Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 27130-38F00 | YOKE, FR DRIVE BEVEL GR Includes Item(s) 2 | 1 |
| 1 | 27592-38F00 | PLATE, OUTPUT FLANGE | 1 |
| 1 | 27161-38F10 | YOKE, PROP SHAFT JOINT FR | 1 |
| 1 | 27200-19810 | JOINT SET, UNIVERSAL | 1 |
| 4 | 09380-20016 | CIRCLIP | 4 |
| 27311-44D60 | GEAR, FR DRIVE BVL | ||
| 1 | 27441-19B00 | HOUSING, FR DRIVE BVL GR | 1 |
| 1 | 27445-19810 | SHIM SET, FR DRIVE BVL HSG T:0.15/0.30/0.35/0.40 | 1 |
| 1 | 09159-16004 | NUT, FR DRIVE BVL GR | 1 |
| 1 | 09160-16026 | WASHER, FR DRIVE BVL GR 16X30X3 | 1 |
| 1 | 09180-25085 | SPACER, FR DRIVE BVL GR 25.3X28X28 | 1 |
| 1 | 09265-25024 | BRG,FR DRIVE BVL GR,FR 25X52X16.25 | 1 |
| 1 | 09265-25013 | BRG,FR DRIVE BVL GR,FR 25X52X19.25 | 1 |
| 1 | 09280-63004 | O RING, DRIVE BVL GR HSG ID:62.6,DD:2.4 | 1 |
| 1 | 09283-34008 | SEAL, FR DRIVE BVL GR JOINT 34X52X9 | 1 |
| 1 | 01550-08253 | BOLT, FR DRIVE BVL GR HSG | 1 |
| 27321-09F50 | GEAR, FR DRIVEN BEVEL | ||
| 1 | 27326-19810 | SHIM SET, JFR DRIVEN BVL GR T:0.35/0.40/0.50/0.60 | 1 |
| 1 | 27327-34810 | SHIM SET, DRIVEN GEAR BRG T:0.35/0.40/0.50/0.60 | 1 |
| 1 | 27371-19B01 | DOG, FR DIF LOCK SLIDING | 1 |
| 1 | 09262-70001 | BRG, FR DRIVEN BEVEL GR 70X110X13 | 1 |
| 1 | 09283-34008 | SEAL, FR DRIVEN OUTPUT,LH 34X52X9 | 1 |
| 1 | 08113-60050 | BRG, FR DRIVEN OUTPUT SFT,LH | 1 |
| 27300-09F70 | DIFFERENTIAL ASSY, FR MODEL K1 | ||
| 27361-09F70 | SHAFT, FR DRIVEN OUTPUT MODEL K1 | ||
| 27300-09F80 | DIFFERENTIAL ASSY, FRONT MODEL K2 | ||
| 1 | 09262-40006 | BRG, DIFFERENTIAL CASE RH 40X62X12 | 1 |
| 1 | 09283-34008 | SEAL, FR DIF SIDE OUTPUT OIL 34X52X9 | 1 |
| 27450-19B13 | HOUSING, FR DIF GEAR Includes Item(s) 29 | ||
| 1 | 09364-08003 | UNION, BREATHER | 1 |
| 27461-19B10 | CASE, FR DRIVEN GR BRG | ||
| 1 | 09103-10148 | BOLT, FR DIFF HOUSING MTG 10X110 | 1 |
| 09103-10052 | BOLT, FR DIFF HOUSING MTG 10X120 | ||
| 1 | 09168-14002 | .GASKET (13.8X18.8X4.8) 13.8X18.8X0.4 | 1 |
| 1 | 09168-16002 | GASKET, OIL FILLER PLUG 16X22X2.0 | 1 |
| 1 | 09247-14002 | PLUG (MAGNETO) | 1 |
| 1 | 09248-16012 | PLUG, GR OIL FILLER | 1 |
| 1 | 09280-00022 | O RING, FR DRIVEN GR BRG CASE ID:131.4,DD:2.4 | 1 |
| 1 | 09352-70103-00B | HOSE, BREATHER (7X10.2X2000) L:2000->700 | 1 |
| 1 | 09401-10403 | CLIP | 1 |
| 2 | 09407-18402 | CLAMP (L:165) | 2 |
| 8 | 01550-08253 | BOLT, FR DRIVEN GR CASE | 8 |
| 2 | 08319-31103 | NUT, FR DIFF HOUSING HTG | 2 |
| 2 | 09381-22007 | RING, FR DRIVE SHAFT | 2 |
| 1 | 27471-19B01 | COVER, FR DRIVEN GR CASE | 1 |
| 1 | 27473-19B11 | GASKET, CASE COVER | 1 |
| 2 | 01547-06253 | BOLT, CASE COVER | 2 |
| 2 | 01547-06353 | BOLT, CASE COVER | 2 |
| 2 | 04211-09109 | PIN, CASE COVER | 2 |
