Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8GJ-21940-01-00 | FRONT FRAME COMP. | 1 |
| 2 | 59V-21646-00-00 | BAND | 1 |
| 3 | 8GJ-2175W-00-00 | BRACKET 4 | 1 |
| 4 | 92017-05045-00 | BOLT, BUTTON HEAD | 1 |
| 5 | 95702-05500-00 | NUT, FLANGE | 1 |
| 6 | 8GJ-21912-01-00 | PANEL, SUB FRAME 1 | 1 |
| 7 | 90267-48086-00 | RIVET, BLIND (4.8X19 BLACK) | 5 |
| 8 | 90338-12192-00 | PLUG | 1 |
| 9 | 8GC-2195A-10-00 | PROTECTOR, FRAME A | 1 |
| 10 | 90269-05003-00 | RIVET | 4 |
| 11 | 8GJ-21950-21-00 | REAR FRAME COMP. | 1 |
| 12 | 8GC-21991-00-00 | REINF., PANEL FRAME 1 | 1 |
| 13 | 8GK-21930-20-00 | HOUSING, REINF SUB-ASSY (R. | 1 |
| 14 | 93306-20511-00 | BEARING | 1 |
| 15 | 99009-52500-00 | CIRCLIP | 1 |
| 16 | 8GJ-21950-29-00 | REAR FRAME COMP. | 1 |
| 17 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELL | 4 |
| 18 | 8GJ-21943-00-00 | BRACKET, MAIN TRACK 1 | 1 |
| 19 | 8GJ-21953-00-00 | BRACKET, MAIN TRACK 2 | 1 |
| 20 | 95822-08012-00 | BOLT, FLANGE | 2 |
| 21 | 8GJ-21926-00-00 | REINFORCEMENT, FOOTREST 1 | 1 |
| 22 | 8GJ-21936-00-00 | REINFORCEMENT, FOOTREST 2 | 1 |
| 23 | 8GJ-21944-00-00 | BRACKET, REAR TRACK SUS | 1 |
| 24 | 95822-08020-00 | BOLT, FLANGE | 8 |
| 25 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELL | 32 |
| 26 | 8GJ-21954-00-00 | BRACKET, REAR TRACK SUS | 1 |
| 27 | 8FK-21953-00-00 | BRACKET, MAIN TRACK 2 | 2 |
| 28 | 8GJ-21967-00-00 | PATCH 7 | |
| 29 | 8GJ-21988-00-00 | PATCH 8 | 1 |
| 30 | 8GJ-21391-00-00 | BRACKET, SEAT | 2 |
| 31 | 8GJ-21329-00-00 | PLATE | 2 |
| 32 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELL | 20 |
| 33 | 95822-08014-00 | BOLT, FLANGE | 2 |
| 34 | 95822-08016-00 | BOLT, FLANGE | 4 |
| 35 | 8GC-2199H-00-00 | SHIELD, HEAT | 1 |
| 36 | 8GC-1467H-00-00 | BRACKET, SILENCER 1 | 1 |
| 37 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELL | 26 |
| 38 | 95822-08016-00 | BOLT, FLANGE | 2 |
| 39 | 90267-48023-00 | RIVET, BLIND (4.8X12.1 YELL | 35 |
| 40 | 90267-48177-00 | RIVET, BLIND (4.8X14 YELLO | 68 |
| 41 | 95022-08020-00 | BOLT, FLANGE | 10 |
| 42 | 8GJ-12440-00-00 | HEAT EXCHANGER ASSY | |
| 43 | 95822-08020-00 | BOLT, FLANGE | 6 |
| 44 | 90109-065G4-00 | BOLT | 2 |
| 45 | 8GC-21973-00-00 | HOOK | 1 |
| 46 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW | 7 |
