Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 415130101 | FRAME EXPEDITION 154 Includes 10 to 90 | ||
| 1 | 518325782 | RH Deflector, Black Polypropylene | 1 |
| 1 | 518325783 | LH Deflector, Black Polypropylene | 1 |
| 4 | 293150104 | Pop Rivet 3/16" | 4 |
| 2 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 2 |
| 1 | 518325560 | Adhesive Patch | 1 |
| 1 | 518327907 | Front Radiator Ass'y Includes 22 to 22a | 1 |
| 1 | 250300027 | Clinch Stud M6 X 20 | 1 |
| 5 | 293150203 | Rivet Avibulb 3/16 | 5 |
| 1 | 293150174 | Hemlock Rivet, 6.4 mm | 1 |
| 1 | 518326937 | RH Reinforcement, Running Board | 1 |
| 1 | 518326938 | LH Reinforcement, Running Board | 1 |
| 1 | 518325973 | RH Rear Base | 1 |
| 1 | 518325974 | LH Rear Base | 1 |
| 1 | 293450275 | Insert | 1 |
| 1 | 518326656 | Seal | 1 |
| 1 | 518327105 | Rear Cap | 1 |
| 2 | 293450275 | Insert | 2 |
| 1 | 518328942 | RH Stirup Includes 40 to 40a | 1 |
| 1 | 390909200 | Avex Rivet | 1 |
| 1 | 293450268 | Insert M5 X 0.8 | 1 |
| 1 | 518328528 | LH Stirup Includes 44 to 44a | 1 |
| 3 | 250000752 | Torx Screw M8 X 1.25 X 25, Scotch Grip | 3 |
| 1 | 293730042 | Full Moon Dart 5 mm | 1 |
| 4 | 293450268 | Insert M5 X 0.8 | 4 |
| 22 | 293150203 | Rivet Avibulb 3/16 | 22 |
| 4 | 390909100 | Avex Rivet | 4 |
| 8 | 293150144 | Stavex Rivet | 8 |
| 12 | 293150146 | Henrob Rivet | 12 |
| 4 | 293150119 | Hemlock Rivet, 6.5 mm | 4 |
| 1 | 518328078 | E Module Includes 63 to 78 | 1 |
| 1 | 518326328 | RH Side Member | 1 |
| 1 | 518326330 | LH Side Member | 1 |
| 1 | 518326198 | Front Member | 1 |
| 1 | 293150144 | Stavex Rivet | 1 |
| 2 | 293150120 | Hemlock Rivet 6.5 mm | 2 |
| 2 | 505073317 | Leg Cushion | 2 |
| 2 | 250000767 | Torx Truss Screw M6 X 12 | 2 |
| 1 | 518327605 | RH Suspension Bracket | 1 |
| 1 | 518327606 | LH Suspension Bracket | 1 |
| 1 | 518328098 | RH Roller | 1 |
| 1 | 518328099 | LH Roller | 1 |
| 1 | 518326692 | Rear Radiator Ass'y, 154" Includes 70 | 1 |
| 8 | 293150147 | Hemlock Rivet | 8 |
| 1 | 518326178 | Engine Support | 1 |
| 3 | 390402400 | Pop Rivet 3/16" | 3 |
| 1 | 233161414 | Hex. Flange Nut M6 | 1 |
| 1 | 518327535 | BRACE ASS'Y | 1 |
| 2 | 512060295 | Rubber Mount | 2 |
| 1 | 234281474 | Conical Spring Washer M8 | 1 |
| 1 | 518328320 | Cross Member S Module | 1 |
| 1 | 518327487 | Front Suspension Support | 1 |
| 1 | 518327565 | Front Member | 1 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 250000822 | Hex. Flange Screw M6 X 16 | 2 |
| 2 | 207662544 | Hex. Flange Screw M6 X 25 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 6 | 293150191 | Monobolt Rivet, 4.8 mm | 6 |
| 2 | 293150182 | Monobolt Rivet 6.4 | 2 |
| 2 | 207661644 | Hex. Flange Screw M6 X 16 | 2 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 2 | 250000351 | Hex. Flange Screw M8 X 25, Nylon | 2 |
| 1 | 207584034 | Hex. Flange Screw, Scotch Grip | 1 |
| 1 | 518326559 | Rear Member | 1 |
| 2 | 518326848 | Upper Column Support | 2 |
| 2 | 207662044 | Hex. Flange Screw M6 X 20 | 2 |
| 2 | 233261416 | Elastic Flange Nut M6 X 1.0 | 2 |
| 1 | 518326355 | Center Column Support | 1 |
| 1 | 518325579 | Clear Rear Bumper | 1 |
| 1 | 520000711 | Full Moon RH Cap | 1 |
| 1 | 520000712 | Full Moon LH Cap | 1 |
| 3 | 293730041 | Full Moon Dart 8 mm | 3 |
| 2 | 293730059 | Full Moon Dart 10 mm | 2 |
| 1 | 518327145 | Sub A Support | 1 |
| 2 | 250000079 | Panel Nut M5 X 0.8 | 2 |
| 10 | 250000779 | Torx Screw M6 X 1.0 X 18, Scotch Grip | 10 |
| 6 | 224061201 | Flat Washer | 6 |
