Список запчастей

№	Артикул	Название	Кол-во
2	207582044	Hex. Flange Screw M8 X 20, Scotch Grip	2
2	207602544	Hex. Flange Screw M10 X 25 MAX Model	2
2	230602546	Hex. Flange Screw M10 X 125	2
2	250100047	Hex. Castellated Nut M18	2
2	233201414	Hex. Flange Elastic Nut M10 MAX Model	2
2	233201436	Hex. Flange Elastic Nut M10	2
1	250000847	Hex. Flange Screw M10 X 20	1
8	250100042	Steel Wheel Nut Package STD	8
56	250100082	Chrome Wheel Nut M10 X 1.25	56
8	250100100	Black Wheel Nut M10 X 1.25	8
1	250200014	Flat Washer M10	1
2	250200049	Spring Washer	2
8	705400791	Wheel Stud Commander Model Except Package XTP	8
16	250300051	Wheel Stud MAX Model - Commander Model Package XTP	16
2	250400071	Cotter Pin	2
2	293000110	Valve Cap	2
2	293250246	O-Ring	2
2	293350040	Cone Bearing	2
2	293370019	Circlip	2
2	293750002	Tie Wrap 142 mm	2
2	503032900	Washer MAX Model	2
2	705400780	Wear Sleeve	2
3	705400193	Rim Valve With Cap	3
1	705401239	Axle Drive Ass'y	1
1	705401495	Drive Axle Ass'y MAX Model	1
2	705400921	Wheel Cap Package STD	2
2	705400928	Wheel Cap Package XTP	2
2	705401541	Wheel Cap Package DPS, XT, Hunter, LTD	2
1	705401548	LH Front Knuckle	1
1	705401549	RH Front Knuckle	1
6	705401601	Screw	6
8	705401602	Screw	8
1	705401603	Nut	1
1	705401604	Shim	1
1	705401605	Ball Bearing	1
2	705401606	Ball Bearing	2
1	705401607	Needle Bearing	1
2	705401608	Ball Bearing	2
1	705401610	Front Cover	1
1	705401612	Gear 36 Teeth	1
1	705401613	Vent Valve	1
1	705401614	Differential	1
1	705401615	Oil Seal	1
1	705401616	Seal	1
1	705401617	O'Ring	1
2	705401618	Gasket	2
1	705401646	Ball Bearing MAX Model	1
1	705400036	Wear Ring	1
1	705401654	RH Half Shaft	1
1	705401653	LH Half Shaft	1
1	705500504	Fill Level Plug	1
1	705500506	Copper Washer	1
1	219704465	1/2 OZ Weight	1
1	705501885	Drain Plug	1
2	705401314	Wheel Hub Commander Model Except Package XTP	2
2	705501900	Wheel Hub MAX Model - Commander Model Package XTP	2
1	219704410	Polyurethane Hose 10000Mm Long	1
2	705401348	RH Plunging Joint	2
2	705401344	CV Joint	2
2	705401345	Boot Kit, Wheel Side	2
2	715900284	Oetiker Clamp, Large	2
2	715900282	Oetiker Clamp	2
2	715900283	Oetiker Clamp, Small	2
2	715900261	Oetiker Clamp, Small	2
2	705401346	Boot Kit, Differential Side	2
1	705401791	Pinion 10 Teeth	1
1	703500899	Front Differential Ass'y Package STD	1
1	703500900	Front Differential Ass'y Except Package STD	1
2	715900183	U-Joint MAX Model	2
	715900117	SNAP RING MAX Model
4	703500813	GREASE FITTING MAX Model	4
1	703500815	Grease Fitting MAX Model	1
2	715900231	Yoke Joint MAX Model, Cover 715900483	2
3	703500814	Unit Pack Kit	3
1	703500815	Grease Fitting	1
1	715900116	Fixed Yoke Joint	1
	705400781	TIRE_27X9R12 F Package STD
1	705401377	Front Tire Package DPS (Except Europe)	1
1	705401377	Front Tire Package XT (Except Europe)	1
1	705401377	Front Tire Package LTD	1
1	705401377	Front Tire Package Hunter	1
1	705401385	Front Tire Maxxis 27X9X12 Package XTP	1
1	705400961	Front Tire Europe	1
2	705401217	Black, 12" X 6" Rim Package STD	2
1	705401559	Silver Front Rim Package DPS	1
1	705401559	Silver Front Rim Package XT Yellow	1
1	705401559	Silver Front Rim Package XT White	1
1	705401564	Black Front Rim Package XT Camo	1
1	705401564	Black Front Rim Package XT Brushed Aluminium	1
1	705401564	Black Front Rim Package XT Black	1
1	705401678	Black, Rim Package XTP	1
1	705401564	Black Front Rim Package Hunter	1
1	705401563	Black Front Rim Package LTD	1
16	250000787	Hex. Flange Screw M6 X 25 Package XTP	16
16	293450317	Insert Package XTP	16
2	705401349	Circlip Joint	2
1	715900187	COVER	1
