Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 7546601 | NYLOK NUT | 2 |
| 1 | 8450040-600 | FUEL LINE, 600 CM | 1 |
| ------- | ASM., CARBURETOR [SEE CARBURETOR PG. D6, REF. 9] | ||
| 2 | 7080511 | NARROW BAND CLAMP | 2 |
| 5410995 | Discontinued | ||
| 1 | 7080909 | CLAMP, NARROW BAND | 1 |
| 1 | 8450003-1525 | FUEL LINE, 1/4 ID | 1 |
| 1 | 7052075 | FITTING, TEE | 1 |
| 2 | 7541923 | WELL NUT | 2 |
| ------- | SCREW AND WASHER [SEE CARBURETOR PG. D6, REF. 8] | ||
| 5246551 | STRAP-CARB MNT | ||
| 7512247 | BOLT | ||
| 1 | 8360009-600 | LINE,FUEL,1/8 ID,600 CM. | 1 |
| 2 | 7512315 | BOLT | 2 |
| 2 | 7552901 | SPRING LOCK WASHER | 2 |
| 8 | 7547108 | NUT | 8 |
| 1 | 7080694 | CLAMP,HOSE,SPRING | 1 |
| ------- | HOSE, BREATHER [SEE AIR BOX PG. A12, REF. 18] | ||
| 2 | 7555815 | FLAT WASHER | 2 |
| 3110046 | Discontinued | ||
| 1 | 7080539 | CLAMP,NYLON,CABLE | 1 |
| 1 | 7621462 | RIVET | 1 |
| 5224658-067 | FRAME SUPPORT STRAP, MEDIUM GLO | ||
| 1 | 7512566 | BOLT | 1 |
| 1 | 7575202 | WASHER LOCK | 1 |
| 1 | 5210748 | WASHER | 1 |
| 1 | 5430261 | BUSHING | 1 |
| 1 | 5410421 | CLUTCH INTAKE BOOT | 1 |
| ------- | ASM., DRIVE CLUTCH, BRAKING [SEE DRIVE CLUTCH PG. C4, REF. 14] | ||
| ------- | SCREW AND WASHER [SEE CRANKCASE PG. C14, REF. 6] | ||
| ------- | BRACKET, RETAINER, SEAL [SEE CLUTCH COVER PG. C6, REF. 22] | ||
| 2 | 7080474 | HOSE CLAMP | 2 |
| 2 | 7515417 | SCREW | 2 |
| 5241150 | MOUNT-ENGINE,FRONT | ||
| 2 | 3110044 | ENGINE MOUNT ISOLATOR | 2 |
| ------- | NUT [SEE CYLINDER PG. D1, REF. 23] | ||
| ------- | WASHER [SEE CYLINDER PG. D1, REF. 22] | ||
| 1 | 1261043-029 | EXHST MANIFOLD HGH TEMP POWDER | 1 |
| ------- | GASKET, EXHAUST [SEE CYLINDER PG. D1, REF. 34] | ||
| 3087023 | Discontinued [EH42PLE052] NOTE: The Short Block assembly contains a crankcase assembly, cylinder & cylinder head assembly and a piston & crankshaft assembly. Prior authorization is required for warranty consideration. | ||
| 5241453 | MOUNT-ENGINE,TOP PLTD | ||
| 1 | 7512232 | BOLT | 1 |
| 4010132 | CABLE,GND-ENGINE | ||
| 7051011 | VALVE,CHECK | ||
| 1 | 2530009 | SMALL IN-LINE FILTER | 1 |
| 8 | 7080003 | HOSE CLAMP | 8 |
