Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 715003790 | Frame MAX Ass'y Black Package XMR, DPS | ||
| 715003795 | Frame MAX Ass'y Black Package XDS XRS, XDS DPS, XDS STD | ||
| 1 | 715003420 | Black Cage Kit Includes 30 to 30c | 1 |
| 715003427 | Red Cage Kit Includes 30 to 30c | ||
| 1 | 715003423 | Blue Cage Kit Includes 30 to 30c | 1 |
| 1 | 704903679 | Warning Label | 1 |
| 1 | 704903680 | Warning Label | 1 |
| 1 | 704903492 | Warning Label | 1 |
| 1 | 715003424 | Black Center Safety Cage Kit Includes 40 to 40d | 1 |
| 1 | 715003429 | Red Center Safety Cage Kit Includes 40 to 40d | 1 |
| 1 | 715003425 | Blue Center Safety Cage Kit Includes 40 to 40d | 1 |
| 3 | 233181414 | Hex. Flange Nut M8 | 3 |
| 1 | 705203514 | Rear Hand Mounting | 1 |
| 705203685 | FRONT BUMPER Package DPS, XMR, XDS STD | ||
| 705204266 | FRONT BUMPER ASS'Y Package XDS DPS, XDS XRS | ||
| 1 | 250000597 | Hex. Flange Screw | 1 |
| 1 | 233201416 | Hex. Flange Elastic Nut M10 | 1 |
| 2 | 207382544 | SCREW-HEX.CAP DIN.933 S.GRIP | 2 |
| 2 | 250100118 | Panel Nut M8 X 1.25 | 2 |
| 1 | 234201474 | Conical Spring Washer 10 mm | 1 |
| 1 | 705203642 | Black RH Front Side Protector Tube | 1 |
| 1 | 705203643 | Black LH Front Side Protector Tube | 1 |
| 1 | 705204069 | RED RH FRONT SIDE PROTECTOR TUBE | 1 |
| 1 | 705204068 | RED LH FRONT SIDE PROTECTOR TUBE | 1 |
| 1 | 705204819 | BLUE RH FRONT SIDE PROTECTOR TUBE | 1 |
| 1 | 705204818 | BLUE LH FRONT SIDE PROTECTOR TUBE | 1 |
| 2 | 705203415 | Binding Block | 2 |
| 1 | 705203332 | Black Handle | 1 |
| 4 | 207662046 | Hex. Flange Screw M6 X 20 | 4 |
| 4 | 233261416 | Elastic Flange Nut M6 X 1.0 | 4 |
| 26 | 250000848 | Screw Pan M10 X 30 | 26 |
| 14 | 233101464 | Hex. Elastic Flange Nut , M10 X 1.5 | 14 |
| 8 | 250000789 | Torx Truss M6X14 | 8 |
| 8 | 705202223 | Offset Washer | 8 |
| 8 | 207682044 | Hex. Flange Screw M8 X 20 | 8 |
| 8 | 233281414 | Hex. Flange Elastic Nut M8 | 8 |
| 4 | 250200154 | Washer | 4 |
| 1 | 705203649 | Black LH Rear Side Protector Tube | 1 |
| 1 | 705203652 | Black RH Rear Side Protector Tube | 1 |
| 1 | 705204064 | RED LH REAR SIDE PROTECTOR TUBE | 1 |
| 1 | 705204065 | RED RH REAR SIDE PROTECTOR TUBE | 1 |
| 1 | 705204820 | SIDE PROTECT | 1 |
| 1 | 705204821 | BLUE RH REAR SIDE PROTECTOR TUBE | 1 |
| 1 | 705203695 | REINFORCEMENT Package DPS, XMR | 1 |
| 1 | 705203454 | FRONT SUSPENSION LINK | 1 |
| 705204767 | REAR BUMPER RED Package XDS XRS | ||
| 705203282 | REAR PROTECTOR Package XDS XRS | ||
| 2 | 250000234 | Torx Screw M6 X 20, Stainless Package XDS XRS | 2 |
| 2 | 233261494 | Hex. Elastic Flange Nut M6 Package XDS XRS | 2 |
| 705204766 | UPPER ARM RED Package XDS XRS | ||
| 2 | 250000761 | Torx Truss Screw M8 X 50 Package XDS XRS | 2 |
| 2 | 234082410 | Flat Washer 8 mm Package XDS XRS | 2 |
| 8 | 233281464 | Elastic Flange Nut M8 Package XDS XRS | 8 |
| 4 | 250000777 | Torx Screw Scotch Grip M8X60 Package XDS XRS | 4 |
| 708300563 | WASHER Package XDS XRS | ||
| 4 | 233201416 | Hex. Flange Elastic Nut M10 Package XDS XRS | 4 |
| 4 | 207609046 | Hex. Flange Screw M10 X 90 Package XDS XRS | 4 |
