Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4 | 15772-292-010 | CLIP, BREATHER TUBE | 4 |
| 1 | 15772-551-000 | CLIP, BREATHER TUBE | 1 |
| 17210-MAW-760 | HOUSING, AIR CLEANER (SOURCE: VINTAGE PARTS INC.) | ||
| 17210-MS6-920 | HOUSING, AIR CLEANER | ||
| 17210-MS8-000 | HOUSING, AIR CLEANER | ||
| 17213-MM9-300 | SEAL, ELEMENT | ||
| 17217-MF5-000 | SEAL, AIR CLEANER CAP | ||
| 17221-MM9-670 | STAY, SUB-AIR CLEANER HOUSING | ||
| 17222-MM9-670 | TUBE, R. SUB-AIR CLEANER (SOURCE: VINTAGE PARTS INC.) | ||
| 17223-MM9-670 | TUBE, L. SUB-AIR CLEANER | ||
| 17227-MM9-000 | BAND, AIR CLEANER | ||
| 17228-MM9-000 | BAND, AIR CLEANER CONNECTING | ||
| 17230-MM9-000 | ELEMENT, AIR CLEANER | ||
| 17240-MM9-000 | TRAP, FLAME | ||
| 17241-MS8-700 | DUCT, AIR CLEANER IN. | ||
| 2 | 17251-KT8-000 | CASE, SUB-AIR CLEANER | 2 |
| 17252-KT8-000 | COVER, SUB-AIR CLEANER | ||
| 2 | 17253-KT8-000 | FILTER, SUB-AIR CLEANER | 2 |
| 17253-MM9-000 | CHAMBER, AIR CLEANER | ||
| 3 | 17256-358-000 | BAND B, AIR CLEANER CONNECTING TUBE | 3 |
| 3 | 17256-425-010 | BAND ASSY., AIR CLEANER CONNECTING TUBE | 3 |
| 3 | 95018-60250 | BAND, AIR CLEANER CONNECTING TUBE (60) | 3 |
| 17257-MAW-760 | TUBE, MAIN CONNECTING (SOURCE: VINTAGE PARTS INC.) | ||
| 17257-MM9-000 | TUBE, MAIN CONNECTING | ||
| 17258-MM9-670 | TUBE, R. CONNECTING | ||
| 17259-MM9-670 | TUBE, L. CONNECTING | ||
| 1 | 17316-611-000 | CLIP, BREATHER TUBE | 1 |
| 17357-MM9-000 | TUBE B, DRAIN | ||
| 1 | 17358-HA0-680 | TUBE, DRAIN | 1 |
| 1 | 17358-HM8-000 | TUBE, DRAIN | 1 |
| 17358-MM9-000 | TUBE, OIL BREATHER | ||
| 1 | 17370-382-870 | PLUG, BREATHER TUBE | 1 |
| 1 | 17611-MB1-000 | CUSHION, FR. FUEL TANK | 1 |
| 2 | 17724-102-700 | CLIP, SUB-TANK HOSE | 2 |
| 33118-MC7-000 | COLLAR | ||
| 1 | 61104-MA6-720 | COLLAR | 1 |
| 1 | 61104-357-000 | COLLAR, FR. FENDER | 1 |
| 1 | 61104-428-000 | COLLAR, FR. FENDER | 1 |
| 2 | 90501-MC4-000 | COLLAR A, AIR CLEANER HOUSING | 2 |
| 2 | 90505-MC4-000 | GROMMET A, AIR CLEANER HOUSING | 2 |
| 2 | 90522-028-000 | WASHER, CHAIN CASE SETTING | 2 |
| 91462-393-780 | CLIP, TUBE | ||
| 1 | 91463-393-780 | JOINT, TUBE | 1 |
| 2 | 92101-06014-0A | BOLT, HEX. (6X14) | 2 |
| 3 | 93500-04025-0A | SCREW, PAN (4X25) | 3 |
| 2 | 93500-05025-0A | SCREW, PAN (5X25) | 2 |
| 3 | 93891-06012-07 | SCREW-WASHER (6X12) | 3 |
| 1 | 95002-01160 | CLIP, TUBE (A16) | 1 |
| 95003-37006-31 | TUBE, VINYL (11X15X60) (95003-37001-60M) (NA USE ALT:95003-37001-60M) | ||
| 1 | 95701-06010-00 | BOLT, FLANGE (6X10) | 1 |
| 2 | 95701-06020-08 | BOLT, FLANGE (6X20) | 2 |
| 95800-06012-08 | BOLT, FLANGE (6X12) (NA USE ALT:95700-06012-08) | ||
| 96300-06020-07 | BOLT, FLANGE (6X20) (SOURCE: VINTAGE PARTS INC.) | ||
| 96500-06020-07 | BOLT, FLANGE (6X20) |
