Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4 | 230602546 | Hex. Flange Screw M10 X 125 | 4 |
| 2 | 250100047 | Hex. Castellated Nut M18 | 2 |
| 4 | 233201416 | Hex. Flange Elastic Nut M10 | 4 |
| 250000378 | HEX FLANGED SCREW M12 X 16, SCOTCH GRIP | ||
| 1 | 250000359 | Hex Flange Screw M12 x 16 | 1 |
| 16 | 250000435 | Hex. Flange Screw M6 X 25 X Black EUR | 16 |
| 16 | 250000435 | Hex. Flange Screw M6 X 25 X Carbon Fiber | 16 |
| 8 | 250100042 | Steel Wheel Nut | 8 |
| 8 | 250100082 | Chrome Wheel Nut M10 X 1.25 XT, DPS | 8 |
| 8 | 250100082 | Chrome Wheel Nut M10 X 1.25 DPS | 8 |
| 8 | 250100082 | Chrome Wheel Nut M10 X 1.25 XT Except CAMO | 8 |
| 8 | 250100100 | Black Wheel Nut M10 X 1.25 XT CAMO | 8 |
| 8 | 250100100 | Black Wheel Nut M10 X 1.25 X | 8 |
| 2 | 250200049 | Spring Washer | 2 |
| 2 | 250200102 | Flat Washer M12 | 2 |
| 4 | 250300045 | Wheel Stud | 4 |
| 2 | 250400036 | Cotter Pin | 2 |
| 2 | 293000110 | Valve Cap Except X | 2 |
| 293000111 | VALVE CAP X | ||
| 2 | 293350040 | Cone Bearing | 2 |
| 2 | 293370019 | Circlip | 2 |
| 2 | 293650138 | Oetiker Gear Clamp 44.0MM | 2 |
| 1 | 390402200 | Pop Rivet 3/16" | 1 |
| 8 | 715900102 | SNAP RING | 8 |
| 2 | 715900186 | U-Joint | 2 |
| 2 | 715900184 | Grease Fitting | 2 |
| 1 | 509000045 | Oetiker Gear Clamp 36.1MM | 1 |
| 2 | 705400504 | WHEEL CAP XT CAMO | 2 |
| 705400520 | WHEEL CAP XT, DPS | ||
| 705400520 | WHEEL CAP DPS | ||
| 705400520 | WHEEL CAP XT Except CAMO | ||
| 1 | 705400872 | VALVE_TIRE WITH CAP FORMED X Black EUR | 1 |
| 1 | 705400872 | VALVE_TIRE WITH CAP FORMED X Carbon Fiber | 1 |
| XXX | Not Available As Spare Parts | ||
| 2 | 705400921 | Wheel Cap STD | 2 |
| 1 | 705400193 | Rim Valve With Cap | 1 |
| 1 | 705400193 | Rim Valve With Cap DPS | 1 |
| 1 | 705400193 | Rim Valve With Cap XT CAMO | 1 |
| 1 | 705400193 | Rim Valve With Cap XT Europe | 1 |
| 705401247 | BEAD LOCK B-160 X Carbon Fiber | ||
| 1 | 705401248 | REINFORCEMENT DISC PLATE X Black Europe | 1 |
| 1 | 705500504 | Fill Level Plug | 1 |
| 1 | 705500506 | Copper Washer | 1 |
| 1 | 705500894 | Drain Plug | 1 |
| 1 | 705501724 | Plug Drain Europe | 1 |
| 1 | 705500964 | Rear Tire XT, DPS Model | 1 |
| 1 | 705500964 | Rear Tire DPS | 1 |
| 1 | 705500964 | Rear Tire XT CAMO | 1 |
| 1 | 705501295 | Rear Tire XT Europe | 1 |
| 1 | 705500965 | Silver Rear Rim XT, DPS | 1 |
| 1 | 705500965 | Silver Rear Rim DPS | 1 |
| 1 | 705500965 | Silver Rear Rim XT Europe | 1 |
| 1 | 705501261 | Black Rear Rim XT CAMO | 1 |
| 1 | 705501121 | Wear Sleeve | 1 |
| 1 | 705501123 | Protector | 1 |
| 2 | 705501124 | Wear Ring | 2 |
| 1 | 705501129 | Rear Tire STD | 1 |
| 1 | 705501434 | Rear Tire STD Europe | 1 |
| 1 | 705501137 | Rear Rim X Black Europe | 1 |
| 1 | 705501137 | Rear Rim X Carbon Fiber | 1 |
| 1 | 705501186 | Rear Tire X Carbon Fiber | 1 |
| 1 | 705501494 | TIRE_27X11R12 REAR X Black Europe | 1 |
| 1 | 705501623 | Black, Rear Rim | 1 |
| 1 | 705501257 | Drive Axle Ass'y | 1 |
| 1 | 715900118 | Rubber Boot | 1 |
| 1 | 715900101 | Fixe Yoke | 1 |
| 1 | 705501373 | Fixed Joint | 1 |
| 1 | 219704465 | 1/2 OZ Weight | 1 |
| 1 | 705501542 | LH Rear Cover Europe | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 2 | 705501481 | Half Shaft | 2 |
| 2 | 705501776 | CV Joint | 2 |
| 705501780 | PLUNGING JOINT | ||
| 2 | 705501781 | Circlip | 2 |
| 2 | 705501777 | Rubber Boot Kit | 2 |
| 2 | 715900242 | Oetiker Clamp, 27.3 mm | 2 |
| 2 | 715900241 | Oetiker Clamp, 82.1 mm | 2 |
| 1 | 705501541 | RH Rear Cover Europe | 1 |
| 703500834 | Pinion 10 Tooth Kit Europe | ||
| 1 | 705501713 | LH Wheel Hub Assembly | 1 |
| XXXX | Not Available As Spare Part - Pinion 36 Tooth Kit Europe | ||
| 1 | 705600459 | Clamp | 1 |
| 1 | 715900106 | Spline Yoke | 1 |
| 1 | 705501549 | Nut Europe | 1 |
| 1 | 705501550 | Nut Europe | 1 |
| 1 | 705501554 | O-Ring Europe | 1 |
| 1 | 703500835 | Differential Shim Kit Europe | 1 |
| 2 | 705501556 | Oil Seal Europe | 2 |
| 1 | 705501557 | Oil Seal Europe | 1 |
| 4 | 705501562 | Bolt Europe | 4 |
| 1 | 705501584 | Breather Tube Europe | 1 |
| 1 | 705501711 | O-Ring Europe | 1 |
| 1 | 703500836 | Needle Bearing Ass'y Europe | 1 |
| 1 | 705501723 | Rear Differential Ass'y Europe | 1 |
