Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4 | 705010721 | Clip | 4 |
| 4 | 517302785 | Edge Clip | 4 |
| 2 | 705003841 | Support Plate | 2 |
| 2 | 250000048 | Panel Nut M6 X 1.0 | 2 |
| 2 | 293150089 | Tuflok Plastic Rivet | 2 |
| 2 | 520000271 | Amber, Reflector | 2 |
| 2 | 250000720 | Torx Screw K50 X 16 | 2 |
| 1 | 705011806 | LH Reflector Support | 1 |
| 1 | 705011814 | RH Reflector Support | 1 |
| 1 | 705010628 | LH Light Cover | 1 |
| 1 | 705010629 | RH Light Cover | 1 |
| 1 | 705011354 | WHITE LH DOOR PANEL Bright White | 1 |
| 1 | 705012250 | Yellow LH Door Panel Circuit Yellow Met. | 1 |
| 1 | 705012254 | Black, LH Door Panel Timeless Black Metallic | 1 |
| 1 | 705012256 | Gold, LH Door Panel Liquid Gold | 1 |
| 1 | 705012246 | Black LH Door Frame Exept Liquid Gold | 1 |
| 1 | 705012248 | Red LH Door Frame Liquid Gold | 1 |
| 1 | 705011187 | Door Support | 1 |
| 2 | 207582054 | Washer Head Hexa. Screw M8 X 20 | 2 |
| 2 | 234081430 | Flat Washer M8 | 2 |
| 1 | 234081100 | Flat Washer 8 mm, Nylon | 1 |
| 1 | 705012183 | LH Latch | 1 |
| 1 | 293850126 | Belt | 1 |
| 1 | 293730070 | Belt Stopper | 1 |
| 1 | 293730072 | Belt Stopper | 1 |
| 1 | 705011356 | LH Latch Cover | 1 |
| 1 | 234062670 | Stainless Steel Flat Washer | 1 |
| 3 | 250000048 | Panel Nut M6 X 1.0 | 3 |
| 1 | 250000748 | Torx Screw M6 X 45 | 1 |
| 2 | 250000721 | Torx Truss Screw M6 X 16 | 2 |
| 2 | 293150103 | Pop Rivet 3/16" | 2 |
| 4 | 293150103 | Pop Rivet 3/16" | 4 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 1 | 705011358 | LH Lower Door Cover | 1 |
| 2 | 250000868 | Torx Truss M6 X 50 | 2 |
| 1 | 250000722 | Torx Screw M6 X 20 | 1 |
| 3 | 234062670 | Stainless Steel Flat Washer | 3 |
| 2 | 233261466 | Hex. Flange Elastic Nut M6 | 2 |
| 1 | 250000048 | Panel Nut M6 X 1.0 | 1 |
| 1 | 293850129 | Door Belt | 1 |
| 1 | 705011355 | WHITE RH DOOR PANEL Bright White | 1 |
| 1 | 705012251 | Yellow RH Door Panel Circuit Yellow Met. | 1 |
| 1 | 705012255 | Black, RH Door Panel Timeless Black Metallic | 1 |
| 1 | 705012257 | Gold, RH Door Panel Liquid Gold | 1 |
| 1 | 705012247 | Black RH Door Frame Exept Liquid Gold | 1 |
| 1 | 705012249 | Red RH Door Frame Liquid Gold | 1 |
| 1 | 705012184 | RH Latch | 1 |
| 1 | 705011357 | RH Latch Cover | 1 |
| 1 | 705011359 | Right Lower Door Cover | 1 |
| 1 | 705010067 | White LH Door Panel Bright White | 1 |
| 1 | 705011113 | Yellow LH Door Panel Circuit Yellow Met. | 1 |
| 1 | 705011115 | Black, LH Door Panel Timeless Black Metallic | 1 |
| 1 | 705011117 | Gold, LH Door Panel Liquid Gold | 1 |
| 1 | 705011344 | Black LH Door Frame Exept Liquid Gold | 1 |
| 1 | 705011346 | Red LH Door Frame Liquid Gold | 1 |
| 2 | 234081100 | Flat Washer 8 mm, Nylon | 2 |
| 1 | 705010734 | LH Latch Cover | 1 |
| 3 | 293150103 | Pop Rivet 3/16" | 3 |
| 3 | 250000721 | Torx Truss Screw M6 X 16 | 3 |
| 1 | 705010732 | LH Lower Door Panel | 1 |
| 2 | 250000749 | Torx Truss Screw M6 X 50 | 2 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 1 | 705010068 | White RH Door Panel Bright White | 1 |
| 1 | 705011114 | Yellow RH Door Panel Circuit Yellow Met. | 1 |
| 1 | 705011116 | Black, RH Door Panel Timeless Black Metallic | 1 |
| 1 | 705011118 | Gold, RH Door Panel Liquid Gold | 1 |
| 1 | 705011345 | Black RH Door Frame Exept Liquid Gold | 1 |
