Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 515177854 | Speedometer Ass'y Includes 1 To 4 | 1 |
| XXXX | Not Available As Spare Part - Speedometer Button | ||
| XXXX | Not Available As Spare Part - Gauge Ring | ||
| XXXX | Not Available As Spare Part - Lens And Seal | ||
| 1 | 219902677 | BRP Logo 20 mm | 1 |
| 1 | 515177249 | DESS Switch Includes 6 To 9 | 1 |
| 3 | 515175232 | Male Terminal | 3 |
| 1 | 515175494 | Male Housing, 3 Circuits | 1 |
| 409902000 | Tubing 12 mm | ||
| 1 | 278002963 | Safety Nut (DESS Switch) | 1 |
| 1 | 515177057 | DESS Cap | 1 |
| 1 | 515177187 | Visor Harness | 1 |
| 1 | 572103300 | Cap | 1 |
| 1 | 515175851 | Extension | 1 |
| 1 | 710001248 | DC Outlet | 1 |
| 1 | 515177813 | Temperature Sensor Includes 16 To 18 | 1 |
| 1 | 515175670 | Female Terminal Housing, 2 Circuits | 1 |
| 2 | 278000632 | Female Terminal | 2 |
| XXXX | Not Available As Spare Part - Loctite 592, Pipe Sealant, 50 ml | ||
| 1 | 515176366 | Air Temperature Sensor | 1 |
| 1 | 508000769 | Seal | 1 |
| 2 | 389804300 | Push Nut | 2 |
| 515177683 | WIRING HARNESS MAIN | ||
| 515177593 | Fusebox Support | ||
| 1 | 270000141 | Clip | 1 |
| 1 | 293150037 | Avdel Rivet 3/16" | 1 |
| 3 | 390402200 | Pop Rivet 3/16" | 3 |
| 1 | 234141601 | Lock Washer 4 mm | 1 |
| 1 | 250000127 | Torx Screw M4 X 8 | 1 |
| 1 | 515176234 | FEMALE TERMINAL HOUSING, 6 CIRCUITS | 1 |
| 1 | 515177289 | Ground Wire | 1 |
| 1 | 515177272 | Capacitor | 1 |
| 1 | 515176607 | Capacitor Support | 1 |
| 1 | 515176605 | Capacitor Harness | 1 |
| 2 | 250000462 | Socket Head Screw M10 X 32 | 2 |
| 2 | 250200026 | Lock washer | 2 |
| 1 | 516005515 | CAPACITOR DECAL (ENGLISH) | 1 |
| 1 | 515177193 | Cap | 1 |
| XXXX | Not Available As Spare Part - Loctite 8104 (Dielectric Grease), 75ml | ||
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 293750001 | Tie Wrap 94 mm | 1 |
| 1 | 517304194 | RH Headlamp Ass'y Includes 41 To 45 | 1 |
| 1 | 517304195 | LH Headlamp Ass'y Includes 41 To 45 | 1 |
| 1 | 515176274 | Halogen Bulb, 60/55 W, 12 V ( H4 ) | 1 |
| XXXX | Not Available As Spare Part - Bulb Holder | ||
| 2 | 515176498 | Cap | 2 |
| 1 | 515176499 | Cover | 1 |
| 6 | 250000722 | Torx Screw M6 X 20 | 6 |
| 6 | 250100113 | Panel Nut, M6 X 1.0 | 6 |
