Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705003030 | LH Front Fender, Yellow Yellow Models | 1 |
| 1 | 705003826 | LH Front Fender, Red Red Models | 1 |
| 1 | 705004376 | LH Front Fender, Camo Camo Models | 1 |
| 1 | 705004378 | LH Front Fender, Black Black Models | 1 |
| 1 | 705003029 | RH Front Fender, Yellow Yellow Models | 1 |
| 705003827 | RH FRONT FENDER, RED Red Models | ||
| 1 | 705004375 | RH Front Fender, Camo Camo Models | 1 |
| 1 | 705004377 | RH Front Fender, Black Black Models | 1 |
| 2 | 293150104 | Pop Rivet 3/16" | 2 |
| 1 | 517303756 | Grommet | 1 |
| 1 | 705004337 | Yellow CVT Inlet Cover Yellow Models | 1 |
| 1 | 705004381 | RED CVT INLET COVER Red Models | 1 |
| 1 | 705004382 | CAMO CVT INLET COVER Camo Models | 1 |
| 1 | 705004383 | CVT INLET COVER, BLACK Black Models | 1 |
| 2 | 293150089 | Tuflok Plastic Rivet | 2 |
| 12 | 705003841 | Support Plate | 12 |
| 10 | 517302785 | Edge Clip | 10 |
| 2 | 250000048 | Panel Nut M6 X 1.0 | 2 |
| 2 | 207662044 | Hex. Flange Screw M6 X 20 | 2 |
| 1 | 705002915 | Yellow Fixed Hood Yellow Models, Black Models | 1 |
| 1 | 705004379 | Red Fixed Hood Red Models | 1 |
| 1 | 705004380 | HOOD B-005 Camo Models | 1 |
| 4 | 293150104 | Pop Rivet 3/16" | 4 |
| 5 | 250000146 | Truss Head Torx Screw K50 X 16 | 5 |
| 5 | 234062670 | Stainless Steel Flat Washer | 5 |
| 1 | 705002881 | Removable Hood, Yellow Yellow Models | 1 |
| 1 | 705004384 | Removable Hood, Red Red Models | 1 |
| 1 | 705004385 | Removable Hood, Camo Camo Models | 1 |
| 1 | 705004386 | Removable Hood, Black Black Models | 1 |
| 2 | 705005156 | Oval Washer | 2 |
| 1 | 705003629 | FASCIA UP B-160 | 1 |
| 1 | 705004350 | LH Upper Facia Protector | 1 |
| 1 | 705004351 | RH Upper Facia Protector | 1 |
| 1 | 705004336 | Center Upper Facia Protector | 1 |
| 2 | 250000128 | Torx Truss Screw M6 X 20 | 2 |
| 2 | 234082410 | Flat Washer 8 mm | 2 |
| 1 | 705003306 | Front Facia | 1 |
| 1 | 705004755 | Lower Front Facia Protector | 1 |
| 1 | 705004819 | LH Lower Rear Facia Protector | 1 |
| 1 | 705004820 | RH Lower Rear Facia Protector | 1 |
| 11 | 517302785 | Edge Clip | 11 |
| 4 | 250000261 | Torx Screw M6 X 16 | 4 |
| 2 | 234062670 | Stainless Steel Flat Washer | 2 |
| 293450274 | Insert | ||
| 250000197 | Torx Truss Screw M8 X 30 Except XT Models | ||
| 2 | 232081414 | Hex. Nut M8 Except XT Models | 2 |
| 2 | 234081410 | Flat Washer 8 mm Except XT Models | 2 |
| 1 | 705003399 | Bottom Deflector Except XT Models | 1 |
| 2 | 293150089 | Tuflok Plastic Rivet Except XT Models | 2 |
| 1 | 705002885 | LH Front Facia | 1 |
| 1 | 705002886 | RH Front Facia | 1 |
| 4 | 250000398 | Torx Truss Screw M6 X 30 | 4 |
| 4 | 232561434 | Elastic Stop Nut M6 | 4 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 2 | 705002891 | Facia Front Support | 2 |
| 4 | 250000297 | Truss Head Torx Screw K50 X 20 | 4 |
| 2 | 250000146 | Truss Head Torx Screw K50 X 16 | 2 |
| 4 | 207661644 | Hex. Flange Screw M6 X 16 | 4 |
