Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8EK-21940-29-00 | FRONT FRAME COMP. | 1 |
| 8EK-2191A-00-00 | BULKHEAD | ||
| 8EK-12440-20-00 | HEAT EXCHANGER ASSY | ||
| 70 | 90267-48016-00 | RIVET, BLIND (4.8X16.4 YELLOW UN | 70 |
| 5 | 90267-48057-00 | RIVET, BLIND UN | 5 |
| 8EK-21950-08-00 | REAR FRAME COMP. | ||
| 2 | 8CR-2198J-00-00 | COVER 3 | 2 |
| 8EK-21960-09-00 | FOOTREST COMP. 1 | ||
| 8EK-21970-09-00 | FOOTREST COMP. 2 | ||
| 8EK-W2195-00-00 | FRAME CONNECTION KIT | ||
| 2 | 8CR-21943-01-00 | BRACKET, MAIN TRACK 1 | 2 |
| 2 | 8CR-21953-00-00 | BRACKET, MAIN TRACK 2 | 2 |
| 1 | 8CR-2196F-00-00 | BRACKET 3 | 1 |
| 1 | 8EK-21920-00-00 | HOUSING, REINF SUB-ASSY (L.H) | 1 |
| 3 | 8CR-21939-00-00 | BRACKET, CHAIN HOUSING | 3 |
| 2 | 8DN-21977-00-00 | CLAMP, FUEL PIPE | 2 |
| 1 | 8EK-21917-00-00 | PANEL, SUB FRAME 6 | 1 |
| 1 | 8EK-21918-00-00 | PANEL, SUB-FRAME 7 | 1 |
| 4 | 90267-48176-00 | RIVET, BLIND (4.8X17 YELLOW) | 4 |
| 1 | 8EK-2194J-00-00 | STAY, MUFFLER | 1 |
| 50 | 90267-47186-00 | RIVET, BLIND (4.7X16.4 BLACK UR UN | 50 |
| 10 | 90267-47197-00 | RIVET, BLIND (4.7X19.5 SILVER UR UN | 10 |
| 1 | 8CR-2198G-01-00 | COVER 2 | 1 |
| 2 | 90461-05003-00 | CLAMP | 2 |
| 1 | 90461-06142-00 | CLAMP | 1 |
| 90462-05059-00 | CLAMP | ||
| 1 | 90461-10148-00 | CLAMP | 1 |
| 8DF-21941-00-00 | PIPE, PIVOT 1 | ||
| 1 | 8DF-21951-00-00 | PIPE, PIVOT 2 | 1 |
| 16 | 90269-07080-00 | RIVET | 16 |
| 8DN-2198F-00-00 | COVER 1 | ||
| 2 | 8CR-2195E-00-00 | PLATE, STEERING BRACKET 1 | 2 |
| 10 | 90267-47197-00 | RIVET, BLIND (4.7X19.5 SILVER) | 10 |
| 1 | 8EK-21912-00-00 | PANEL, SUB FRAME 1 | 1 |
| 8EK-23788-00-00 | PLATE, BACK UP | ||
| 8CR-77128-00-00 | STAY 4 | ||
| 8EK-2196A-01-00 | FRAME UNDER 1 | ||
| 8EK-2196E-01-00 | FRAME, UNDER 2 | ||
| 8EK-21972-00-00 | BRACKET, GUARD FITTING | ||
| 28 | 90267-48018-00 | RIVET, BLIND (4.8X18.6 BLACK) | 28 |
| 16 | 90201-05033-00 | WASHER, PLATE | 16 |
| 24 | 90267-47187-00 | RIVET, BLIND (4.7X16.4 BLACK) | 24 |
| 1 | 8EK-77512-00-00 | BUMPER, FRONT 2 | 1 |
| 4 | 95807-08020-00 | BOLT, FLANGE | 4 |
| 8EK-21949-00-00 | BRACKET, FRONT | ||
| 1 | 8EK-21959-00-00 | BRACKET, FRONT BUMPER | 1 |
| 4 | 95607-08200-00 | NUT, SELF-LOCKING | 4 |
| 4 | 95807-08035-00 | BOLT, FLANGE | 4 |
| 4 | 90387-08015-00 | COLLAR | 4 |
| 4 | 95707-08500-00 | NUT,FLANGE (JN5) | 4 |
| 2 | 90267-48018-00 | RIVET, BLIND (4.8X18.6 BLACK) | 2 |
| 1 | 8DJ-14728-00-00 | PROTECTOR, MUFFLER 2 | 1 |
| 8EK-21923-00-00 | REINEFORCEMENT, FRAME REAR 1 | ||
| 9 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 9 |
| 8CR-21973-00-00 | HOOK | ||
| 3 | 90267-48169-00 | RIVET, BLIND (4.8X14.1 BLACK) | 3 |
| 1 | 8EK-21921-00-00 | REINEFORCEMENT, FRAME REAR 1 | 1 |
| 6 | 90105-10617-00 | BOLT, FLANGE | 6 |
| 1 | 95827-10065-00 | BOLT, FLANGE | 1 |
| 1 | 95707-10500-00 | NUT, FLANGE | 1 |
| 3 | 92907-10200-00 | WASHER, PLAIN | 3 |
| 3 | 90338-44093-00 | PLUG | 3 |
| 1 | 90338-30256-00 | PLUG | 1 |
| 1 | 8DF-21998-10-00 | SPACER | 1 |
| 1 | 8EK-77261-00-00 | LINING, SHROUD 1 | 1 |
| 1 | 8EK-77262-00-00 | LINING, SHROUD 2 | 1 |
| 1 | 8EK-77263-00-00 | LINING, SHROUD 3 | 1 |
| 1 | 8EK-77264-00-00 | LINING, SHROUD 4 | 1 |
| 1 | 8EK-77265-00-00 | LINING, SHROUD 5 | 1 |
| 1 | 8EK-77266-10-00 | LINING, SHROUD 6 | 1 |
| 1 | 8EK-77267-00-00 | LINING, SHROUD 7 | 1 |
| 1 | 8EK-77268-00-00 | LINING, SHROUD 8 | 1 |
| 1 | 8EK-77269-00-00 | LINING, SHROUD 9 | 1 |
| 8EK-21978-00-00 | PROTECTOR, FRAME | ||
| 90267-50004-00 | RIVET, BLIND |
