Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 233251414 | Hex. Flange Elastic Nut M5 | 1 |
| 1 | 250000079 | Panel Nut M5 X 0.8 | 1 |
| XXX | Not Available As Spare Parts | ||
| 2 | 250000128 | Torx Truss Screw M6 X 20 | 2 |
| 1 | 250000465 | Torx Screw M5 X 20 | 1 |
| 250000498 | SQUARE NUT M6 | ||
| 2 | 250000501 | PHILLIPS SCREW M6 X 35 | 2 |
| 1 | 250000528 | Torx Screw M5 X 20 | 1 |
| 2 | 250000565 | Hexalob Screw M4 X 10 | 2 |
| 4 | 250000587 | Torx Screw M5 X 26 | 4 |
| 2 | 250100035 | Jack Nut M5 | 2 |
| 2 | 250100113 | Panel Nut, M6 X 1.0 | 2 |
| 2 | 250100156 | Weld Nut M4 | 2 |
| 6 | 250200024 | Rubber Washer 5 mm | 6 |
| 8 | 293150104 | Pop Rivet 3/16" | 8 |
| 1 | 293150108 | Pop Rivet 3/16” | 1 |
| 2 | 414644300 | Black, Dart | 2 |
| 8 | 517124300 | Washer | 8 |
| 2 | 517302841 | Grommet | 2 |
| 1 | 517303612 | RH Panel Latch | 1 |
| 3 | 517303756 | Grommet | 3 |
| 1 | 517303808 | LH Panel Latch | 1 |
| 1 | 517304221 | Latch Support | 1 |
| 1 | 517305039 | GREY RH WIND DEFLECTOR | 1 |
| 1 | 517305392 | CAN-AM RED RH WIND DEFLECTOR | 1 |
| 1 | 517305040 | GREY LH WIND DEFLECTOR | 1 |
| 1 | 517305393 | CAN-AM REDLH WIND DEFLECTOR | 1 |
| 1 | 517304518 | Console Nut | 1 |
| 1 | 517305369 | Red Center Hood | 1 |
| 1 | 517305386 | Can-Am Red Rear Console | 1 |
| 1 | 517305181 | Deep Black Rear Console | 1 |
| 1 | 517305397 | White Panel RH | 1 |
| 1 | 517304801 | Black Panel RH | 1 |
| 1 | 517304802 | Deep Black, Panel Trim RH | 1 |
| 1 | 517305405 | White LH Panel | 1 |
| 1 | 517304804 | Black LH Panel | 1 |
| 1 | 517304805 | Black, LH Flashing Panel | 1 |
| 1 | 517305384 | HOOD RH B-229 | 1 |
| 1 | 517305370 | Black Mat - RH Hood | 1 |
| 1 | 517305385 | HOOD LH B-229 | 1 |
| 1 | 517305371 | Black Mat - LH Hood | 1 |
| 1 | 517304912 | Deep Black, Upper Storage Access Cover | 1 |
| 1 | 517304917 | Cover Latch | 1 |
| 1 | 517304921 | Windshield 235mm | 1 |
| 1 | 517304922 | Deep Black, Windshield Support - Short | 1 |
| 1 | 517304923 | RH Air Deflec.Console, Black 63% Transm. | 1 |
| 1 | 517304924 | LH Air Deflec.Console, Black 63% Transm. | 1 |
| 1 | 517304935 | Deep Black, RH Panel Vent Grid | 1 |
| 1 | 517304970 | Deep Black, Console Support | 1 |
| 1 | 517305010 | Headlight Trim Cap | 1 |
| 1 | 860200712 | Grey Wind Deflector Kit | 1 |
| 860201036 | WIND DEFLECTOR KIT, RED | ||
| 1 | 517305090 | RH Rear Hood Foam | 1 |
| 1 | 517305091 | LH Rear Hood Foam | 1 |
| 1 | 517305095 | Deep Black, Trunk | 1 |
| 4 | 517305109 | Rivet Plate | 4 |
| 1 | 517305504 | Pin | 1 |
| 1 | 517305143 | Deep Black, LH Front Console | 1 |
| 1 | 517305147 | Deep Black, Support Console Cap | 1 |
| 1 | 517305148 | Deep Black, Support Console Cap | 1 |
| 2 | 517305157 | Seal Joint | 2 |
| 1 | 517305196 | RH Foam Upper | 1 |
| 1 | 517305197 | RH Foam Central | 1 |
| 1 | 517305198 | RH Foam Lower | 1 |
| 1 | 517305199 | RH Foam Rear | 1 |
| 1 | 517305200 | LH Upper Panel Foam | 1 |
| 1 | 517305201 | LH Center Panel Foam | 1 |
| 1 | 517305202 | LH Lower Panel Foam | 1 |
| 1 | 517305203 | LH Rear Panel Foam | 1 |
| 2 | 517305279 | Panel Latch | 2 |
| 1 | 517305493 | RH Clip | 1 |
| 1 | 517305494 | LH Clip | 1 |
| 1 | 517305497 | Headlamp | 1 |
| 1 | 517305511 | Deep Black, Indicator Support | 1 |
| 2 | 517305451 | Heat Shield | 2 |
| 1 | 250100158 | Push Nut | 1 |
| 2 | 219400070 | Cap | 2 |
| 2 | 515176274 | Halogen Bulb, 60/55 W, 12 V ( H4 ) | 2 |
| 2 | 219800282 | Holder Bracket | 2 |