| 4 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 4 |
| 4 | 234061600 | Stainless Flat Washer M6 | 4 |
| 2 | 705002409 | Amber Reflector Except Europe | 2 |
| 2 | 233251414 | Hex. Flange Elastic Nut M5 Except Europe | 2 |
| 1 | 705003627 | LH FLASHER CAP Europe | 1 |
| 1 | 705003628 | RH Flasher Cap Europe | 1 |
| 2 | 250000146 | Truss Head Torx Screw K50 X 16 Europe | 2 |
| 2 | 389804300 | Push Nut Europe | 2 |
| 1 | 705002887 | Yellow LH Front Lateral Pannel Yellow Models | 1 |
| 1 | 705003847 | LH Front Lateral Pannel, Red Red Models | 1 |
| 705004389 | LH Front Lateral Pannel, Camo Camo Models | ||
| 1 | 705004391 | LH Front Lateral Pannel, Black Black Models | 1 |
| 1 | 705002888 | Yellow RH Front Lateral Pannel Yellow Models | 1 |
| 1 | 705003848 | RH Front Lateral Pannel, Red Red Models | 1 |
| 705004390 | RH Front Lateral Pannel, Camo Camo Models | ||
| 1 | 705004392 | RH Front Lateral Pannel, Black Black Models | 1 |
| 2 | 250000350 | Torx Truss Screw M6 X 20 | 2 |
| 2 | 250000350 | Torx Truss Screw M6 X 20 Except XT Models | 2 |
| 4 | 250000048 | Panel Nut M6 X 1.0 | 4 |
| 4 | 234051410 | Flat Washer M5 | 4 |
| 1 | 705002904 | LH Rear Lateral Pannel, Yellow Yellow Models | 1 |
| 1 | 705003850 | LH Rear Lateral Pannel, Red Red Models | 1 |
| 1 | 705004396 | LH Rear Lateral Pannel, Camo Camo Models | 1 |
| 1 | 705004398 | LH Rear Lateral Pannel, Black Black Models | 1 |
| 1 | 705002905 | RH Rear Lateral Pannel, Yellow Yellow Models | 1 |
| 1 | 705003851 | RH Rear Lateral Pannel, Red Red Models | 1 |
| 1 | 705004395 | RH Rear Lateral Pannel, Camo Camo Models | 1 |
| 1 | 705004397 | RH Rear Lateral Pannel, Black Black Models | 1 |
| 2 | 250000398 | Torx Truss Screw M6 X 30 | 2 |
| 1 | 250000215 | Torx Screw M6 X 45 | 1 |
| 3 | 250000048 | Panel Nut M6 X 1.0 | 3 |
| 4 | 250100129 | PUSH NUT | 4 |
| 2 | 705004261 | Support Plate | 2 |
| 4 | 250000146 | Truss Head Torx Screw K50 X 16 | 4 |
| 1 | 705003318 | LH Central Lateral Pannel STD | 1 |
| 1 | 705003938 | LH Central Lateral Pannel XT | 1 |
| 705004355 | LH Central Lateral Pannel X | ||
| 705003319 | RH Central Lateral Pannel STD | ||
| 1 | 705003939 | RH Central Lateral Pannel XT | 1 |
| 705004356 | RH Central Lateral Pannel X | ||
| 8 | 293150104 | Pop Rivet 3/16" | 8 |
| 715001013 | FENDER EXTENSION KIT Includes 80 to 87 | ||
| 40 | 250000398 | Torx Truss Screw M6 X 30 | 40 |
| 41 | 234062670 | Stainless Steel Flat Washer | 41 |
| 41 | 232561434 | Elastic Stop Nut M6 | 41 |
| 1 | 250000350 | Torx Truss Screw M6 X 20 | 1 |
| 1 | 706200281 | Hardened Washer | 1 |
| 705003513 | LH SKID PLATE | ||
| 1 | 705003514 | RH Skid Plate | 1 |
| 1 | 705003624 | Rear Skid Plate | 1 |
| 24 | 705004510 | Cup | 24 |
| 24 | 210262080 | Hex. Forming Screw M6 X 20 | 24 |
| 1 | 705002895 | LH Deflector Except XT Models | 1 |
| 1 | 705005113 | LH Deflector XT | 1 |
| 1 | 705002894 | RH Deflector | 1 |
| 6 | 293720053 | Grommet | 6 |
| 4 | 517303439 | Knob | 4 |
| 2 | 708000759 | Rubber Stopper | 2 |