| 47 | 2TK-2177L-00-00 | PLATE, SPRING | 1 |
| 48 | 90267-32192-00 | RIVET, BLIND (3.2X13.8) | 2 |
| 49 | 8GJ-21963-00-00 | PATCH 3 | 1 |
| 50 | 8GJ-21964-00-00 | PATCH 4 | 1 |
| 51 | 8GJ-2176E-00-00 | PLATE | 1 |
| 52 | 95822-10016-00 | BOLT, FLANGE | 2 |
| 53 | 8GC-14747-00-00 | DAMPER, MUFFLER | 2 |
| 54 | 8GC-21121-00-00 | BRACKET, DAMPER | 2 |
| 55 | 92012-06010-00 | BOLT, BUTTON HEAD | 4 |
| 56 | 8GC-21967-00-00 | PATCH 7 | 2 |
| 57 | 8GC-2164F-00-00 | STAY 1 | 1 |
| 58 | 90183-06053-00 | NUT, SPRING | 2 |
| 59 | 91312-06012-00 | BOLT | 2 |
| 60 | 8GJ-21916-00-00 | PANEL, SUB FRAME 5 | 1 |
| 61 | 98902-06012-00 | SCREW, BIND | 2 |
| 62 | 8GJ-2164G-00-00 | STAY 2 | 1 |
| 63 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 2 |
| 64 | 8GJ-21960-00-00 | FOOTREST COMP. 1 | 1 |
| 65 | 90267-48010-00 | RIVET, BLIND (4.8X12 YELLOW) | 2 |
| 66 | 90465-08368-00 | CLAMP | 3 |
| 67 | 90267-48083-00 | RIVET, BLIND (4.8X15.2 SILVER | 1 |
| 68 | 90201-043H7-00 | WASHER, PLATE | 2 |
| 69 | 90480-13163-00 | GROMMET | 1 |
| 70 | 95822-08016-00 | BOLT, FLANGE | 2 |
| 71 | 95022-06012-00 | BOLT, FLANGE | 4 |
| 72 | 90105-06080-00 | BOLT, FLANGE | 2 |
| 73 | 8GJ-21970-00-00 | FOOTREST COMP. 2 | 1 |
| 74 | 95822-08020-00 | BOLT, FLANGE | 8 |
| 75 | 90105-08190-00 | BOLT, FLANGE | 2 |
| 76 | 8GJ-2193A-00-00 | PROTECTOR | 1 |
| 77 | 90109-066G1-00 | BOLT | 6 |
| 78 | 90480-27001-00 | GROMMET | |
| 79 | 90480-40003-00 | GROMMET | 1 |
| 80 | 8GJ-27431-00-00 | FOOTREST, REAR 1 | 1 |
| 81 | 8GJ-27441-00-00 | FOOTREST, REAR 2 | 1 |
| 82 | 97702-50020-00 | SCREW, TAPPING | 10 |
| 83 | 8GJ-2195E-00-00 | PLATE, STEERING BRACKET 1 | 1 |
| 84 | 8GJ-2195F-00-00 | PLATE, STEERING BRACKET 2 | 1 |
| 85 | 8GJ-2198F-00-00 | COVER 1 | 1 |
| 86 | 8GJ-2198J-00-00 | COVER 3 | 1 |
| 87 | 90269-05003-00 | RIVET | 6 |
| 88 | 90269-05002-00 | RIVET | 2 |
| 89 | 8GJ-77557-01-00 | PROTECTOR 7 | 1 |
| 90 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 11 |
| 91 | 90267-47187-00 | RIVET, BLIND (4.7X16.4 BLACK) | 3 |
| 92 | 90201-05033-00 | WASHER, PLATE | 11 |
| 93 | 8GJ-2197E-00-00 | PROTECTOR, FRAME FRONT | |
| 94 | 8GJ-241A4-00-00 | SEAL 4 | 1 |
| 95 | 8GJ-241A5-00-00 | SEAL 5 | 1 |
| 96 | 90269-05055-00 | RIVET | 5 |
| 97 | 8GL-77319-00-00 | DAMPER 1 | 1 |
