Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 04211-09109 | PIN | 1 |
| 1 | 25211-19B00 | FORK, GEAR SHIFT, NO.1 MODEL J/K/L/M/N | 1 |
| 1 | 25211-19B01 | FORK, GEAR SHIFTING, NO.1 MODEL P | 1 |
| 1 | 25211-19B00 | FORK, GEAR SHIFT, NO.1 MODEL R/S/T | 1 |
| 1 | 25221-19B00 | FORK, GEAR SHIFT, NO.2 | 1 |
| 25241-19B00 | FORK, GEAR SHIFTING, NO.4 | ||
| 25411-24501 | SHAFT, NO.1 | ||
| 1 | 25231-19B00 | FORK, GEAR SHIFT, NO.3 | 1 |
| 1 | 25411-14330 | SHAFT, NO.2 MODEL J/K/L/M/N | 1 |
| 1 | 25411-14340 | SHAFT, NO.2 MODEL P | 1 |
| 1 | 25411-14331 | SHAFT, NO.2 MODEL R/S/T | 1 |
| 25310-19B02 | CAM, GEAR SHIFTING Includes Item(s) 8 - 8 | ||
| 04221-04109 | PIN MODEL J/K/L/M/N/P/R/S | ||
| 1 | 04221-04089 | .PIN MODEL T | 1 |
| 25322-19B00 | RETAINER, PIN | ||
| 6 | 09261-04002 | .ROLLER (4X13.8) | 6 |
| 1 | 09262-25002 | BEARING (25X47X8) MODEL J/K/L/M/N/P | 1 |
| 1 | 09262-25006 | BEARING (25X47X8) MODEL R/S/T | 1 |
| 25341-19B00 | RETAINER | ||
| 1 | 24741-21A00 | RETAINER | 1 |
| 2 | 02112-06123 | SCREW | 2 |
| 25350-19B00 | STOPPER, CAM | ||
| 1 | 09111-06019 | BOLT (6X14.6) MODEL J/K/L/M/N/P | 1 |
| 1 | 09111-06054 | BOLT (6X14.6) MODEL S/T | 1 |
| 1 | 08211-06141 | WASHER | 1 |
| 09443-06067 | SPRING | ||
| 1 | 09223-04001 | PIN | 1 |
| 1 | 25381-20A00 | PLATE, STOPPER | 1 |
| 1 | 01550-06253 | BOLT | 1 |
| 25320-19B01 | CAM, REVERSE SHIFTING | ||
| 1 | 08211-12183 | WASHER | 1 |
| 1 | 25351-11000 | STOPPER, CAM | 1 |
| 1 | 09440-05011 | SPRING | 1 |
| 1 | 25352-11010 | HOLDER, STOPPER | 1 |
| 1 | 09168-14004 | GASKET (14.1X18X1.5) MODEL J/K/L/M/N/P | 1 |
| 1 | 09168-14002 | .GASKET (13.8X18.8X4.8) MODEL S/T | 1 |
| 25510-19B00 | SHAFT, GEAR SHIFTING NO.1 | ||
| 25520-19B01 | ARM, GEAR SHIFTING NO.2 Includes Item(s) 31 - 32 | ||
| 1 | 09448-13006 | SPRING | 1 |
| 1 | 08332-11076 | E RING | 1 |
| 25540-19B01 | ARM, LINK | ||
| 1 | 09444-26022 | SPRING MODEL J/K/L/M/N | 1 |
| 1 | 09444-26025 | SPRING MODEL P/R/S/T | 1 |
| 25671-24500 | STOPPER, ARM | ||
| 1 | 09180-07014 | SPACER (7X10X5) | 1 |
| 09103-08193 | BOLT | ||
| 1 | 08211-08201 | WASHER | 1 |
| 2 | 09285-12006 | SEAL,OIL (12X22X9) | 2 |
| 2 | 09280-10012 | O RING (D:1.5,ID:10) | 2 |
| 1 | 25661-19B00 | COLLAR | 1 |
| 25600-19B03 | LEVER ASSY, GEAR SHIFTING MODEL J/K | ||
| 1 | 25600-19B70 | LEVER ASSY, GEAR SHIFTING MODEL L/M/N/P/R/S/T; Includes Item(s) 43 | 1 |
| 1 | 25652-24401 | .RUBBER | 1 |
| 1 | 04111-25208 | COTTER PIN MODEL J/K/L/M/N/P/R/S | 1 |
| 1 | 04111-25158 | COTTER PIN MODEL T | 1 |
| 1 | 01517-06555 | BOLT MODEL J/K/L/M/N/P | 1 |
| 1 | 01550-06553 | BOLT MODEL R/S/T | 1 |
| 1 | 25640-19B00 | ARM | 1 |
| 1 | 25630-19B10 | ARM, GEAR SHIFTING CABLE MODEL J/K | 1 |
| 1 | 25630-19B70 | ARM, GEAR SHIFTING CABLE MODEL L/M/N/P/R/S/T | 1 |
| 1 | 09100-06091 | BOLT (6X20) MODEL J/K/L/M/N | 1 |
| 1 | 01107-06207 | BOLT MODEL P | 1 |
| 1 | 01500-06203 | BOLT MODEL R/S/T | 1 |
| 1 | 01107-08256 | BOLT MODEL J/K/L/M/N/P | 1 |
| 1 | 01500-08253 | BOLT MODEL R/S/T | 1 |
| 3 | 08322-11088 | WASHER MODEL J/K/L/M/N/P | 3 |
| 3 | 08322-01083 | WASHER MODEL R/S/T | 3 |
| 2 | 08332-11063 | E RING | 2 |
| 1 | 37600-19B02 | SWITCH ASSY, REVERSE | 1 |
| 1 | 09280-16008 | O RING (D:3.2,ID:15.8) | 1 |
| 1 | 37720-24501 | SWITCH, GEAR SHIFTING | 1 |
| 1 | 09280-26005 | O RING (D:2.4,ID:26.2) | 1 |
| 2 | 02112-75208 | SCREW MODEL J/K/L/M/N/P | 2 |
| 2 | 02112-75203 | SCREW MODEL R/S/T | 2 |
| 1 | 09209-05011 | CONTACT | 1 |
| 1 | 09440-04010 | SPRING | 1 |
| 1 | 09407-14403 | CLAMP (L:125) | 1 |
| 1 | 68392-24210 | LABEL, GEAR SHIFT PATTERN | 1 |
