Каталог / Side x Side / Can-Am / 2012 / Commander STD, XT, X, 1000 EFI / Drive System, Front Std, Xt, X

Список запчастей

№	Артикул	Название	Кол-во
2	207582044	Hex. Flange Screw M8 X 20, Scotch Grip	2
2	230602546	Hex. Flange Screw M10 X 125	2
2	250100047	Hex. Castellated Nut M18	2
2	233201416	Hex. Flange Elastic Nut M10	2
1	250000359	Hex Flange Screw M12 x 16	1
	250000378	HEX FLANGED SCREW M12 X 16, SCOTCH GRIP
16	250000435	Hex. Flange Screw M6 X 25 X Model	16
16	250000435	Hex. Flange Screw M6 X 25 X Model Europe	16
8	250100042	Steel Wheel Nut STD Model	8
8	250100100	Black Wheel Nut M10 X 1.25 XT Model Camo	8
8	250100100	Black Wheel Nut M10 X 1.25 X Model	8
8	250100082	Chrome Wheel Nut M10 X 1.25 XT Model	8
2	250200049	Spring Washer	2
1	250200102	Flat Washer M12	1
2	250400036	Cotter Pin	2
2	293000110	Valve Cap	2
	293000111	VALVE CAP X Model
2	293250246	O-Ring	2
2	293350040	Cone Bearing	2
2	293350044	Ball Bearing	2
2	293370019	Circlip	2
1	293650138	Oetiker Gear Clamp 44.0MM	1
	715900067	GREASE FITTING
2	703000024	Unit Pack Kit	2
1	705400027	Oil Seal	1
1	705400036	Wear Ring	1
2	705400042	CIRCLIP	2
	XXXX	Not Available As Spare Part - Circlip
1	703500288	Differential Shim Spool Kit	1
1	703500050	Differential Shim Spool Kit	1
	XXXX	Not Available As Spare Part - Wear Ring
1	705400512	Differential Boot Kit	1
4	293650192	OETIKER CLAMP 23MM	4
2	715900139	OETIKER CLAMP 71,1MM	2
2	293650193	OETIKER CLAMP 67MM	2
2	705400504	WHEEL CAP XT Model Camo	2
	705400520	WHEEL CAP XT Model
1	705400632	Silver Front Rim XT Model	1
1	705400919	Black Front Rim XT Model Camo	1
1	705400632	Silver Front Rim XT Model Europe	1
1	705500348	Fix Joint	1
1	705400637	Drive Axle Ass'y	1
	705400782	FIX JOINT
	705500762	Slip Joint
1	705400645	Differential	1
1	705400661	Nut	1
2	705400713	Wheel Hub	2
1	705400762	FRONT COVER	1
2	705400780	Wear Sleeve	2
	705400781	TIRE_27X9R12 F STD Model
2	705401046	Front Tire STD Model Europe	2
8	705400791	Wheel Stud	8
1	705400841	Reinforcement Disk X Model	1
2	705400846	Front Tire X Model	2
2	705401130	TIRE_27X9R12 F X Model Europe	2
2	705400631	Front Tire XT Model	2
2	705400631	Front Tire XT Model Camo	2
2	705400961	Front Tire XT Model Europe	2
2	705400872	VALVE_TIRE WITH CAP FORMED X Model	2
2	705400872	VALVE_TIRE WITH CAP FORMED X Model Europe	2
2	705400910	RIM_12 INCH X 6 STD Model	2
2	705400910	RIM_12 INCH X 6 STD Model Europe	2
2	705400921	Wheel Cap STD Model	2
1	705400945	Front Rim X Model	1
1	705400945	Front Rim X Model Europe	1
1	705500907	Wheel Boot Kit	1
1	705400193	Rim Valve With Cap	1
	705401136	FRONT COVER
1	705401147	LH Knuckle	1
	703500789	RH KNUCKLE
2	705500255	Oil Seal	2
2	705500259	Ball Bearing	2
1	705500260	Ball Bearing	1
1	705500265	Seal	1
1	705500267	O-Ring	1
1	705500504	Fill Level Plug	1
1	705500506	Copper Washer	1
6	705500892	SCREW	6
1	705500893	VENT VALVE	1
2	705500894	Drain Plug	2
	705501238	CV Joint
	703500255	Rubber Boot Kit Includes Parts With +
1	219704465	1/2 OZ Weight	1
1	219704465	1/2 OZ Weight XT Model	1
1	219704465	1/2 OZ Weight X Model	1
1	705501408	Needle Bearing	1
1	705501570	10 Teeth Pinion	1
1	219704410	Polyurethane Hose 10000Mm Long	1
1	705400952	RH CV Joint Ass'y	1
1	705400953	LH CV Joint Ass'y	1
1	705401135	Front Differential Ass'y Includes Parts With *	1
1	703500049	Pinion Shim Kit	1
	705500075	Pinion Gear Shim .022"
1	705501162	Pinion Gear Shim	1
2	207605044	Hex. Flange Screw M10 X 50	2
2	233201414	Hex. Flange Elastic Nut M10	2
