Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4 | 207662046 | Hex. Flange Screw M6 X 20 | 4 |
| 705204253 | Black Console Handle Engine 1000T | ||
| 1 | 705204399 | Black Console Handle Engine 1000R | 1 |
| 1 | 705203330 | Reinforcement Panel Manta Green Model | 1 |
| 1 | 234201474 | Conical Spring Washer 10 mm | 1 |
| 293450274 | Insert | ||
| 2 | 207382544 | SCREW-HEX.CAP DIN.933 S.GRIP | 2 |
| 1 | 233201436 | Hex. Flange Elastic Nut M10 | 1 |
| 1 | 715003092 | Black Frame | 1 |
| 7 | 233261416 | Elastic Flange Nut M6 X 1.0 | 7 |
| 1 | 705204606 | Steel Plate | 1 |
| 3 | 250000317 | Torx Screw M6 X 50 | 3 |
| 1 | 250000597 | Hex. Flange Screw | 1 |
| 2 | 250100118 | Panel Nut M8 X 1.25 | 2 |
| 7 | 293150096 | Hemlock Rivet, 6.5 mm | 7 |
| 705203685 | FRONT BUMPER Europe Model | ||
| 705203685 | FRONT BUMPER Package XDSSTD | ||
| 705204266 | FRONT BUMPER ASS'Y Package XDSDPS | ||
| 705204266 | FRONT BUMPER ASS'Y Package XDSXRS | ||
| 1 | 704903492 | Warning Label | 1 |
| 1 | 704903679 | Warning Label | 1 |
| 1 | 704903680 | Warning Label | 1 |
| XXXX | Not Available As Spare Part - Seat Holder Not Available In Service. Included With Frame | ||
| 1 | 705203332 | Black Handle | 1 |
| 2 | 705203415 | Binding Block | 2 |
| 1 | 705203454 | FRONT SUSPENSION LINK | 1 |
| 1 | 715003420 | Black Cage Kit Black Cage Model | 1 |
| 1 | 715003426 | Manta Green Cage Kit Manta Green Cage Model | 1 |
| 715003427 | Red Cage Kit Red Cage Model | ||
| 1 | 715003423 | Blue Cage Kit Blue Cage Model | 1 |
| 12 | 250000848 | Screw Pan M10 X 30 | 12 |
| 4 | 233101464 | Hex. Elastic Flange Nut , M10 X 1.5 | 4 |
| 4 | 250000789 | Torx Truss M6X14 | 4 |
| 4 | 705202223 | Offset Washer | 4 |
| 4 | 207682044 | Hex. Flange Screw M8 X 20 | 4 |
| 4 | 233281414 | Hex. Flange Elastic Nut M8 | 4 |
| 1 | 705203640 | TUBE RH B-160 PAINTED Black Cage Model | 1 |
| 1 | 705204408 | TUBE RH B-357 PAINTED Manta Green Cage Model | 1 |
| 1 | 705204410 | Red RH Front Side Protector Tube Red Cage Model | 1 |
| 1 | 705204817 | Blue RH Side Protector Tube Blue Cage Model | 1 |
| 1 | 705203637 | TUBE LH B-160 PAINTED Black Cage Model | 1 |
| 1 | 705204407 | TUBE LH B-357 PAINTED Manta Green Cage Model | 1 |
| 1 | 705204409 | Red LH Front Side Protector Tube Red Cage Model | 1 |
| 1 | 705204816 | TUBE LH B-352 PAINTED Blue Cage Model | 1 |
| 705204767 | REAR BUMPER RED Package XDSXRS | ||
| 705204766 | UPPER ARM RED Package XDSXRS | ||
| 705203282 | REAR PROTECTOR Package XDSXRS | ||
| 4 | 250000383 | Torx Screw M8 X 60, Scotch Grip Package XDSXRS | 4 |
| 708300563 | WASHER Package XDSXRS | ||
| 4 | 233281464 | Elastic Flange Nut M8 Package XDSXRS | 4 |
| 4 | 233201416 | Hex. Flange Elastic Nut M10 Package XDSXRS | 4 |
| 4 | 207609046 | Hex. Flange Screw M10 X 90 Package XDSXRS | 4 |
| 2 | 250000234 | Torx Screw M6 X 20, Stainless Package XDSXRS | 2 |
| 2 | 233261494 | Hex. Elastic Flange Nut M6 Package XDSXRS | 2 |
| 2 | 250000761 | Torx Truss Screw M8 X 50 Package XDSXRS | 2 |
| 2 | 234082410 | Flat Washer 8 mm Package XDSXRS | 2 |
| 2 | 233281464 | Elastic Flange Nut M8 Package XDSXRS | 2 |
| 3 | 233261416 | Elastic Flange Nut M6 X 1.0 | 3 |
| 4 | 250200154 | Washer | 4 |
