Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 47110-24B00-13Z | COVER, FRAME RH (BLACK) MODEL G | ||
| 47100-24B00-37X | COVER, FRAME RH (BLACK) MODEL M/N/P | ||
| 47110-24B00-00J | COVER, FRAME RH (RED) MODEL G | ||
| 47110-24B00-24V | COVER, FRAME RH (BLUE) MODEL J/K/L | ||
| 47110-24B00-33D | COVER, FRAME RH (MAROON) MODEL J/K/L | ||
| 47100-24B00-1FX | COVER, FRAME RH (BLUE) MODEL M/N/P; Includes Item(s) 2 - 3 | ||
| 68131-24B00-23A | EMBLEM (GRAY) MODEL G FOR 13Z | ||
| 68131-24B00-22Z | EMBLEM (RED) FOR 00J,33DMODEL M/N/P FOR 37X | ||
| 68131-24B00-38W | EMBLEM (BLUE) MODEL J/K/L FOR 24VMODEL M/N/P FOR 1FX | ||
| 1 | 13719-84150 | PAD | 1 |
| 1 | 02142-05124 | SCREW | 1 |
| 1 | 02142-05164 | SCREW, LOWER | 1 |
| 1 | 08321-21055 | LOCK WASHER | 1 |
| 1 | 08322-21055 | WASHER | 1 |
| 47210-24B00-13Z | COVER, FRAME LH (BLACK) MODEL G | ||
| 47200-24B00-37X | COVER, FRAME LH (BLACK) MODEL M/N/P | ||
| 47210-24B00-00J | COVER, FRAME LH (RED) MODEL G | ||
| 47210-24B00-24V | COVER, FRAME LH (BLUE) MODEL J/K/L | ||
| 47210-24B00-33D | COVER, FRAME LH (MAROON) MODEL J/K/L | ||
| 47200-24B00-1FX | COVER, FRAME LH (BLUE) MODEL M/N/P; Includes Item(s) 9 - 9 | ||
| 68131-24B00-38W | EMBLEM (BLUE) MODEL J/K/L FOR 24VMODEL M/N/P FOR 33H | ||
| 1 | 47180-24B03 | BRACKET, FRAME COVER LH | 1 |
| 1 | 47117-45000 | CUSHION, LH | 1 |
| 2 | 02122-06125 | SCREW, BRACKET | 2 |
| 1 | 47430-24B01 | HOLDER, TOOL INNER | 1 |
| 1 | 47440-24B00 | HOLDER, TOOL OUTER MODEL G | 1 |
| 1 | 47440-24B10 | HOLDER, TOOL OUTER MODEL J/K/L/M/N/P; Includes Item(s) 16 - 17 | 1 |
| 2 | 47445-24B00 | MOLDING, TOOL HOLDER | 2 |
| 2 | 33652-38A10 | .PROTECTOR (20X90X2) | 2 |
| 2 | 02112-05105 | SCREW, LOWER MODEL G/J/K | 2 |
| 2 | 02112-15105 | SCREW, LOWER MODEL L/M/N/P | 2 |
| 2 | 08322-21055 | WASHER MODEL G/J/K | 2 |
| 1 | 02112-06108 | SCREW, UPPER | 1 |
| 68226-24B00 | LABEL, TOOL LOCK COVER | ||
| 1 | 95700-24B00-KEY | LOCK ASSY, TOOL HOLDER MODEL G/J/K/L | 1 |
| 1 | 95700-24870 | LOCK SET, TOOL HOLDER MODEL M/N/P | 1 |
| 1 | 47434-24B00 | PLATE, LOCK | 1 |
| 1 | 09800-00318 | TOOL ASSY MODEL G | 1 |
| 1 | 09800-00347 | TOOL ASSY MODEL J/K/L/M/N/P; Includes Item(s) 25 | 1 |
| 1 | 96220-24B00 | GUAGE ASSY, TENTION | 1 |
