Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8EK-14100-00-00 | CARBURETOR ASSY | |
| 2 | 8EK-14101-00-00 | CARBURETOR ASSY 1 | |
| 3 | 8EK-14102-00-00 | CARBURETOR ASSY 2 | |
| 4 | 8EK-14103-00-00 | CARBURETOR ASSY 3 | |
| 5 | 89A-14292-00-00 | LEVER A 2 | 1 |
| 6 | 89A-14243-00-00 | PLATE | 1 |
| 7 | 89A-14137-00-00 | CLIP | 1 |
| 8 | 89A-14199-00-00 | GASKET | 1 |
| 9 | 8CC-14216-00-00 | SCREW | |
| 10 | 89A-14188-00-00 | CONNECTOR | 1 |
| 11 | 3MA-14918-00-00 | RING | 2 |
| 12 | 3GF-14126-00-00 | GASKET | 2 |
| 13 | 620-14198-00-00 | GASKET | 1 |
| 14 | 3MA-14937-00-00 | CLIP | 1 |
| 15 | 3MA-14159-00-00 | CLIP | 1 |
| 16 | 8AB-14227-00-00 | WASHER (T=0.4MM) | 2 |
| 17 | 8EK-14112-15-00 | VALVE, THROTTLE 1 | 1 |
| 18 | 3H1-14147-00-00 | O-RING | 1 |
| 19 | 3H1-14962-00-00 | WASHER | 1 |
| 20 | 5K7-14134-00-00 | SPRING, AIR ADJUSTING | 1 |
| 21 | 89A-14565-00-00 | SCREW, PILOT ADJUSTING | 1 |
| 22 | 3H1-14142-55-00 | JET, PILOT (#55) AP | 1 |
| 3H1-14142-52-00 | JET, PILOT (#52.5) AP | 1 | |
| 3H1-14142-47-00 | JET, PILOT (#47.5) AP | 1 | |
| 3H1-14142-45-00 | JET, PILOT (#45) STD | 1 | |
| 3H1-14142-50-00 | JET, PILOT (#50) AP | 1 | |
| 23 | 89A-14996-00-00 | PIPE | 1 |
| 24 | 1T1-14116-A4-00 | NEEDLE | |
| 25 | 89A-14141-48-00 | NOZZLE, MAIN | |
| 26 | 1LX-14153-00-00 | WASHER, MAIN JET | 1 |
| 27 | 89A-14194-00-00 | RING | 1 |
| 28 | 3G2-1423A-82-00 | JET, MAIN (#157.5) AP | 1 |
| 3G2-1423E-60-00 | JET, MAIN (#151.3) AP | 1 | |
| 3G2-1423E-61-00 | JET, MAIN (#153.8) AP | 1 | |
| 3G2-1423E-59-00 | JET, MAIN (#148.8) AP | 1 | |
| 3G2-1423E-58-00 | JET, MAIN (#146.3) AP | 1 | |
| 3G2-1423E-62-00 | JET, MAIN (#156.3) STD | 1 | |
| 3G2-1423E-63-00 | JET, MAIN (#158.8) AP | ||
| 3G2-1423E-56-00 | JET, MAIN (#141.3) AP | 1 | |
| 3G2-1423A-80-00 | JET, MAIN (#147.5) AP | 1 | |
| 3G2-1423E-55-00 | JET, MAIN (#138.8) AP | 1 | |
| 3G2-14231-30-00 | JET, MAIN (#150) AP | 1 | |
| 3G2-1423E-57-00 | JET, MAIN (#143.8) AP | 1 | |
| 3G2-1423A-81-00 | JET, MAIN (#152.5) AP | 1 | |
| 3G2-14231-28-00 | JET, MAIN (#140) AP | 1 | |
| 3G2-14231-29-00 | JET, MAIN (#145) AP | 1 | |
| 3G2-14231-32-00 | JET, MAIN (#160) AP | 1 | |
| 3G2-14231-31-00 | JET, MAIN (#155) AP | 1 | |
| 29 | 500-14115-00-00 | PLUG, SCREW | 1 |
| 30 | 558-14147-00-00 | O-RING | 1 |
| 31 | 2LN-14565-00-00 | SCREW | 1 |
| 32 | 8EK-14185-00-00 | FLOAT | |
| 33 | 537-14186-00-00 | PIN, FLOAT | 1 |
| 34 | 1AE-14190-13-00 | NEEDLE VALVE ASSY | 1 |
| 35 | 89A-14147-00-00 | O-RING | 1 |
