Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | F3F-U35B1-A0-00 | Backrest Front, Port UR FOR SC2 | 1 |
| 1 | F3F-U35B1-B0-00 | Backrest Front, Port UR FOR PBC8 | 1 |
| 4 | 90209-14SA3-00 | Washer UN | 4 |
| 4 | 90204-14S00-00 | Washer, Spring UN | 4 |
| 4 | 90170-14S00-00 | Nut UN | 4 |
| 1 | F1C-U5195-00-00 | Clip, 1 UN | 1 |
| 1 | 90167-08SA8-00 | Screw, Tapping UN | 1 |
| 1 | F3F-U35B2-A0-00 | Backrest Front, Stbd UR FOR SC2 | 1 |
| 1 | F3F-U35B2-B0-00 | Backrest Front, Stbd UR FOR PBC8 | 1 |
| 1 | F3F-U3796-A0-00 | Back Rest 3 UR FOR SC2 | 1 |
| 1 | F3F-U3796-B0-00 | Back Rest 3 UR FOR PBC8 | 1 |
| 1 | F3F-U3798-A0-00 | Back Rest, 4 UR FOR SC2 | 1 |
| 1 | F3F-U3798-B0-00 | Back Rest, 4 UR FOR PBC8 | 1 |
| 1 | F3F-U35A1-A0-00 | Cushion, Fore 1 UR FOR SC2 | 1 |
| 1 | F3F-U35A1-B0-00 | Cushion, Fore 1 UR FOR PBC8 | 1 |
| 4 | F3F-U3714-20-00 | Bracket,Seat | 4 |
| 16 | 90201-10S00-00 | Washer, Plate | 16 |
| 16 | 90204-10S00-00 | Washer, Spring | 16 |
| 16 | 90170-10S00-00 | .Nut | 16 |
| 16 | 90151-10S16-00 | Screw, Countersunk | 16 |
| 16 | 90185-10S00-00 | Nut, Self-Locking | 16 |
| 4 | F3F-U3714-30-00 | Bracket,Seat | 4 |
| 1 | F3F-U35A2-A0-00 | Cushion Seat, Front Right UR FOR SC2 | 1 |
| 1 | F3F-U35A2-B0-00 | Cushion Seat, Front Right UR FOR PBC8 | 1 |
| 1 | F3F-U35A5-A0-00 | Cushion, Fore 5 | 1 |
| F3F-U35A6-A0-00 | Cushion, Fore 6 | ||
| 1 | F3F-U3791-A0-00 | Back Rest 1 UR FOR SC2 | 1 |
| 1 | F3F-U3791-B0-00 | Back Rest 1 UR FOR PBC8 | 1 |
| 1 | F3F-U371D-A0-00 | Cushion 1 UR FOR SC2 | 1 |
| 1 | F3F-U371D-B0-00 | Cushion 1 UR FOR PBC8 | 1 |
| 1 | F3F-U3795-A0-00 | Backrest 2 UR FOR SC2 | 1 |
| 1 | F3F-U3795-B0-00 | Backrest 2 UR FOR PBC8 | 1 |
| 1 | F3F-U371E-A0-00 | Cushion 2 UR FOR SC2 | 1 |
| 1 | F3F-U371E-B0-00 | Cushion 2 UR FOR PBC8 | 1 |
| 1 | F3F-U3766-A0-00 | Backrest 1 UR FOR SC2 | 1 |
| 1 | F3F-U3766-B0-00 | Backrest 1 UR FOR PBC8 | 1 |
| 1 | F3F-U3724-A0-00 | Cushion Seat, Rear UR FOR SC2 | 1 |
| 1 | F3F-U3724-B0-00 | Cushion Seat, Rear UR FOR PBC8 | 1 |
| 1 | F1C-U5192-00-00 | .Snap | 1 |
| 1 | F3F-U36A1-A0-00 | Pad 1 UR FOR SC2 | 1 |
| 1 | F3F-U36A1-B0-00 | Pad 1 UR FOR PBC8 | 1 |
| 1 | F3F-U36A2-A0-00 | Pad 2 UR FOR SC2 | 1 |
| 1 | F3F-U36A2-B0-00 | Pad 2 UR FOR PBC8 | 1 |
| 1 | F3F-U521C-A0-00 | Pad 1 UR FOR SC2 | 1 |
| 1 | F3F-U521C-B0-00 | Pad 1 UR FOR PBC8 | 1 |
| 1 | F3F-U521D-A0-00 | Pad 2 UR FOR SC2 | 1 |
| 1 | F3F-U521D-B0-00 | Pad 2 UR FOR PBC8 | 1 |
| 2 | F3F-U2829-00-00 | . .Hinge 3 | 2 |
| 2 | F3F-U5532-00-00 | . .Latch | 2 |
| 16 | 90169-10SA1-00 | Tapping Screw | 16 |
| 4 | 90169-08SA5-00 | Tapping Screw | 4 |
| 1 | F3F-U35B3-A0-00 | Backrest, Fore 3 UR FOR SC2 | 1 |
| 1 | F3F-U35B3-B0-00 | Backrest, Fore 3 UR FOR PBC8 | 1 |
| 1 | F3F-U372D-A0-00 | Cushion, 3 UR FOR SC2 | 1 |
| 1 | F3F-U372D-B0-00 | Cushion, 3 UR FOR PBC8 | 1 |
| 1 | F3F-U372E-A0-00 | Cushion 4 UR FOR SC2 | 1 |
| 1 | F3F-U372E-B0-00 | Cushion 4 UR FOR PBC8 | 1 |
| 2 | F3F-U372F-40-00 | Cushion 5 | 2 |
| 1 | F3F-U592C-N0-00 | Pad 1 UR FOR SC2 | 1 |
| 1 | F3F-U592C-R0-00 | Pad 1 UR FOR PBC8 | 1 |
| 1 | F3F-U592C-P0-00 | Pad 1 UR FOR SC2 | 1 |
| 1 | F3F-U592C-S0-00 | Pad 1 UR FOR PBC8 | 1 |
| 1 | F3F-U521E-A0-00 | Pad 3 | 1 |
| 1 | F3F-U521F-A0-00 | Pad 4 | 1 |
| F3F-U828B-A0-00 | Cushion 1 UR FOR SC2 | ||
| 1 | F3F-U828B-B0-00 | Cushion 1 UR FOR PBC8 | 1 |
| F3F-U828C-A0-00 | Cushion 2 UR FOR SC2 | ||
| 1 | F3F-U828C-B0-00 | Cushion 2 UR FOR PBC8 | 1 |
