Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4 | 230602546 | Hex. Flange Screw M10 X 125 | 4 |
| 2 | 250100047 | Hex. Castellated Nut M18 | 2 |
| 4 | 233201436 | Hex. Flange Elastic Nut M10 | 4 |
| 1 | 250000359 | Hex Flange Screw M12 x 16 | 1 |
| 1 | 250000615 | Screw-Hex.Flange M10 X 16 | 1 |
| 8 | 250100082 | Chrome Wheel Nut M10 X 1.25 Model-DPS | 8 |
| 8 | 250100100 | Black Wheel Nut M10 X 1.25 Model-XT CAMO | 8 |
| 8 | 250100082 | Chrome Wheel Nut M10 X 1.25 Model-XT Except CAMO | 8 |
| 2 | 250200049 | Spring Washer | 2 |
| 1 | 250200014 | Flat Washer M10 | 1 |
| 8 | 250300051 | Wheel Stud Model-COM-MAX | 8 |
| 2 | 250400036 | Cotter Pin | 2 |
| 2 | 293000110 | Valve Cap | 2 |
| 1 | 250200102 | Flat Washer M12 | 1 |
| 2 | 293350040 | Cone Bearing | 2 |
| 2 | 293370019 | Circlip | 2 |
| 1 | 293650138 | Oetiker Gear Clamp 44.0MM | 1 |
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 1 | 414227300 | Clip | 1 |
| 1 | 705400036 | Wear Ring | 1 |
| 705400520 | WHEEL CAP Model-DPS | ||
| 2 | 705400504 | WHEEL CAP Model-XT CAMO | 2 |
| 705400520 | WHEEL CAP Model-XT Except CAMO | ||
| 1 | 705400193 | Rim Valve With Cap | 1 |
| 1 | 705502019 | Rear Tire Model-DPS | 1 |
| 1 | 705502019 | Rear Tire Model-XT North America Except CAMO | 1 |
| 1 | 705502019 | Rear Tire Model-XT CAMO | 1 |
| 1 | 705501295 | Rear Tire Model-XT Europe | 1 |
| 1 | 705502019 | Rear Tire Model-XT International Except CAMO | 1 |
| 1 | 705501121 | Wear Sleeve | 1 |
| 1 | 705501123 | Protector | 1 |
| 1 | 219704465 | 1/2 OZ Weight | 1 |
| 1 | 715900118 | Rubber Boot | 1 |
| 1 | 509000045 | Oetiker Gear Clamp 36.1MM | 1 |
| 2 | 705501481 | Half Shaft | 2 |
| 1 | 715900184 | Grease Fitting | 1 |
| 705501803 | Axle Ass'y | ||
| 1 | 705501804 | Rear Differential Ass'y | 1 |
| 1 | 705501874 | Needle Bearing | 1 |
| 1 | 705501875 | Ball Bearing | 1 |
| 1 | 705501876 | Ball Bearing | 1 |
| 1 | 705501877 | Ball Bearing | 1 |
| 1 | 705501878 | Oil Seal | 1 |
| 2 | 705501879 | Oil Seal | 2 |
| 1 | 705501880 | Oil Seal | 1 |
| 1 | 705501881 | Oil Seal iDIA 6.737 oDIA 6.943 | 1 |
| 1 | 705501882 | Nut | 1 |
| 1 | 705501885 | Drain Plug | 1 |
| 4 | 705501886 | Bolt | 4 |
| 1 | 705501887 | Vent Valve | 1 |
| 1 | 705501889 | Fill Level Plug | 1 |
| 2 | 705501900 | Wheel Hub | 2 |
| 1 | 705600459 | Clamp | 1 |
| 2 | 715500371 | Universal Joint | 2 |
| 1 | 715900233 | FIXED YOKE | 1 |
| 1 | 715900129 | Fixed Joint | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 705501812 | RIM 14 INCH X 8,5 Model-DPS | 1 |
| 1 | 705501812 | RIM 14 INCH X 8,5 Model-XT North America Except CAMO | 1 |
| 1 | 705501814 | Rear Rim Model-XT CAMO | 1 |
| 1 | 705501812 | RIM 14 INCH X 8,5 Model-XT Europe | 1 |
| 1 | 705501812 | RIM 14 INCH X 8,5 Model-XT International Except CAMO | 1 |
| 1 | 705501776 | CV Joint | 1 |
| 705501780 | PLUNGING JOINT | ||
| 1 | 705501781 | Circlip | 1 |
| 1 | 715900241 | Oetiker Clamp, 82.1 mm | 1 |
| 1 | 715900242 | Oetiker Clamp, 27.3 mm | 1 |
| 2 | 705501864 | Boot Kit | 2 |
| 1 | 715900106 | Spline Yoke | 1 |