| 1 | 705011347 | Red RH Door Frame Liquid Gold | 1 |
| 1 | 705010735 | RH Latch Cover | 1 |
| 3 | 250000722 | Torx Screw M6 X 20 | 3 |
| 1 | 705010733 | RH Lower Door Panel | 1 |
| 1 | 715004064 | LH Front Lateral Panel Kit | 1 |
| 8 | 250000722 | Torx Screw M6 X 20 | 8 |
| 2 | 233161464 | Hex. Elastic Flange Nut M6 | 2 |
| 293450274 | Insert | ||
| 1 | 250000868 | Torx Truss M6 X 50 | 1 |
| 1 | 715004074 | RH Front Lateral Panel Kit | 1 |
| 1 | 233161464 | Hex. Elastic Flange Nut M6 | 1 |
| 1 | 517303756 | Grommet | 1 |
| 1 | 705010334 | RH Side Panel Cover | 1 |
| 1 | 705009511 | LH Rear Fender Deflector | 1 |
| 1 | 705009512 | RH Rear Fender Deflector | 1 |
| 10 | 250000722 | Torx Screw M6 X 20 | 10 |
| 10 | 234062670 | Stainless Steel Flat Washer | 10 |
| 10 | 233161464 | Hex. Elastic Flange Nut M6 | 10 |
| 2 | 250000807 | Torx Truss Screw M6 X 25 | 2 |
| 1 | 705009513 | LH Central Lateral Panel | 1 |
| 1 | 705009514 | RH Central Lateral Panel | 1 |
| 4 | 250000722 | Torx Screw M6 X 20 | 4 |
| 2 | 705010872 | Insert | 2 |
| 1 | 705011368 | LH Rear Central Lateral Panel | 1 |
| 1 | 705011369 | RH Rear Central Lateral Panel | 1 |
| 2 | 293150108 | Pop Rivet 3/16” | 2 |
| 2 | 250000722 | Torx Screw M6 X 20 | 2 |
| 1 | 705010676 | LH Rear Lateral Panel | 1 |
| 1 | 705010677 | Deep Black, RH Rear Lateral Panel | 1 |
| 2 | 293150104 | Pop Rivet 3/16" | 2 |
| 1 | 705009515 | White, LH Rear Fender Bright White | 1 |
| 1 | 705011119 | Yellow LH Rear Fender Circuit Yellow Met. | 1 |
| 1 | 705011121 | Black, LH Rear Fender Timeless Black Metallic | 1 |
| 1 | 705011123 | Gold, LH Rear Fender Liquid Gold | 1 |
| 1 | 705009516 | White, RH Rear Fender Bright White | 1 |
| 1 | 705011120 | Yellow RH Rear Fender Circuit Yellow Met. | 1 |
| 1 | 705011122 | Black, RH Rear Fender Timeless Black Metallic | 1 |
| 1 | 705011124 | Gold, RH Rear Fender Liquid Gold | 1 |
| 14 | 250000722 | Torx Screw M6 X 20 | 14 |
| 10 | 705010872 | Insert | 10 |
| 4 | 705003841 | Support Plate | 4 |
| 1 | 705010686 | LH Rear Lateral Cover | 1 |
| 1 | 705010687 | RH Rear Lateral Cover | 1 |
| 3 | 250000720 | Torx Screw K50 X 16 | 3 |
| 1 | 705011579 | LH Central Cage Trim | 1 |
| 1 | 705011580 | RH Central Cage Trim | 1 |
| 4 | 250000048 | Panel Nut M6 X 1.0 | 4 |
| 1 | 705010335 | LH Rear Cage Trim | 1 |
| 1 | 705010336 | RH Rear Cage Trim | 1 |
| 2 | 293650268 | Clip | 2 |
| 1 | 705011370 | WHITE LH CENTRAL DOOR TRIM Bright White | 1 |
| 1 | 705012267 | Yellow LH Central Door Trim Circuit Yellow Met. | 1 |
| 1 | 705012271 | Black, LH Central Door Trim Timeless Black Metallic | 1 |
| 1 | 705012273 | Gold, LH Central Door Trim Liquid Gold | 1 |
| 1 | 705010872 | Insert | 1 |
| 1 | 293150103 | Pop Rivet 3/16" | 1 |
| 1 | 705011371 | White RH Central Door Trim Bright White | 1 |
| 705012268 | Yellow RH Central Door Trim Circuit Yellow Met. | ||
| 1 | 705012272 | Black RH Central Door Trim Timeless Black Metallic | 1 |
| 1 | 705012274 | Gold, RH Central Door Trim Liquid Gold | 1 |
| 2 | 230683034 | Hex. Flange Screw M8 X 130 | 2 |
| 2 | 269501943 | Elastic Nut Housing M8 Includes 5620 to 5620a | 2 |
| 1 | 232581200 | Hex. Elastic Nut M8 Brass | 1 |
| 2 | 233261494 | Hex. Elastic Flange Nut M6 | 2 |
| 4 | 207687044 | Hex. Flange Screw M8 X 70 | 4 |
| 4 | 233081416 | Hex. Flange Nut M8 | 4 |
