Список запчастей

№	Артикул	Название	Кол-во
2	207028046	Hex. Screw M12 X 80	2
2	207607046	Hex. Flange Screw M10 X 70 Package STD - DPS - XMR - XC -XXC	2
10	207608046	Hex Flange Screw M10 X 80	10
4	207628546	Hex. Flange Screw M12 X 85	4
2	232521416	Elastic Stop Nut M12	2
2	232591414	Elastic Stop Nut M18	2
1	233201436	Hex. Flange Elastic Nut M10	1
4	233221416	Elastic Flange Nut M12	4
1	250000047	Hex. Flange Elastic Nut M12	1
1	250200025	Washer M5	1
2	250200045	Washer	2
2	293300100	O-Ring	2
4	293370093	Retaining Ring	4
2	293550056	Grease Fitting 90°	2
8	408200700	Grease Fitting	8
2	706000251	Retaining Ring	2
1	706001354	Black LH Rear Lower Arm Package STD - DPS - XMR	1
1	706001355	Black RH Rear Lower Arm Package STD - DPS - XMR	1
1	706001484	LH REAR PAINTED LOWER ARM Package XC	1
1	706001485	Black RH Rear Lower Arm Package XC	1
1	706001484	LH REAR PAINTED LOWER ARM Package XXC	1
1	706001485	Black RH Rear Lower Arm Package XXC	1
1	706001935	Black LH Rear Lower Arm Package XDS - XDS DPS	1
1	706001936	Black RH Rear Lower Arm Package XDS - XDS DPS	1
1	706001935	Black LH Rear Lower Arm Package XDSSTD	1
1	706001936	Black RH Rear Lower Arm Package XDSSTD	1
1	706001935	Black LH Rear Lower Arm Package XDSXRS	1
1	706001936	Black RH Rear Lower Arm Package XDSXRS	1
1	706001356	Sway Bar Except MAX Model	1
1	706001625	SWAY BAR MAX Model	1
2	706001371	Sway Bar Lever	2
4	706001373	Radial Joint	4
2	706001402	Sway Bar Housing	2
2	706001711	Spring Spacer MAX Model Package DPS	2
1	706001741	LH Double Ball Joint Package STD - DPS - XMR - XC -XXC	1
1	706001742	RH Double Ball Joint Package STD - DPS - XMR - XC -XXC	1
1	706002089	LH Double Ball Joint Package XDS - XDS DPS	1
1	706002090	RH Double Ball Joint Package XDS - XDS DPS	1
1	706002089	LH Double Ball Joint Package XDSXRS - XDSSTD	1
1	706002090	RH Double Ball Joint Package XDSXRS - XDSSTD	1
1	706001798	Ball Joint	1
	706002058	REAR SHOCK Package STD - DPS
2	706002055	REAR SHOCK MAX Model Package DPS	2
2	706002056	Rear Shock Package XC, XXC	2
1	706002418	Shock Package XDSDPS Except Black	1
1	706002347	Shock Package XDSDPS Black	1
2	706001947	Shock MAX Model XDS DPS	2
2	706002129	REAR SHOCK Package XDS	2
1	706002362	SHOCK Package XDSXRS	1
1	706001947	Shock MAX Model XDSXRS	1
1	706002403	SHOCK Package XDSSTD	1
1	706002406	SHOCK MAX Model XDSSTD	1
2	706001920	REAR SHOCK Package XMR	2
1	706001801	Adjustment Rod Package XC, XXC	1
2	706002081	Adjustment Rod Except Package XC, XXC	2
	706001848	SUSPENSION ARM REAR L ECOAT Package XC
1	706001849	Black RH Rear Upper Arm Package XC	1
1	706002091	Black LH Rear Upper Arm Package STD	1
1	706002092	Black RH Rear Upper Arm Package STD	1
1	706002223	SUSPENSION ARM REAR L ECOAT Package XDSSTD	1
1	706002224	SUSPENSION ARM REAR R ECOAT Package XDSSTD	1
1	706001882	RED LH REAR UPPER ARM Package XXC White Model	1
1	706001884	RED RH REAR UPPER ARM Package XXC White Model	1
