Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8 | 207523544 | Hex. Flange Screw M12 X 35, Scotch Grip | 8 |
| 4 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip Commander Package LTD | 4 |
| 4 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip Commander Package LTD | 4 |
| 2 | 207661644 | Hex. Flange Screw M6 X 16 Commander Package LTD | 2 |
| 4 | 233221416 | Elastic Flange Nut M12 | 4 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 Commander Package LTD | 2 |
| 3 | 233281414 | Hex. Flange Elastic Nut M8 Commander Package LTD | 3 |
| 2 | 250000515 | Hex. Cap Screw M12 X 241 | 2 |
| 2 | 250000546 | Oval Head Torx Screw K60 X 16 Commander Package LTD | 2 |
| 1 | 250100124 | Hex. Nut With Nylon 1/2" X 20 Commander Package LTD | 1 |
| 2 | 250200120 | Flat Washer M12 | 2 |
| 4 | 293150104 | Pop Rivet 3/16" | 4 |
| 4 | 293200094 | Seal | 4 |
| 8 | 293350055 | Ball Bearing | 8 |
| 293450274 | Insert Commander Package LTD | ||
| 4 | 293650053 | Crimp Clamp Commander Package LTD | 4 |
| 1 | 293650195 | Clamp, Oetiker Commander Package LTD | 1 |
| 1 | 293650218 | Hose Retainer Commander Package LTD | 1 |
| 1 | 293710035 | Straight Fitting Commander Package LTD | 1 |
| 3 | 293730018 | Mount Dart Commander Package LTD | 3 |
| 1 | 293750002 | Tie Wrap 142 mm Commander Package LTD | 1 |
| 2 | 390406500 | Pop Rivet 3/16" | 2 |
| 1 | 414115200 | Tie-Rap 180 mm Commander Package LTD | 1 |
| 1 | 414811400 | O-Ring Commander Package LTD | 1 |
| 2 | 515176044 | Battery Strap Commander Package LTD | 2 |
| 4 | 517124300 | Washer Commander Package LTD | 4 |
| 2 | 705600040 | Open Clamp Commander Package LTD | 2 |
| 1 | 705601337 | Bracket Commander Package LTD | 1 |
| 1 | 706000567 | Spring Stopper | 1 |
| 1 | 706000615 | Rear Shock Except Com-MAX Model - Except Package XTP, LTD | 1 |
| 1 | 706001509 | Rear Shock Com-MAX Model Except Package LTD | 1 |
| 1 | 706002004 | REAR SHOCK Com-Max Package LTD | 1 |
| 1 | 706002264 | REAR SHOCK Package XTP | 1 |
| 1 | 706000630 | LH Joint Protector | 1 |
| 1 | 706000667 | Yellow Rear Spring Commander Package XT Yellow Model | 1 |
| 1 | 706001997 | YELLOW REAR SPRING Com-Max Package XT Yellow Model | 1 |
| 1 | 706001043 | Red Rear Spring Commander Package DPS | 1 |
| 706001809 | CAN-AM RED REAR SPRING Com-Max Package DPS | ||
| 1 | 706001043 | Red Rear Spring Commander Package XT White Model | 1 |
| 1 | 706001043 | Red Rear Spring Commander Package XT Brush Aluminium Model | 1 |
| 706001809 | CAN-AM RED REAR SPRING Com-Max Package XT Brush Aluminium Model | ||
| 1 | 706001043 | Red Rear Spring Commander Package STD | 1 |
| 1 | 706001045 | Black Rear Spring Commander Package XT Camo , Hunter, Model | 1 |
| 1 | 706001998 | BLACK REAR SPRING Com-Max Package XT Camo Model | 1 |
| 1 | 706002143 | Black Rear Spring Commander Package XT Black Model | 1 |
| 1 | 706002145 | BLACK REAR SPRING Com-Max Package XT Black Model | 1 |
| 1 | 706002005 | BLACK REAR SPRING Com-Max Package LTD | 1 |
| 1 | 706001807 | PAINT REAR SPRING Package XTP | 1 |
| 1 | 706000806 | T-FITTING Commander Package LTD | 1 |
| 1 | 706000808 | Auxiliary Hose Commander Package LTD | 1 |
| 1 | 706000814 | RH Joint Protector | 1 |
| 1 | 706000910 | Adjustment Ring | 1 |
| 1 | 706000911 | Protector Ring | 1 |
| 1 | 706001039 | Rear Shock Ass'y Commander Package LTD | 1 |
| 2 | 706002004 | REAR SHOCK Package LTD MAX Model | 2 |
| 2 | 706002264 | REAR SHOCK Package XTP | 2 |
| 1 | 706001040 | BLACK REAR SPRING Commander Package LTD | 1 |
| 706001100 | COMPRESSOR Commander Package LTD | ||
| 706001120 | UPPER SUPPORT Commander Package LTD | ||
| 706001121 | LOWER SUPPORT Commander Package LTD | ||
| 3 | 706001127 | RUBBER MOUNT Commander Package LTD | 3 |
| 1 | 706001141 | Air Filter Commander Package LTD | 1 |
| 1 | 706001144 | PRESSURE DISTRIBUTOR ASS'Y Commander Package LTD | 1 |
| 1 | 706001145 | HOSE, POLYURETHANE 6 MM Commander Package LTD | 1 |
| 1 | 706001874 | HOSE 4.0MM Commander Package LTD | 1 |
| 219704411 | FUEL LINE 10000MM LONG Commander Package LTD | ||
| 1 | 219704410 | Polyurethane Hose 10000Mm Long Commander Package LTD | 1 |
| 1 | 706001318 | RH Swing Arm Except Max Model | 1 |
| 1 | 706001319 | LH Swing Arm Except Max Model | 1 |
| 1 | 706001513 | RH Swing Arm MAX Model | 1 |
| 1 | 706001514 | LH Swing Arm MAX Model | 1 |
| 4 | 706001350 | Spacer | 4 |
| 1 | 706001500 | Sway Bar Ass'y Except MAX Model - Except Package XTP | 1 |
| 706001503 | SWAY BAR ASS'Y Package XTP | ||
| 1 | 706001718 | Sway Bar MAX Model | 1 |
| 2 | 706001529 | Bushing | 2 |
| 1 | 706001751 | Rear Shock Distributor Commander Package LTD | 1 |
| 1 | 706001104 | Solenoid Valve Commander Package LTD | 1 |
| 706002294 | Support Bracket Commander Package LTD | ||
| 1 | 706002299 | Rear Hose Ass'y Commander Package LTD | 1 |
| 1 | 706201524 | TANK BRACKET Commander Package LTD | 1 |
| 4 | 210261250 | Hex. Flange Screw M6 X 12 Commander Package LTD | 4 |
| 4 | 715500360 | O-RING BUSHING Commander Package LTD | 4 |
| 4 | 715900209 | O-Ring Bushing Package LTD MAX Model | 4 |
| 4 | 715900209 | O-Ring Bushing Package XTP | 4 |
| 4 | 715500361 | Interior Bushing Commander Package LTD | 4 |
| 4 | 715900210 | Interior Bushing Package LTD MAX Model | 4 |
| 4 | 715900210 | Interior Bushing Package XTP | 4 |
| 2 | 715900251 | Spherical Bearing Package LTD MAX Model | 2 |
| 2 | 715900251 | Spherical Bearing Package XTP | 2 |
| 4 | 715900252 | Retaining Ring Package LTD MAX Model | 4 |
| 4 | 715900252 | Retaining Ring Package XTP | 4 |