| 36 | 8F2-14147-00-00 | O-RING | 1 |
| 37 | 1J7-14994-00-00 | NET, FILTER | 1 |
| 38 | 89A-14216-00-00 | SCREW 1,3 | 1 |
| 39 | 95302-05700-00 | NUT 1,3 | 1 |
| 40 | 89A-14276-00-00 | LEVER 1,3 | |
| 41 | 89A-14286-00-00 | SPRING 1,3 | 1 |
| 42 | 89A-14905-00-00 | LEVER, STARTER 1,3 | |
| 43 | 8EK-14251-00-00 | NIPPLE 1,3 | |
| 44 | 98501-04014-00 | SCREW, PAN HEAD | 4 |
| 45 | 12R-14191-00-00 | PLUG, DRAIN | 1 |
| 46 | 239-14172-10-00 | PILOT JET, AIR (1.0) | 1 |
| 47 | 302-14173-00-00 | COVER, PLUNGER CAP | |
| 48 | 8EK-14171-00-00 | PLUNGER, STARTER | |
| 49 | 1AW-14135-00-00 | SPRING, PLUNGER | 1 |
| 50 | 1FN-14174-00-00 | CAP, PLUNGER | |
| 51 | 1AE-14147-00-00 | O-RING | 1 |
| 52 | 8CH-14995-00-00 | BRACKET 2 | |
| 53 | 98502-04010-00 | SCREW, PAN HEAD 2 | 1 |
| 54 | 8CC-14122-00-00 | SCREW, THROTTLE 2 | 1 |
| 55 | 2J2-14133-00-00 | SPRING, THROTTLE STOP 2 | 1 |
| 56 | 89A-14265-00-00 | COLLAR 2 | 1 |
| 57 | 22F-14117-00-00 | WASHER, PLUG SCREW 2 | 1 |
| 58 | 1UF-14952-00-00 | WASHER 2 | |
| 59 | 89A-14594-00-00 | NUT 2 | 1 |
| 60 | 89A-24529-00-00 | SPRING 2 | 1 |
| 61 | 87S-8259A-00-00 | SWITCH, CARBURETOR 2 | 1 |
| 62 | 98702-05008-00 | SCREW, FLAT HEAD 2 | |
| 63 | 8EK-14348-00-00 | PIPE 1 1,3 | |
| 64 | 8EK-14349-00-00 | PIPE 1,3 | |
| 65 | 8CH-14348-00-00 | PIPE 1 1,3 | |
| 66 | 8F2-14197-00-00 | PIPE 2 | |
| 67 | 89A-14198-00-00 | GASKET | 3 |
| 68 | 97605-04110-00 | SCREW, PAN HEAD WITH WASHER | 6 |
| 69 | 98702-04014-00 | SCREW, FLAT HEAD | |
| 70 | 1AE-14135-00-00 | SPRING, PLUNGER | |
| 71 | 3H1-14227-00-00 | WASHER | |
| 72 | 89A-14264-00-00 | COLLAR | |
| 73 | 8CH-14589-00-00 | SPRING | |
| 74 | 89A-14118-00-00 | CAP | |
| 75 | 97602-04116-00 | SCREW, PAN HEAD WITH WASHER | 2 |
| 76 | 89A-14208-00-00 | LEVER COMP. 1 | |
| 77 | 11H-14991-00-00 | SCREW | 3 |
| 78 | 98502-05012-00 | SCREW, PAN HEAD | 12 |
| 79 | 35H-14139-00-00 | CLIP, PIPE | 6 |
| 80 | 8CH-14978-00-00 | SHAFT, STARTER LEVER | |
| 81 | 90467-10035-00 | CLIP | 4 |
| 82 | 8CH-14987-10-00 | HOSE | |
| 83 | 97602-05110-00 | SCREW, PAN HEAD WITH WASHER | 1 |
| 84 | 3FV-14962-00-00 | WASHER | |
| 85 | 89A-14588-00-00 | LEVER | |
| 86 | 22F-14117-00-00 | WASHER, PLUG SCREW | 1 |
| 87 | 22F-14115-00-00 | PLUG, SCREW | |
| 88 | 5FL-85885-00-00 | THROTTLE SENSOR ASSY | 1 |
| 89 | 8CC-14216-10-00 | SCREW | 2 |
| 90 | 8DN-82309-00-00 | WIRE, SUB LEAD | |
| 91 | 4N0-14251-00-00 | NIPPLE | 1 |
| 92 | 8EK-14251-00-00 | NIPPLE | |
| 93 | 89A-24452-00-00 | COVER |