1	706002095	RED LH REAR UPPER ARM Package XMR White Model	1
1	706002096	Red RH Rear Upper Arm Package XMR White Model	1
1	706002365	SUSPENSION ARM REAR L B-101 CAN-AM RED Package XDSXRS	1
1	706002366	SUSPENSION ARM REAR R B-101 BLACK Package XDSXRS	1
1	706002341	Gulfstream Blue LH Rear Upper Arm Package XDS DPS Silver-Black/Blue Model	1
1	706002342	SUSPENSION ARM REAR R B-352 GULFS BLUE Package XDS DPS Silver-Black/Blue Model	1
1	706002152	Gulfstream Blue LH Rear Upper Arm Package XMR Silver Model	1
1	706002153	SUSPENSION ARM REAR R B-352 GULFS BLUE Package XMR Silver Model	1
	706002154	ARM_SUSPENSION REAR L B-352 PAINTED Package XXC Quarry Gray Model
1	706002155	SUSPENSION ARM REAR R B-352 GULFS BLUE Package XXC Quarry Gray Model	1
1	706002225	SUSPENSION ARM REAR L B-357 MANTA GREEN Package XDS-XDS DPS Black Carbon-Quarry Gray-Black/White Model	1
1	706002226	Manta Green RH Rear Upper Arm Package XDS-XDS DPS Black Carbon-Quarry Gray-Black/White Model	1
1	706002097	MANTA GREEN LH REAR UPPER ARM Package XMR Digital Camo Model	1
1	706002098	MANTA GREEN RH REAR UPPER ARM Package XMR Digital Camo Model	1
1	250200086	Flat Washer	1
8	706201590	Sleeve	8
16	706201659	Cushion	16
8	706201660	Wear Plate	8
2	706202215	Protector	2
2	706202216	SPRING RETAINER Package XDS - XDS DPS - XDSXRS - XDSSTD	2
	706001946	MANTA GREEN SPRING Package XDS-XDS DPS - XDSSTD
2	706001949	MANTA GREEN SPRING MAX Model XDS DPS - XDSSTD	2
2	706002179	GULFSTREAM BLUE SPRING Package XDS DPS-Silver Model	2
2	706002183	GULFSTREAM BLUE SPRING MAX Model XDS DPS-Silver Model	2
2	706002273	RED - REAR SPRING MAX Model Package DPS	2
1	706002364	SPRING Package XDSXRS	1
1	706002370	Red Spring MAX Model XDSXRS	1
2	706001588	WHITE REAR SPRING Package STD White Model	2
1	706002373	SPRING Package XC	1
	706001924	MANTA GREEN REAR SPRING Package XMR Digital Camo Model
	706001945	MANTA GREEN SPRING Package XDS-XDS DPS - XDSSTD
2	706001948	MANTA GREEN SPRING MAX Model XDS DPS - XDSSTD	2
2	706002165	REAR SPRING GULFSTREAM BLUE Package XMR Silver Model	2
2	706002168	GULFSTREAM BLUE SPRING Package XXC Quarry Gray Model	2
	706002178	GULFSTREAM BLUE SPRING Package XDS DPS-Silver Model
2	706002182	GULFSTREAM BLUE SPRING MAX Model XDS DPS-Silver Model	2
2	706002272	RED - REAR SPRING MAX Model Package DPS	2
1	706002363	SPRING Package XDSXRS	1
1	706002369	SPRING MAX Model XDSXRS	1
2	706001591	RED REAR SPRING Package XXC White Model	2
	706002075	RED REAR SPRING Package XMR White Model
2	706002159	RED SPRING Package DPS-STD Quarry Gray Model	2
4	715900267	Internal Bushing Package STD - DPS XMR - XXC - MAX DPS	4
8	715900340	INTERNAL BUSHING Package XDS - XDS DPS - MAX XDS DPS	8
3	210251650	Hex. Forming Screw M5 X 16	3
4	207626046	Hex. Flange Screw M12 X 60	4
2	233201416	Hex. Flange Elastic Nut M10 Package STD - DPS - XMR - XC -XXC	2
1	232170411	Hex. Jam Nut M14	1
1	232175411	LH Hex. Lock Nut M14	1
1	706001437	Ball Joint	1
