Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXX | Not Available As Spare Parts | ||
| 2 | 207162544 | Hex. Screw M6 X 25 | 2 |
| 6 | 207662034 | Hex. Flange Screw M6 X 20 | 6 |
| 1 | 207662044 | Hex. Flange Screw M6 X 20 | 1 |
| 2 | 207682534 | Hex. Flange Screw M8 X 25 | 2 |
| 2 | 224060201 | Flat Washer | 2 |
| 2 | 224061201 | Flat Washer | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 1 | 233261494 | Hex. Elastic Flange Nut M6 | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 15 | 234062410 | Flat Washer 6 mm | 15 |
| 2 | 234062410 | Flat Washer 6 mm | 2 |
| 1 | 234062670 | Stainless Steel Flat Washer | 1 |
| 2 | 234082410 | Flat Washer 8 mm | 2 |
| 1 | 250000048 | Panel Nut M6 X 1.0 | 1 |
| 2 | 250000079 | Panel Nut M5 X 0.8 | 2 |
| 1 | 250000145 | Torx Screw M5 X 14 | 1 |
| 1 | 250000261 | Torx Screw M6 X 16 | 1 |
| 7 | 250000284 | Torx Screw M6 x 25 | 7 |
| 2 | 250000297 | Truss Head Torx Screw K50 X 20 | 2 |
| 11 | 250000712 | Torx Screw M6 X 20 | 11 |
| 3 | 250000398 | Torx Truss Screw M6 X 30 | 3 |
| 4 | 250000630 | Torx Truss Screw M6 X 25 | 4 |
| 1 | 250000720 | Torx Screw K50 X 16 | 1 |
| 1 | 250000722 | Torx Screw M6 X 20 | 1 |
| 2 | 250000724 | Torx Screw M5 X 20 | 2 |
| 2 | 250000728 | Torx Screw M6 X 25 | 2 |
| 1 | 250200025 | Washer M5 | 1 |
| 2 | 250200040 | Flat Washer | 2 |
| 1 | 293150089 | Tuflok Plastic Rivet | 1 |
| 2 | 293250242 | Rubber Cover | 2 |
| 1 | 293250252 | Upper Seal | 1 |
| 1 | 293250253 | Bottom Seal | 1 |
| 1 | 293250318 | SEAL TRAY | 1 |
| 293450274 | Insert | ||
| 1 | 293830005 | Rubber Bumper | 1 |
| 3 | 414859400 | CAP | 3 |
| 1 | 503189273 | Washer | 1 |
| 2 | 506151252 | Washer | 2 |
| 1 | 517302785 | Edge Clip | 1 |
| 4 | 705003668 | Oblong Grommet | 4 |
| 2 | 705003841 | Support Plate | 2 |
| 715002190 | CENTRAL CONSOLE ASS'Y | ||
| 1 | 707900001 | LH Side Console | 1 |
| 1 | 707900002 | RH Side Console | 1 |
| 1 | 707900004 | RH Front Floor | 1 |
| 1 | 707900006 | RH Under Seat Plate | 1 |
| 1 | 707900046 | Storage Bin | 1 |
| 1 | 707900011 | Passenger Handle | 1 |
| 1 | 715001250 | Dashboard Ass'y | 1 |
| 1 | 707900221 | Luggage Cover Kit | 1 |
| 1 | 707900098 | RH Fixe Side Console | 1 |
| 1 | 707900022 | LH Lower Floor | 1 |
| 1 | 707900023 | RH Lower Floor | 1 |
| 1 | 707900029 | SUPPORT_PANEL LH | 1 |
| 1 | 707900030 | SUPPORT_PANEL RH | 1 |
| 1 | 707900031 | Latch | 1 |
| 2 | 707900036 | Cup Retainer | 2 |
| 1 | 707900062 | Trim Glove Box | 1 |
| 1 | 707900042 | REAR CENTRAL CONSOLE FOAM | 1 |
| 1 | 707900043 | LH Upper Lateral Console Foam | 1 |
| 1 | 707900044 | LH Lower Lateral Console Foam | 1 |
| 1 | 707900045 | RH Lateral Console Foam | 1 |
| 1 | 707900048 | Connector Tube | 1 |
| 1 | 219704365 | Was 293200017 Neoprene Seal | 1 |
| 1 | 707900055 | RH Lateral Console Foam | 1 |
| 1 | 707900056 | RH Lateral Console Foam | 1 |
| 1 | 715002187 | Central Dashboard Ass'y | 1 |
| 1 | 707900066 | Gauge Support | 1 |
| 1 | 707900070 | Lever Indicator | 1 |
| 1 | 707900192 | Deflector | 1 |
| 1 | 219704353 | Was 271000110 Protection Trim | 1 |
| 1 | 715002356 | LH Under Seat Plate Kit | 1 |
| 1 | 707900133 | Insert | 1 |
| 1 | 707900145 | Heat Sheet | 1 |
| 1 | 707900146 | Heat Sheet | 1 |
| 1 | 707900147 | Heat Sheet | 1 |
| 1 | 707900148 | Heat Sheet | 1 |
| 1 | 707900149 | Heat Sheet | 1 |
| 1 | 707900150 | Heat Sheet | 1 |
| 1 | 707900151 | Heat Sheet | 1 |
| 1 | 707900165 | DEFLECTOR_BODY PANEL REAR L | 1 |
| 1 | 707900166 | DEFLECTOR_BODY PANEL REAR R | 1 |
| 1 | 707900167 | Heat Shield | 1 |
| 1 | 707900171 | LH Safety Net | 1 |
| 1 | 707900172 | RH Safety Net | 1 |
| 1 | 707900178 | Grille | 1 |
| 1 | 707900180 | Grille | 1 |
| 1 | 707900181 | LH Front Floor | 1 |
| 1 | 707900182 | Heat Shield | 1 |
| 1 | 707900183 | Heat Shield | 1 |
| 1 | 707900184 | Heat Shield | 1 |
| 1 | 707900190 | Heat Sheet | 1 |
| 1 | 707900191 | Heat Sheet | 1 |
| 1 | 707900193 | Front Side Dash Panel | 1 |
| 1 | 707900214 | Front Central Console Foam | 1 |
| 3 | 732610072 | Push Nut | 3 |
