Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 61511075033 | Main wiring harness cmpl. NEW PART | 1 |
| 1 | 61511085000 | Engine wiring harness NEW PART | 1 |
| 1 | 61311059050 | BATTERY CABLE | 1 |
| 1 | 61311076100 | REAR WIRING HARNESS | 1 |
| 1 | 60711033050 | Rubber band NEW PART | 1 |
| 1 | 60711033000 | Control unit MCU 3.0 NEW PART | 1 |
| 1 | 61508018020 | MCU bracket NEW PART | 1 |
| 1 | 61508018010 | MCU bracket NEW PART | 1 |
| 3 | 0081050161 | EJOT PT SCREW K50X16 1451 NEW PART | 3 |
| 2 | 61111057000 | RELAY CM1A-R-12V-H80 07 | 2 |
| 1 | 60416031000 | ELECTRONIC CONTROL UNIT SAFE | 1 |
| 1 | 61041085100 | PRESSURE SENSOR 06 | 1 |
| 1 | 61041085150 | RUBBER SUPP. PRESSURE SENS. 06 | 1 |
| 1 | 61311087050 | RUBBER CASING FUSE BOX | 1 |
| 1 | 60311034000 | VOLTAGE REGULATOR | 1 |
| 2 | 0025060206 | HH collar screw M6x20 TX30 | 2 |
| 1 | 76211058000 | STARTER RELAY 07 | 1 |
| 2 | 0738060101 | COU.SUNK SCR. AH ISO7380 M6X10 | 2 |
| 1 | 60312032000 | RECEIVER AIR PRESSURE SENSOR | 1 |
| 1 | 61111018100 | TEMPERATURE SENSOR | 1 |
| 1 | 61412032040 | TPMS holder | 1 |
| 1 | 60414039000 | CONTROL UNIT CURVE LIGHT | 1 |
| 2 | 60316029000 | RUBBER EDS-CONTROL UNIT | 2 |
| 1 | 60311047000 | CABLE CHANNEL R/S | 1 |
| 1 | 61341031300 | Control unit EFI NEW PART | 1 |
| 1 | 60341031050 | ECU RUBBER BRACKET | 1 |
| 2 | 60416063000 | ACCLERATION SENSOR | 2 |
| 4 | 0025060166 | HH collar screw M6x16 TX30 | 4 |
| 1 | 61411083000 | CONNECTOR BOARD FRONT | 1 |
| 1 | 61414039050 | LCU HOLDER | 1 |
| 2 | 69008021060 | special screw M5x17 | 2 |
| 1 | 60711042000 | Power socket 12V | 1 |
| 1 | 60416061000 | MAGNET HOLDER | 1 |
| 1 | 58605083014 | SCREW M5X14 TORX 25 07 | 1 |
| 1 | 61408019040 | HEATINGSWITCH COVER | 1 |
| 1 | 61542090000 | Angle sensor NEW PART | 1 |
| 1 | 61342090040 | SUPPORT SLOPING POS. SENSOR | 1 |
| 3 | 0024060106 | HH COLLAR SCREW M6X10 TX30 | 3 |
| 3 | 62142041000 | DAMP. COMPONENT ABS MODUL | 3 |
| 1 | 61411098000 | GROUND CABLE BATT.-FRAME 16MM | 1 |
| 1 | 61342090050 | COVER SENSOR BOX | 1 |
| 1 | 60011053000 | BATTERY 12V/11AH 03 | 1 |
| 1 | 61311053050 | RUBBER PLATE FOR BATTERY | 1 |
| 1 | 62111059060 | COVER POSITIVE POLE | 1 |
| 2 | 83008000015 | SPECIAL SCREW M6X15X3 | 2 |
| 1 | 44011076140 | CABLE TIE 140/2,5MM BLACK | 1 |
| 1 | 44011076200 | CABLE TIE 200/3,6MM BLACK | 1 |
| 1 | 44011076305 | CABLE TIE 300/4,8MM BLACK | 1 |
| 1 | 60311042050 | Lid 12V-socket | 1 |
| 1 | 60011093075 | RUBBER CABLE TIE 75MM 03 | 1 |
| 1 | 60416062000 | WHEEL TRAVEL SENSOR | 1 |
| 1 | 61411049000 | CONNECTOR BOARD REAR | 1 |
| 1 | 61611060033 | Direct current horn complete | 1 |
| 1 | 61511078000 | Front wiring harness NEW PART | 1 |
| 1 | 64111058010 | Cover cap starter relay NEW PART | 1 |
| 2 | 58011109130 | FUSE 30 A NEW PART | 2 |
| 4 | 0081050181 | SCREW FOR PLASTIC K50X18 T20 NEW PART | 4 |
| 1 | 69011168000 | Antenna keyless NEW PART | 1 |
