Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 7042320 | SHOCK-RESERVOIR,REAR (AA)(AB)(AD) | 1 |
| 7043074 | SHOCK-REAR,RES (AC) | ||
| 1500222 | VALVE | ||
| 1500532 | PLATE-DAMPING | ||
| 1500221 | VALVE | ||
| 1500252 | SCREW | ||
| 1500223 | SCREW | ||
| 1 | 1500253 | O-RING | 1 |
| 1500226 | BALL | ||
| 1500225 | SPRING | ||
| 1 | 1500254 | DRUM,COMPRESSION DAMPING | 1 |
| 1500522 | HOUSING,CD (AA)(AB)(AD) | ||
| 1500591 | Housing, CD (AC) | ||
| 1 | 1500208 | SEAL,O-RING | 1 |
| 1500515 | PISTON,FLOATING | ||
| 1 | 1500161 | SCREW ASM,BLK (800-10-008) | 1 |
| 1500228 | O-RING | ||
| 1 | 1500514 | ASM-RES.END CAP (AA)(AB)(AD) | 1 |
| 1500589 | ASM-RES.END CAP (AC) | ||
| 1500014 | AIR VALVE ASSEMBLY | ||
| 1 | 1500019 | SCREW | 1 |
| 2 | 1500230 | EXTERNAL BEARING | 2 |
| 1500543 | NEEDLE,DAMPING ADJUST | ||
| 1 | 1500470 | PLATE-TOP,OUT | 1 |
| 1500298 | BUMPER-T/OX.4TLG 008-00-003 | ||
| 2 | 1500236 | RING,RETAINING | 2 |
| 1500257 | WIPER-U-CUP | ||
| 1500501 | PIN,SPRING | ||
| 1500525 | Discontinued | ||
| 1500256 | U-CUP | ||
| 1500579 | O-RING | ||
| 1500578 | ASM-BEARING | ||
| 1 | 1500260 | BEARING,INTERNAL | 1 |
| 1500517 | PISTON,NO BLEED,1.834 DIA | ||
| 2 | 1500516 | PLATE,BACK-UP | 2 |
| 1 | 1500472 | NUT-LOCK | 1 |
| 1 | 1500534 | JET,.122X1.425 TLG | 1 |
| 1500518 | RESERVOIR (AA)(AB)(AD) | ||
| 1500594 | Reservoir (AC) | ||
| 1 | 1500227 | O-RING | 1 |
| 1500519 | HOUSING,COMP.DAMPING (AA)(AB)(AD) | ||
| 1500590 | Asm., Housing, Damping (AC) | ||
| 1500533 | HOSE,10.00 TLG | ||
| 2 | 1500107 | FITTING,HOSE,90 DEG. | 2 |
| 1 | 1500251 | WASHER | 1 |
| 1500233 | RING,RETAINING | ||
| 1500531 | ASM-DAMPING ADJUST | ||
| 1500250 | BOLT | ||
| 1 | 1500521 | KNOB,8 CLICK | 1 |
| 1500520 | DOWEL | ||
| 1 | 1500575 | PRELOAD RING (AA)(AB)(AD) | 1 |
| 1500593 | Ring, Preload (AC) | ||
| 1 | 1500576 | RING-PRELOAD,JAM NUT (AA)(AB)(AD) | 1 |
| 1500592 | Ring, Preload, Jam Nut (AC) | ||
| 1 | 1500580 | BODY (AA)(AB)(AD) | 1 |
| 1500596 | Body (AC) | ||
| 1 | 1500581 | ROD-METERING | 1 |
| 1500503 | Discontinued | ||
| 1 | 1500508 | WASHER,BRASS BACK-UP | 1 |
| 1500502 | RING-SNAP | ||
| 1500540 | ADAPTER-SPRING RETAINER | ||
| 1500536 | COVER-DUST | ||
| 1 | 1500535 | ADJUST,RD [Incl. 54,55,58-60,62] | 1 |
| 1500541 | EXTENSION,EYELET | ||
| 2 | 1500524 | SPHERICAL BEARING | 2 |
| 1 | 1500523 | RING,SNAP,(FOX SP) | 1 |
| 1500539 | DOWEL | ||
| 1 | 1500542 | KNOB-12 CLICK | 1 |
| 1 | 1500538 | WIRE,RET.RING,SS | 1 |
| 1500507 | RETAINER,SPRING | ||
| 1 | 1500537 | O-RING | 1 |
| 1 | 1500577 | BUMPER (008-02-005) | 1 |
| 1 | 1500582 | SHAFT | 1 |
| 1 | 7556312 | WASHER-FLAT,2.26 ID | 1 |
| 1 | 1500510 | O-RING | 1 |
| 1 | 1500509 | ASM-BODY CAP (AA)(AB)(AD) | 1 |
| 1 | 1500595 | ASM-BODY CAP (AC) | 1 |
