except Europe | 1 |
| 1 | 234281474 | Conical Spring Washer M8 Engine 1000TEFI Except Europe | 1 |
| 1 | 705004731 | LH Rear Facia Except Europe | 1 |
| 1 | 705004927 | LH Rear Facia Europe | 1 |
| 1 | 705004732 | RH Rear Facia Except Europe | 1 |
| 1 | 705004926 | RH Rear Facia Europe | 1 |
| 1 | 705010793 | Trim LH Can-Am Red Package XMR | 1 |
| 1 | 705010794 | TRIM_HEADLIGHT REAR R B-101 Package XMR | 1 |
| 1 | 705009733 | Hyper Silver LH Trim Package XDS | 1 |
| 1 | 705009734 | Hyper Silver RH Trim Package XDS | 1 |
| 1 | 705008952 | TRIM_HEADLIGHT REAR L B-365 | 1 |
| 1 | 705008953 | TRIM_HEADLIGHT REAR R B-365 | 1 |
| 1 | 705009731 | TIMELESS BLACK LH TRIM | 1 |
| 1 | 705009732 | TIMELESS BLACK RH TRIM | 1 |
| 1 | 705007370 | WHITE LH REAR FACIA TRIM Package XC DPS | 1 |
| 1 | 705007371 | WHITE RH REAR FACIA TRIM Package XC DPS | 1 |
| 1 | 705005990 | YELLOW LH REAR FACIA TRIM Package XC | 1 |
| 1 | 705005991 | Yellow RH Rear Facia Trim Package XC | 1 |
| 4 | 233261434 | Flange Elastic Nut M6 | 4 |
| 2 | 250000079 | Panel Nut M5 X 0.8 | 2 |
| 2 | 250000724 | Torx Screw M5 X 20 | 2 |
| 2 | 224060201 | Flat Washer | 2 |
| 4 | 705007044 | Rear Support Facia Clip | 4 |
| 2 | 207687044 | Hex. Flange Screw M8 X 70 | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 1 | 705007299 | Body Tube | 1 |
| 1 | 705007046 | RH Rear Facia Support | 1 |
| 2 | 705007047 | TUBE CONNECTOR | 2 |
| 2 | 207562544 | Hex. Flange Screw M6 X 25 | 2 |
| 2 | 224061201 | Flat Washer | 2 |
| 1 | 705204547 | SCOOP ASS'Y Engine 1000TEFI | 1 |
| 8 | 241140060 | Screw K40 X 10 | 8 |
| 1 | 705009260 | Upper Grille | 1 |
| 1 | 705009261 | Lower Grille | 1 |
| 8 | 391301000 | WASHER | 8 |
| 1 | 705009262 | Air Duct Support Engine 1000TEFI | 1 |
| 2 | 250000712 | Torx Screw M6 X 20 Engine 1000TEFI | 2 |
| 1 | 705009343 | REAR SUPPORT Engine 1000TEFI | 1 |
| 2 | 233261434 | Flange Elastic Nut M6 Engine 1000TEFI | 2 |
| 2 | 293150103 | Pop Rivet 3/16" Engine 1000TEFI | 2 |
| 1 | 705008988 | LH Front Deflector Model Hyper Sylver and Timeless Black | 1 |
