Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 12361-035-000 | CAP, VALVE ADJ. | 1 |
| 1 | 12361-300-000 | CAP, VALVE ADJ. | |
| 1 | 12361-371-980 | CAP, VALVE ADJ. | |
| 2 | 41300-MB9-000 | GEAR ASSY., FINAL DRIVEN | |
| 3 | 41301-463-000 | CASE, FINAL GEAR | |
| 4 | 41303-463-300 | STAY, RUBBER (LOWER) | |
| 5 | 41306-463-000 | CAP, BREATHER | |
| 6 | 414A3-MB9-000 | GEAR SET, FINAL DRIVEN | |
| 7 | 41321-463-000 | COVER, L. GEAR CASE | |
| 8 | 41324-463-010 | PLATE, DUST GUARD | |
| 9 | 41331-463-000 | RETAINER B, BEARING | |
| 10 | 41332-415-000 | LOCK A, BEARING ADJ. | 1 |
| 11 | 41333-415-000 | LOCK B, BEARING ADJ. | 1 |
| 12 | 41351-463-000 | RETAINER A, BEARING | |
| 13 | 41410-463-000 | JOINT, PINION | |
| 14 | 41450-415-000 | SHIM A, PINION GEAR (1.10) | |
| 14 | 41451-415-000 | SHIM B, PINION GEAR (1.14) | |
| 14 | 41452-415-000 | SHIM C, PINION GEAR (1.18) | |
| 14 | 41453-415-000 | SHIM D, PINION GEAR (1.22) | |
| 14 | 41454-415-000 | SHIM E, PINION GEAR (1.26) | |
| 14 | 41455-415-000 | SHIM F, PINION GEAR (1.30) | |
| 14 | 41456-415-000 | SHIM G, PINION GEAR (1.34) | |
| 14 | 41457-415-000 | SHIM H, PINION GEAR (1.38) | |
| 14 | 41458-415-000 | SHIM I, PINION GEAR (1.42) | |
| 14 | 41459-415-000 | SHIM J, PINION GEAR (1.46) | |
| 14 | 41460-415-000 | SHIM K, PINION GEAR (1.50) | |
| 14 | 41461-415-000 | SHIM L, PINION GEAR (1.54) | |
| 14 | 41462-415-000 | SHIM M, PINION GEAR (1.58) | |
| 14 | 41463-415-000 | SHIM N, PINION GEAR (1.62) | |
| 14 | 41464-415-000 | SHIM O, PINION GEAR (1.66) | |
| 14 | 41465-415-000 | SHIM P, PINION GEAR (1.70) | |
| 14 | 41466-415-000 | SHIM Q, PINION GEAR (1.74) | |
| 14 | 41467-415-000 | SHIM R, PINION GEAR (1.78) | |
| 14 | 41468-415-000 | SHIM S, PINION GEAR (1.82) | |
| 14 | 41469-415-000 | SHIM T, PINION GEAR (1.86) | |
| 14 | 41470-415-000 | SHIM U, PINION GEAR (1.90) | |
| 15 | 41501-371-010 | SPACER B, RING GEAR (1.80) | |
| 15 | 41502-371-010 | SPACER C, RING GEAR (1.84) | |
| 15 | 41503-371-010 | SPACER D, RING GEAR (1.88) | |
| 15 | 41504-371-010 | SPACER E, RING GEAR (1.92) | |
| 15 | 41505-371-010 | SPACER F, RING GEAR (1.96) | |
| 15 | 41506-371-010 | SPACER G, RING GEAR (2.00) | |
| 15 | 41507-371-010 | SPACER H, RING GEAR (2.04) | |
| 15 | 41508-371-010 | SPACER I, RING GEAR (2.08) | |
| 15 | 41509-371-010 | SPACER J, RING GEAR (2.12) | |
| 15 | 41510-371-010 | SPACER K, RING GEAR (2.16) | |
| 15 | 41511-371-010 | SPACER, L. GEAR | |
| 15 | 41512-371-010 | SPACER M, GEAR | |
| 15 | 41513-371-010 | SPACER N, GEAR | |
| 15 | 41514-371-010 | SPACER O, GEAR | |
| 15 | 41515-371-010 | SPACER P, RING GEAR (2.36) | |
| 15 | 41516-371-000 | SPACER Q, RING GEAR (2.40) | |
| 15 | 41517-371-000 | SPACER R, RING GEAR (2.44) | |
| 16 | 42625-463-000 | COLLAR B, RR. WHEEL DISTANCE | |
| 17 | 90109-371-000 | BOLT, SEALING (8MM) | 1 |
| 18 | 90125-371-000 | BOLT, STUD (10X45) | |
| 19 | 90126-415-000 | BOLT, BREATHER | |
| 20 | 90133-371-000 | BOLT, FLANGE (8X32) | |
| 21 | 90134-371-000 | BOLT, FLANGE (10X38) | |
| 22 | 90381-371-000 | NUT, HEX. (16MM) | |
| 23 | 90471-580-000 | WASHER (8MM) | 1 |
| 24 | 90545-300-000 | WASHER, OIL BOLT | 1 |
| 25 | 90581-463-010 | WASHER (16MM) | |
| 26 | 91051-463-008 | BEARING (CR-1457) | |
| 27 | 91052-463-003 | BEARING (32907) | |
| 28 | 91061-463-004 | BEARING (30206C) (KOYO) | |
| 28 | 91061-463-008 | BEARING (30206C) (TOYO) | |
| 29 | 91062-415-013 | BEARING (30203C) | |
| 29 | 91121-PH8-961 | BEARING, TAPER (30203) | |
| 30 | 91261-463-013 | OIL SEAL (30X51X10) | |
| 31 | 91264-463-005 | OIL SEAL (35X47X9) | |
| 31 | 91264-752-003 | OIL SEAL (35X47X9) | |
| 32 | 91265-463-003 | OIL SEAL (70X94X6) | |
| 33 | 91266-463-005 | DUST SEAL (75X86X6.5) | |
| 34 | 91302-001-020 | O-RING (30.8MM) | 1 |
| 35 | 91353-463-005 | O-RING (57X4.3) | |
| 36 | 91354-463-003 | O-RING (60.5X2.4) | |
| 37 | 91355-463-003 | O-RING (100.5X2) | |
| 37 | 91355-463-005 | O-RING (100.5X2) | |
| 38 | 92000-06012 | BOLT, HEX. (6X12) | 4 |
| 38 | 92101-06012 | BOLT, HEX. (6X12) | 4 |
| 38 | 92101-06012-0A | BOLT, HEX. (6X12) | 4 |
| 39 | 96201-80000 | FITTING, GREASE (B.76S) | 1 |
