Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 17316-611-000 | CLIP, BREATHER TUBE | 1 |
| 19010-MM8-003 | RADIATOR (TOYO) | ||
| 19015-MM8-003 | SHROUD (TOYO) | ||
| 1 | 19020-MG8-003 | FAN, COOLING | 1 |
| 19030-MM8-004 | MOTOR ASSY., FAN | ||
| 19030-MM8-014 | MOTOR ASSY., FAN | ||
| 19031-MG8-300 | TUBE, RUBBER | ||
| 19040-MM8-000 | COVER, RADIATOR | ||
| 19040-MM8-000ZA | COVER, RADIATOR *NH1* (BLACK) | ||
| 1 | 19045-MB3-000 | CAP, RADIATOR | 1 |
| 1 | 19051-KA4-000 | RUBBER, RADIATOR SETTING | 1 |
| 1 | 19052-MB0-000 | COLLAR, RADIATOR SETTING | 1 |
| 19103-MM8-000 | TANK, RESERVE | ||
| 19103-MM8-010 | TANK, RESERVE | ||
| 19103-463-000 | JOINT, TUBE | ||
| 1 | 19105-MG8-000 | CAP ASSY., RESERVE TANK | 1 |
| 1 | 19106-MM8-000 | NECK, FILLER | 1 |
| 1 | 19107-MG8-000 | GASKET, RESERVE TANK | 1 |
| 19110-MM8-000 | FILLER NECK, RESERVE TANK | ||
| 19112-ME9-000 | RUBBER, RADIATOR | ||
| 19113-MM8-000 | TUBE, RADIATOR RESERVE TANK | ||
| 1 | 19116-MM8-000 | HOSE, RADIATOR (UPPER) | 1 |
| 1 | 19117-MM8-000 | HOSE, RADIATOR (LOWER) | 1 |
| 19120-MM8-000 | GUARD, RADIATOR HOSE (LOWER) | ||
| 19206-MM8-000 | TUBE, RADIATOR RESERVE | ||
| 1 | 19300-MB0-003 | THERMOSTAT | 1 |
| 19311-MM8-000 | CASE, THERMOSTAT | ||
| 19315-MG8-000 | COVER, THERMOSTAT | ||
| 1 | 19503-MB1-870 | CLAMP, WATER HOSE | 1 |
| 1 | 19516-MJ8-000 | CLAMP A, WATER HOSE | 1 |
| 1 | 19517-KM9-000 | CLIP, WATER HOSE | 1 |
| 1 | 19521-MM8-000 | HOSE A, OUTLET WATER | 1 |
| 1 | 32161-438-000 | BAND, CABLE | 1 |
| 1 | 33741-ME9-672 | REFLECTOR, FR. REFLEX | 1 |
| 1 | 33741-ME9-673 | REFLECTOR, FR. REFLEX | 1 |
| 1 | 37750-PC1-004 | SENDING UNIT, WATER TEMPERATURE (DENSO) | 1 |
| 1 | 37760-MB2-901 | SWITCH ASSY., THERMO | 1 |
| 1 | 37760-MR1-003 | SWITCH ASSY., THERMO | 1 |
| 50176-KE8-000 | CLAMP, CHOKE CABLE (A) | ||
| 50189-MM8-000 | BRACKET, THERMOSTAT CASE | ||
| 87507-MB4-670 | LABEL, RESERVE TANK | ||
| 90042-MB6-000 | BOLT, SPECIAL (8MM) | ||
| 1 | 90116-ME9-000 | BOLT, FLANGE (6MM) | 1 |
| 1 | 90167-SA0-980 | NUT, FLANGE CAP (5MM) | 1 |
| 90308-MF2-003 | NUT, FLANGE (6X1.0) | ||
| 1 | 90315-MK3-003 | NUT, SERRATE (5MM) | 1 |
| 1 | 90473-896-000 | WASHER (8MM) | 1 |
| 1 | 90522-MF5-000 | WASHER, FR. COVER | 1 |
| 1 | 91307-MB0-003 | O-RING (54X2) | 1 |
| 1 | 91307-PH7-660 | O-RING (13.5X1.4) | 1 |
| 1 | 91307-611-000 | O-RING (12.5X1.4) | 1 |
| 1 | 94050-06080 | NUT, FLANGE (6MM) | 1 |
| 1 | 94101-05800 | WASHER, PLAIN (5MM) | 1 |
| 1 | 94608-30000 | O-RING (23X2.4) | 1 |
| 1 | 95002-02120 | CLIP, TUBE (B12) | 1 |
| 1 | 95002-70000 | CLIP, TUBE (C11) | 1 |
| 1 | 95005-70003-30M | BULK HOSE, VACUUM (7X3000) (7X330) | 1 |
| 1 | 95005-750012-0M | BULK TUBE,TB75-1M | 1 |
| 1 | 95701-06012-08 | BOLT, FLANGE (6X12) | 1 |
| 1 | 95701-06028-07 | BOLT, FLANGE (6X28) | 1 |
| 1 | 96000-06014-07 | BOLT, FLANGE (6X14) | 1 |
| 1 | 96001-06014-07 | BOLT, FLANGE (6X14) | 1 |
| 1 | 96000-06020-07 | BOLT, FLANGE (6X20) | 1 |
| 1 | 96001-06020-07 | BOLT, FLANGE (6X20) | 1 |
