Интерактивное демо базы запчастей
Просматривайте запчасти для ATV, мотоциклов, снегоходов, водных моторов и другой техники по марке, году и модели. Каталог доступен для покупки в виде базы данных SQL с изображениями или для аренды.
Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 207582044 | Hex. Flange Screw M8 X 20, Scotch Grip | 2 |
| 2 | 230602546 | Hex. Flange Screw M10 X 125 | 2 |
| 2 | 250100047 | Hex. Castellated Nut M18 | 2 |
| 2 | 233201416 | Hex. Flange Elastic Nut M10 | 2 |
| 250000378 | HEX FLANGED SCREW M12 X 16, SCOTCH GRIP | ||
| XXX | Not Available As Spare Parts | ||
| 8 | 250100042 | Steel Wheel Nut STD Model | 8 |
| 8 | 250100100 | Black Wheel Nut M10 X 1.25 XT Model Camo | 8 |
| 8 | 250100082 | Chrome Wheel Nut M10 X 1.25 XT Model | 8 |
| 2 | 250200049 | Spring Washer | 2 |
| 2 | 250200102 | Flat Washer M12 | 2 |
| 2 | 250400036 | Cotter Pin | 2 |
| 2 | 293000110 | Valve Cap | 2 |
| 2 | 293250246 | O-Ring | 2 |
| 2 | 293350040 | Cone Bearing | 2 |
| 2 | 293350044 | Ball Bearing | 2 |
| 2 | 293370019 | Circlip | 2 |
| 1 | 293650138 | Oetiker Gear Clamp 44.0MM | 1 |
| 715900067 | GREASE FITTING | ||
| 2 | 703000024 | Unit Pack Kit | 2 |
| 1 | 705400027 | Oil Seal | 1 |
| 1 | 705400036 | Wear Ring | 1 |
| 2 | 705400042 | CIRCLIP | 2 |
| XXXX | Not Available As Spare Part - Circlip | ||
| 1 | 703500288 | Differential Shim Spool Kit | 1 |
| 1 | 703500050 | Differential Shim Spool Kit | 1 |
| XXXX | Not Available As Spare Part - Wear Ring | ||
| 1 | 705400512 | Differential Boot Kit | 1 |
| 4 | 293650192 | OETIKER CLAMP 23MM | 4 |
| 2 | 715900139 | OETIKER CLAMP 71,1MM | 2 |
| 2 | 293650193 | OETIKER CLAMP 67MM | 2 |
| 2 | 705400504 | WHEEL CAP XT Model Camo | 2 |
| 705400520 | WHEEL CAP XT Model | ||
| 1 | 705400632 | Silver Front Rim XT Model | 1 |
| 1 | 705400919 | Black Front Rim XT Model Camo | 1 |
| 1 | 705400632 | Silver Front Rim XT Model Europe | 1 |
| 1 | 705500348 | Fix Joint | 1 |
| 1 | 705400637 | Drive Axle Ass'y | 1 |
| 705400782 | FIX JOINT | ||
| 705500762 | Slip Joint | ||
| 1 | 705400645 | Differential | 1 |
| 1 | 705400661 | Nut | 1 |
| 2 | 705400713 | Wheel Hub | 2 |
| 1 | 705400762 | FRONT COVER | 1 |
| 2 | 705400780 | Wear Sleeve | 2 |
| 705400781 | TIRE_27X9R12 F STD Model | ||
| 2 | 705401046 | Front Tire STD Europe Model | 2 |
| 8 | 705400791 | Wheel Stud | 8 |
| 1 | 705400631 | Front Tire XT Model | 1 |
| 1 | 705400961 | Front Tire XT Model Europe | 1 |
| 1 | 705400910 | RIM_12 INCH X 6 STD Model | 1 |
| 1 | 705400910 | RIM_12 INCH X 6 STD Model Europe | 1 |
| 2 | 705400921 | Wheel Cap STD Model | 2 |
| 1 | 705500907 | Wheel Boot Kit | 1 |
| 1 | 705400193 | Rim Valve With Cap | 1 |
| 705401136 | FRONT COVER | ||
| 1 | 705401147 | LH Knuckle | 1 |
| 703500789 | RH KNUCKLE | ||
| 2 | 705500255 | Oil Seal | 2 |
| 2 | 705500259 | Ball Bearing | 2 |
| 1 | 705500260 | Ball Bearing | 1 |
| 1 | 705500265 | Seal | 1 |
| 1 | 705500267 | O-Ring | 1 |
| 1 | 705500504 | Fill Level Plug | 1 |
| 1 | 705500506 | Copper Washer | 1 |
| 6 | 705500892 | SCREW | 6 |
| 1 | 705500893 | VENT VALVE | 1 |
| 2 | 705500894 | Drain Plug | 2 |
| 705501238 | CV Joint | ||
| 703500255 | Rubber Boot Kit Includes Parts With + | ||
| 1 | 219704465 | 1/2 OZ Weight | 1 |
| 1 | 705501408 | Needle Bearing | 1 |
| 1 | 705501570 | 10 Teeth Pinion | 1 |
| 1 | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1 | 705400952 | RH CV Joint Ass'y | 1 |
| 1 | 705400953 | LH CV Joint Ass'y | 1 |
| 1 | 705401135 | Front Differential Ass'y Includes Parts With * | 1 |
| 1 | 703500049 | Pinion Shim Kit | 1 |
| 705500075 | Pinion Gear Shim .022" | ||
| 1 | 705501162 | Pinion Gear Shim | 1 |
| 2 | 207605044 | Hex. Flange Screw M10 X 50 | 2 |
| 2 | 233201414 | Hex. Flange Elastic Nut M10 | 2 |
