Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 710001103 | Voltage Regulator | 1 |
| 1 | 278003012 | Starter Relay | 1 |
| 1 | 410301203 | Battery YUASA YTX20L Includes 340 to 340 a | 1 |
| 1 | 250000282 | Battery Bolt Kit | 1 |
| 4 | 293150123 | Pop Rivet 3/16" | 4 |
| 1 | 278003473 | Battery Support | 1 |
| 1 | 293850095 | Fuel Tank Strap | 1 |
| 1 | 293650257 | Hose Clamp | 1 |
| 1 | 250000287 | Flange Torx Screw K40 X 16 | 1 |
| 2 | 232561200 | Brass Elastic Stop Nut M6 | 2 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 293750047 | Tie Rap, 533 mm | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 2 | 414115200 | Tie-Rap 180 mm | 2 |
| 1 | 278003420 | Wiring Harness Includes 1000 to 1000a | 1 |
| 1 | 278003517 | Housing | 1 |
| 1 | 295100710 | USB Charger Cable Ass'y Includes 1020 to 1020a | 1 |
| 1 | 710005857 | Connector USB wih Cable | 1 |
| 1 | 295100710 | USB Charger Cable Ass'y | 1 |
| 1 | 278003451 | Ground Battery Cable | 1 |
| 1 | 207361260 | Hex. Screw M6 X 12, Scotch Grip | 1 |
| 1 | 234061600 | Stainless Flat Washer M6 | 1 |
| 1 | 278003369 | Starter Cable | 1 |
| 1 | 232561200 | Brass Elastic Stop Nut M6 | 1 |
| 1 | 278002284 | LH Throttle Sensor | 1 |
| 3 | 207361260 | Hex. Screw M6 X 12, Scotch Grip | 3 |
| 3 | 234061600 | Stainless Flat Washer M6 | 3 |
| 1 | 295100711 | Audio System BlueTooth Includes 1400 to 1400g | 1 |
| 1 | 278003497 | Amplifier Harness | 1 |
| 1 | 278003462 | Speaker Harness | 1 |
| 1 | 278003465 | Audio Control | 1 |
| 1 | 278003464 | Amplifier | 1 |
| 2 | 278003463 | Speaker | 2 |
| 2 | 278003466 | Speaker Grille | 2 |
| 1 | 278003663 | Accoustic Speaker Enclosure Ass'y LH | 1 |
| 1 | 278003664 | Accoustic Speaker Enclosure Ass'y RH | 1 |
| 1 | 278003489 | LH Bracket | 1 |
| 1 | 278003518 | RH Bracket | 1 |
| 6 | 250000709 | Torx Screw M6.81 X 30 | 6 |
| 1 | 293730011 | Black, Dart | 1 |
| 3 | 278003564 | Retainer | 3 |
| 1 | 278003649 | LCD Gauge | 1 |
| 1 | 278002283 | Throttle Position Sensor | 1 |
| 1 | 278003476 | Switch | 1 |
| 1 | 278003604 | Switch | 1 |
| 1 | 278003634 | Steering Harness Ass'Y | 1 |
| 1 | 278003636 | Wiring Harness Extension | 1 |
| 1 | 515178225 | DESS Switch, RFID | 1 |
| 1 | 278002963 | Safety Nut (DESS Switch) | 1 |
| 1 | 211000023 | Hex. Screw 10-14 X 7/8” | 1 |
| 1 | 278003448 | Fuse Base Ass'y Includes 1805 to 1805a | 1 |
| 1 | 278003450 | Seal | 1 |
| 1 | 278003469 | Fuse Cover | 1 |
| 1 | 278003401 | Safety Lanyard Ass'y, Learning / RFID | 1 |
| 1 | 278003402 | Safety Lanyard Ass'y, RFID | 1 |
| 1 | 250000399 | Hexagonal Cap Screw M6 X35 | 1 |
